Горячая Распродажа Одобрено CE Высоковольтный полностью медный генератор природного газа/сжиженный газ/биогазовый 200 кВт


Поделиться:


Цена:150 000,00 $ - 156 000,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-16-2025 178500.70 $* 187425.19 $*
Aug-16-2025 177000.63 $* 185850.76 $*
Jul-16-2025 148500.70 $* 155925.35 $*
Jun-16-2025 174000.49 $* 182700.0 $*
May-16-2025 151500.29 $* 159075.49 $*
Apr-16-2025 171000.28 $* 179550.23 $*
Mar-16-2025 169500.44 $* 177975.91 $*
Feb-16-2025 168000.69 $* 176400.6 $*
Jan-16-2025 166500.93 $* 174825.25 $*

Характеристики



Product Description






Specification


Unit model:
MGRQ300GF
Steady state voltage adjustment rate (%):
≤± 1
Output power:
300KW
Voltage fluctuation rate (%):
≤ ± 0.5
Power factor:
COSΦ = 0.8 (lagging)
Transient voltage adjustment rate (%):
+20 ~-15
Output voltage:
400V / 230V
Voltage stabilization time (s):
≤1
Output current:
540A
Steady state frequency adjustment rate (%):
≤ ± 1
Rated frequency:
50Hz
Frequency fluctuation rate (%):
≤ ± 0.5
Rated speed:
1500rpm
Transient frequency adjustment rate (%):
+ 10 ~ -7
Gas grade:
LNG/CNG/Biogas
Frequency stabilization time (S):
≤3
Dimensions:
3000×1050×1700(L×W×H mm)
gas consumption (100% load):
0.6L/kW·h
Start mode:
2800kg
Acoustic noise (LP7m):
≤95dB(A)
Dimensions:
2150×750×1500(L×W×H mm)
Gas consumption (100% load):
0.6L/kW·h
Weight:
950kg
Acoustic noise (LP7m):
≤95dB(A)
Technical parameters of gas engine:
Brand/origin:
Weifang Gas Engine
Cooling method:
closed water circulation cooling
model:
4105D-NG
Ignition method:
Spark plug ignition
Number of cylinders / Dare to mention structure:
6 / L Type
control method:
ECU control
Bore stroke:
105 × 125 mm
Intake method:
inhale naturally
Compression ratio:
16.5:1
Overload capacity:
110%
Start mode:
DC 12V Electric start
Speed:
1500rpm
Technical parameters of generator:
Brand:
Stanford.
Protection level:
IP22
Model:
s1
Wiring mode:
Three-phase four-wire, Y-connection
Rated power:
20kW
Adjustment method:
AVR (Automatic Voltage Regulator)
Rated voltage:
400V / 230V
Output frequency:
50Hz
Insulation class:
H class
Output factor:
COSΦ = 0.8 (lag)
The standard configuration of the generator set is as follows:
Ø EFI internal combustion engine (gas);
Ø AC synchronous generator (single bearing);
ØSuitable for ambient temperature 40 ℃ -50 ℃ radiator water tank, belt driven cooling fan, fan safety shield;
Ø Power generation output air switch, standard control screen;
Ø Unit steel common base (including: unit vibration damping rubber pad);
Ø Dry air filter, fuel oil, lubricating oil filter, start motor, and equipped with self-charging generator;
Ø Random information: original technical documents of gas engine and generator, generator set manual, test report, etc.


Packing & Delivery




plywood or according the customer requirement for 40kw Natural gas/biogas/gas generator with stamford alternator


Company Profile




Qingdao Moore Power is located in the diesel engine manufacturing city, Weifang. For many years, we have become a professional manufacturer of diesel generators.

The power range of our generating set is from 5KW to 2200KW. It is coupled by world famous brand engine such as CUMMINS, PERKINS, DEUTZ, DOOSAN, YUCHAI etc., with world famous brand alternator such as STAMFORD, MARATHON, LEROY SOMER, etc. And we are the OEM manufacturer of Cummins, Doosan, Yuchai and so on. Our products are with advantage of Lower noise, lower vibration, easily starting, reliable performance, which can be widely used in factories, mines, banks, hospitals, ship building, telecommunications, oil fields, buildings, construction fields and other fields, or used as the standby power.

QD Moore has import and export rights, we has establish business relationship with 28 provinces, municipalities and autonomous regions, mainly export products to over 40 countries and regions in Europe, Africa, South America, Latin America, Southeast Asia, West Asia and other, already establish a solid partnership with more than 20 countries in Asia, Africa, the Americas, Europe etc.

We are committed to providing efficient, energy-saving, eco-friendly, high-quality and reliable diesel generator sets to ensure clients' satisfaction. We accept small orders and provide competitive price and high quality. Quick delivery time is also our advantage.


FAQ


1. Are you a factory or trader ?
We are factory,it is located in Weifang city which is the biggest area of power manufacturing in China. And we get the import and export right by QingDao Moore Golden trading in order to supply one-stop service which can save lots of cost and time for our customers.

2. What is our warranty for the machine? How about our warranty?
We will provide 1-year warranty for each machine. If some parts of the machine cannot work, just send a small video to us, and we will be able to judge which parts cannot work, and mail the non working parts to you for free, vividly instructing you to replace them.

3.How about your design ability? Do you provide OEM service?
We have our own design department and provide design services for thousands of partners. OEM accepts that we provide aconfidentiality agreement "trade secret contract" for your design security.

4. How to operate the disel generator set?
a. Add water/antifreeze (depending on temperature)
b. Add oil, recommend CD/CF grade
c. Add No. 0 diesel
d. Connect the output wire
e.Connect the cables
f. Start the generator to output electricity
