Хит продаж, высокопрочный насос для бетонных насосов
US $4800-$5300
Известный бренд Бетономешалка 25 м дизельный бетононасос JH5025 с системой
- Категория: Concrete Pumps >>>
- Поставщик: Sinomada,Heavy,Industry,(Changsha),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 69020.97 $* | 72471.52 $* |
| Aug-19-2025 | 68440.68 $* | 71862.96 $* |
| Jul-19-2025 | 57420.29 $* | 60291.90 $* |
| Jun-19-2025 | 67280.60 $* | 70644.66 $* |
| May-19-2025 | 58580.53 $* | 61509.54 $* |
| Apr-19-2025 | 66120.98 $* | 69426.26 $* |
| Mar-19-2025 | 65540.65 $* | 68817.75 $* |
| Feb-19-2025 | 64960.94 $* | 68208.77 $* |
| Jan-19-2025 | 64380.3 $* | 67599.45 $* |
Характеристики
PRODUCT DESCRIPTION
Best Price 25M Mini Small Concrete Pump Truck JH5025 on Sale.
Jib structure system
jib structure system is based on the finite element analysis,dynamic analysis and test,and the accurate date support. High strenth low alloy steel plate,all materials and welding line by 100% non-destructive technology ensure the jib structure reasonable and highly reliable.
"R" type arms with speed stepless adjustment,pressure compensation and load sensing proportion control syetem ensure the arm running freely and excellent operating performance
jib structure system is based on the finite element analysis,dynamic analysis and test,and the accurate date support. High strenth low alloy steel plate,all materials and welding line by 100% non-destructive technology ensure the jib structure reasonable and highly reliable.
"R" type arms with speed stepless adjustment,pressure compensation and load sensing proportion control syetem ensure the arm running freely and excellent operating performance
PRODUCT PARAMETER
Item | Unit | Parameter | ||
Pumping System | Model | JH5025 | ||
Max. Output | m³/h | 50 | ||
Max. outlet pressure (H/L pressure) | Mpa | 13/7.6 | ||
Rated working pressure | Mpa | 31.5 | ||
Pumping frequency (H/L pressure) | times/min | 14/23 | ||
Hopper capacity | m3 | 0.65 | ||
Feeding height | mm | 1500 | ||
Hydraulic system type | Open circuit | |||
The type of distribution valve | S VALVE | |||
Oil cylinder diameter | mm | DN125 | ||
Concrete cylinder diameter | mm | DN200 | ||
Cooling type of hydraulic oil | Fan cooling | |||
Jib Structure System | Max. placing height | m | 25 | |
Rotary angle | ° | 365 | ||
Arm foldable angle | ° | 90/180/360/540 | ||
Arms section quantity | section | 4 | ||
Chassis and Vehicle | Chassis brand | DO NGFENG | ||
Wheelbase | mm | 4700/5000/5200 | ||
Power of engine | kw | 132 DON GFENG | ||
Rated speed of engine | rpm | 2200 | ||
Emission standard | National IV | |||
Total weight of vehicle | kg | 15500 | ||
Overall dimension of vehicle (L*W*H) | mm | 9650×2500×3500 | ||
Others parameter | Hydraulic oil hopper capacity | L | 300 | |
Water tank capacity | L | 300 | ||
Lubricating mode | Centralized automatic | |||
Control mode | Manual and Remote control | |||
PRODUCT PICTURES
