Application Range

(1). Testing the location, distribution, direction, and diameter of the rebar and the thickness of cover in concrete structure projects.

(2). Inspecting and accepting concrete structural construction quality.

(3). Evaluating the quality of construction.

(4). Establishing the location of rebar for drilling, cutting and coring operations.

(5). Testing the distribution and direction of electric cables, pipelines and metalwork inside walls and floors.

(6). Testing the quantity of rebar when evaluating and developing the old structure, such as installation of furniture and air-condition.

1.3 Features

The high resolution LCD display: 128 x 128 pixels;

 The intuitive operation and handheld ergonomic design with good durability;

 Accurately detect the location of the rebar;

Help extend life of drill and avoid damage when drilling and coring;

The multi coil structure design with high speed, high precision and high resolution;

The built-in high capacity lithium battery, low power consumption, standby for no less than 20h.



Items	Technical Spec.
Diameter Measuring Range(mm)	6~50
Measuring Range(mm)	Location Range: 1~120 First Range: 1~60 Second Range: 30~120
Thickness Measuring Accuracy(mm)	1~40	±1
	41~60	±2
	61~80	±3
	81~100	±5
	101~120	±8
Rebar Location Accuracy	1~60	±3
	61-120	±6
Diameter Measuring Modes	Optional
JGJ  Measurement	Optional
Data Storage	Optional
Off Time	Automatic
Power Supply	Rechargeable Lithium Battery
Working Temperature	-10℃~+42℃
Size(mm)	170×78×38
Weight(kg)	0.28

---------------------------------------------------------------------------
