Dn15 dn20 dn25 домашний счетчик воды по хорошей цене расхода с несколькими
- Категория: Water Meters >>>
- Поставщик: Kaifeng,Xintai,Valve,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 7.21 $* | 7.50 $* |
| Aug-15-2025 | 7.75 $* | 7.31 $* |
| Jul-15-2025 | 6.38 $* | 6.24 $* |
| Jun-15-2025 | 7.97 $* | 7.93 $* |
| May-15-2025 | 6.27 $* | 6.23 $* |
| Apr-15-2025 | 7.39 $* | 7.76 $* |
| Mar-15-2025 | 7.70 $* | 7.46 $* |
| Feb-15-2025 | 7.41 $* | 7.23 $* |
| Jan-15-2025 | 7.69 $* | 7.47 $* |
Характеристики
Product Description
Dimension
Model | Nominal Caliber | Lenght | Width | Height | Connection Thread | Connection Thread | ||||||
L | L1 | W | H | d | D | |||||||
mm | Mark | |||||||||||
LXSY-15E | 15 | 165 | 260 | 99 | 106 | R 1/2 | G 3/4 | |||||
LXSY-20E | 20 | 195 | 300 | 99 | 106 | R 3/4 | G1 | |||||
LXSY-25E | 25 | 225 | 345 | 104 | 112 | R 1 | G 1 1/4 | |||||
LXSY-40E | 40 | 245 | 365 | 128 | 156 | R 1 1/2 | G2 | |||||
Specification
Nominal Caiber DN | Range Ratio Q3/Q1 | Over Flow | Common Flow | Transitional Flow | Min Flow | Mix Display | Max Display | |||
Q4 | Q3 | Q2 | Q1 | m³/h | ||||||
mm | m³/h | L/h | ||||||||
15 | 80 | 3.125 | 2.5 | 50 | 31.25 | 0.0001 | 99999 | |||
160 | 25 | 15.6 | ||||||||
20 | 80 | 5 | 4 | 80 | 50 | 0.0001 | 99999 | |||
160 | 40 | 25 | ||||||||
25 | 80 | 7.875 | 6.3 | 126 | 78.75 | 0.0001 | 99999 | |||
160 | 63 | 39.4 | ||||||||
40 | 80 | 20 | 16 | 320 | 200 | 0.001 | 999999 | |||
160 | 160 | 100 | ||||||||
1. The maximum allow error is 5% from the low zone including Q1 to the low zone that not include Q2; from the high zone including Q2 to the high zone including overload Q2, the maximum allowable error is 2%
2. The water meter is wet, and the wheel drives between the counting mechanism and the measuring mechanism; 3. The word wheel part adopts liquid seal, the pointer part keeps filling with water for a long time, and the mechanism is tight;
4. High measurement accuracy, small initial flow.
5. Max Permissible working pressure is 1.0MPa
6. The maximum permissible temperature of the measured liquid is 30 degrees Celsius
7. Pressure Loss is △P63
8. Up and down flow field sensitivity grade U10D5
9. Unmeasured reverse flow
Company Profile
Certifications
Packing & Delivery
Installation Site
FAQ
Q1: Can I get free samples?
A: Yes, we can provide you with free samples, but you have to bear the delivery costs
Q2: Can your company print our brand logo on your products?
A: With the customer's permission, our factory can print the customer logo on the product. However, the customer needs to provide us with a logo authorization so that we can print the customer logo on the product.
Q3: What are your quality control procedures?
A: We adhere to strict quality control procedures, from product design to the end of the production process, using the most advanced quality control equipment, so that all processes are always in the best state of control.
Q4: Can I request a change in packaging and shipping?
A: Yes, we can change the packing and shipping method according to your requirements, but the cost and difference incurred in the meantime will be your responsibility.
Q5: What are your payment terms?
A: T/T, L/C, Alibaba Trade guarantee is available to provide full protection for your orders.
Q6: What is the standard lead time for each order?
A: It depends on the number of orders you need to purchase. Normally, we complete the order within 15 days.
A: Yes, we can provide you with free samples, but you have to bear the delivery costs
Q2: Can your company print our brand logo on your products?
A: With the customer's permission, our factory can print the customer logo on the product. However, the customer needs to provide us with a logo authorization so that we can print the customer logo on the product.
Q3: What are your quality control procedures?
A: We adhere to strict quality control procedures, from product design to the end of the production process, using the most advanced quality control equipment, so that all processes are always in the best state of control.
Q4: Can I request a change in packaging and shipping?
A: Yes, we can change the packing and shipping method according to your requirements, but the cost and difference incurred in the meantime will be your responsibility.
Q5: What are your payment terms?
A: T/T, L/C, Alibaba Trade guarantee is available to provide full protection for your orders.
Q6: What is the standard lead time for each order?
A: It depends on the number of orders you need to purchase. Normally, we complete the order within 15 days.
