Радиочастотная Идентификация ультравысокой частоты Зарядное устройство USB оборот в минуту (R/W кодировщик ZUD18RW для EPC ISO18000-6C тег чтения
- Категория: Other Access Control Products >>>
- Поставщик: Shenzhen,radio,Technology,Co.,Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 105.86 $* | 110.9 $* |
| Aug-19-2025 | 104.57 $* | 109.89 $* |
| Jul-19-2025 | 87.37 $* | 91.92 $* |
| Jun-19-2025 | 102.13 $* | 107.90 $* |
| May-19-2025 | 89.19 $* | 93.1 $* |
| Apr-19-2025 | 100.28 $* | 105.83 $* |
| Mar-19-2025 | 99.25 $* | 104.4 $* |
| Feb-19-2025 | 99.18 $* | 104.18 $* |
| Jan-19-2025 | 98.58 $* | 103.62 $* |
Характеристики
OVERVIEW
UHF desktop card issuer is a UHF band multi-purpose non-encrypted card issuer that reads the EPC number of UHF tags or cards. Combined with UHF contactless RF circuit and various codec algorithms, it can read EPCglobal UHF Class 1Gen 2/ISO 18000-6C tags/cards with a USB communication interface.USB adopts advanced plug-and-play interface without driver core technology to realize connection with PC and related devices through USB port. The reader control chip comes with watchdog and voltage detection circuit for stable performance.
It can read and write cards and has the advantages of a buzzer prompt, small size, fast reading rate, high receiving sensitivity, small working current, USB power supply, high performance, etc. It can be widely used in all kinds of parking management, personnel access control management, library, consumption management, attendance management, and other systems.
FEATURE
●USB-HID drive-free design, easy-to-use connection, and secondary development.
●Self-contained antenna, no need for external connection.
●Connect the USB for active mode, connect the USB, and perform DEMO operation for passive mode. ●The active-passive mode can be switched by itself.
●Read the card successfully once, beep once, and flash the green light.
●The cursor currently defines the window, and the card number will be displayed in the window.
●This card issuer supports Windows, Android, and Linux systems.
●Can be set to read-only or read-write.
●Card writing and reading DEMO software is available to facilitate card issuance and card writing.
●Self-contained antenna, no need for external connection.
●Connect the USB for active mode, connect the USB, and perform DEMO operation for passive mode. ●The active-passive mode can be switched by itself.
●Read the card successfully once, beep once, and flash the green light.
●The cursor currently defines the window, and the card number will be displayed in the window.
●This card issuer supports Windows, Android, and Linux systems.
●Can be set to read-only or read-write.
●Card writing and reading DEMO software is available to facilitate card issuance and card writing.
Specification
Item | Value |
Place of Origin | China |
Guangdong | |
Brand Name | OEM |
Model Number | ZUD18R/W |
Special Features | USB-HID Data output |
Network | None |
Application | Indoor |
Product name | UHF RFID USB Desktop Read/Write Encoder |
Material | ABS Plastic |
Work frequency | 902-928MHz( 865-868MHz available) |
Protocol | EPC GEN1 CLASS2 / ISO18000-6C |
Work mode | Passive/ Active mode can be set |
USB-HID output | Available |
PC-end Demo | Available |
Power supply | DC 5V |
Size | 107*107*23mm |
Support O/S | Windows / Android / Linux |
Work current | Quiescent current 70 mA, work current 150 mA |
Work temperature | -10℃ ~ +70℃ |
Storage tepmerature | -20℃~+80℃ |
Operating humidity | 15%~90% |
FAQ
1. who are we?
We are based in Guangdong, China, start from 2016,sell to Domestic Market(20.00%),Northern Europe(20.00%),North America(20.00%),Western Europe(5.00%),Eastern Asia(5.00%),Mid East(5.00%),Southeast Asia(5.00%),Eastern Europe(5.00%),South America(5.00%),South Asia(4.00%),Central America(2.00%),Africa(2.00%),Southern Europe(2.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Access control,RFID security Reader,IoT security access control,IC card reader,UHF RFID reader
4. why should you buy from us not from other suppliers?
ZKRadio Tech. have over 20 years of experience in RFID field, a leader company of RFID access control products in China. We have our own R&D team and factory for your need, welcome to place OEM/ODM order.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,DDP,Express Delivery；
Accepted Payment Currency:USD,EUR,AUD,GBP,CNY;
Accepted Payment Type: T/T,Credit Card,Western Union;
Language Spoken:English,Chinese
We are based in Guangdong, China, start from 2016,sell to Domestic Market(20.00%),Northern Europe(20.00%),North America(20.00%),Western Europe(5.00%),Eastern Asia(5.00%),Mid East(5.00%),Southeast Asia(5.00%),Eastern Europe(5.00%),South America(5.00%),South Asia(4.00%),Central America(2.00%),Africa(2.00%),Southern Europe(2.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Access control,RFID security Reader,IoT security access control,IC card reader,UHF RFID reader
4. why should you buy from us not from other suppliers?
ZKRadio Tech. have over 20 years of experience in RFID field, a leader company of RFID access control products in China. We have our own R&D team and factory for your need, welcome to place OEM/ODM order.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,DDP,Express Delivery；
Accepted Payment Currency:USD,EUR,AUD,GBP,CNY;
Accepted Payment Type: T/T,Credit Card,Western Union;
Language Spoken:English,Chinese
