Key Specifications/ Special Features:
EngineROTAX 850 E-TECROTAX 600R E-TEC
Engine detailsLiquid-cooled, two-stoke, eRAVE™Liquid-cooled, two-stoke, eRAVE™
Cylinders22
Displacement849 cc / 51.9 in.³599.4 cc / 36.6 in.³
Bore82 mm / 3.2 in.72.3 mm / 2.85 in.
Stroke80.4 mm / 3.2 in.73 mm / 2.87 in.
Maximum engine speed7,900 RPM8,100 RPM
CarburationE-TEC ® direct injection with additional booster injectorsE-TEC ® direct injection
Recommended fuel typePremium unleadedPremium unleaded
Minimum octane9191
Fuel tank36 L / 9.5 US gal36 L / 9.5 US gal
Oil tank capacity3.4 L / 3.6 qt3.4 L / 3.6 qt
FrameREV® Gen4
BodyworkNarrow design
SkisPilot™ X
Pilot™ TX (optional)
SeatingTrail performance
HandlebarU-shaped aluminum with J-hooks / Transparent handguards
Riser block heightAdjustable-120 mm / 4.7 in.
StarterElectric
ReverseRER™
Heated throttle lever/ gripsStandard
Gauge Type7.2-in. wide digital display, 7.8-in. wide LCD color display (opt.)
MirrorsOptional
WindshieldOptional
RunnerRound 1/2
Carbide configuration102 mm / 4 in. at 90°
