Белый лист ПТФЭ с высокой устойчивостью к истиранию при высоких температурах пластиковая доска политетрафторэтилен естественного

Белый лист ПТФЭ с высокой устойчивостью к истиранию при высоких температурах пластиковая доска политетрафторэтилен естественного

Категория: PTFE >>>
Поставщик: Foshan,Kuliwei,Industrial,Material,Co.,Ltd.

Цена:0,36 $ - 0,38 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.53 $*	0.13 $*
Aug-16-2025	0.2 $*	0.81 $*
Jul-16-2025	0.8 $*	0.51 $*
Jun-16-2025	0.16 $*	0.27 $*
May-16-2025	0.48 $*	0.55 $*
Apr-16-2025	0.12 $*	0.81 $*
Mar-16-2025	0.16 $*	0.35 $*
Feb-16-2025	0.40 $*	0.43 $*
Jan-16-2025	0.1 $*	0.1 $*

Характеристики

Product Description

Material Introduction

PTFE molded sheet is manufactured by molding method with PTFE granular resin. In fluoroplastics, PTFE got the most consumption and was used widely. It’s an important material in variety of fluoroplastics. PTFE exhibits astonishing chemical resistance. This self-lubricating material provides a low friction coefficient, and is ideally suited for the manufacture of corrosion-resistant gaskets & seals.

PTFE SHEET
*length(mm)width(mm)**	thickness(mm)
	Nominal thickness	Tolerance
150 x 150	1.0 ~ 150	±0.30 ~ ±0.50
250 x 250	1.5 ~ 100	±0.30 ~ ±0.50
300 x 300	1.5 ~ 100	±0.30 ~ ±0.50
450 x 450	1.5 ~ 100	±0.30 ~ ±0.50
600 x 600	1 ~ 100	±0.30 ~ ±0.50
800 x 800	1 ~ 100	±0.30 ~ ±0.50
1000 x1000	1 ~ 100	±0.30 ~ ±0.50
1200 x 1200	2 ~ 100	±0.30 ~ ±0.50
1500 x 1500	3 ~ 100	±0.50 ~ ±0.80
1600 x 1600	3 ~ 100	±0.50 ~ ±0.80
2000 x 1000	3 ~ 100	±0.60 ~ ±1 .0
1800 x 1800	3 ~ 100	±0.60 ~ ±1 .0
2000 x 2000	3 ~ 100	±0.60 ~ ±1 .0

PTFE ROD
Diameter (mm)	Tolerance	Lenght (mm)	Tolerance
Φ4 - Φ9	+0.5	1000	+5.0
Φ10 - Φ18	+1.0	1000	+0.5
Φ20 - Φ50	+1.5	1000	+0.5
Φ55- Φ200	+2.5	1000	+0.5

Name: PTFE (polytetrafluoroethylene)
Colors include: White
Types: sheets, rod

Characteristics:

♦ Superior endurance in corrosion
♦ Non-flammable,limited oxygen index is under 90.
♦ Low friction coefficient
♦ Non-viscous, Self-lubricating
♦ Superior endurance in high & low temperature, can be used -200~260℃
♦ High electrical insulation
♦ Atmospheric aging resistance
♦ Low permeability, good gas barrier property
♦ Good physiological compatibility and anti-thrombotic

Applications:

♦ Corrosion resistance: widely used in all chemical containers and parts which contacted with corrosive media, such as tanks, reactors, equipment lining, valves, pumps, fittings, filter materials, separation materials and pipe for corrosive fluids.
♦ Abrasion resistance: can be used as a self lubricating bearing, piston rings, seal rings, gaskets, valve seats, sliders and rails etc..
♦ Insulation materials: mainly used in the manufacture of various products with high temperature resistance, high-frequency resistance, electrical insulation and arc resistance, such as high-frequency cables, moisture-resistant cables, capacitor coils, insulating cover for wire, etc..
♦ Medical materials: such as artificial blood vessels, heart, esophagus, peritoneum, heart devices, a variety of intubation tubes and catheters.
♦ Non-stick materials: can be used for non-stick coating such as non-stick pan and non-stick roller for food processor.
