2023 китайские поставщики обеспечивают высокую гарантию 50 Гц бытовые и промышленные
- Категория: Energy Meters >>>
- Поставщик: Delixi,(Hangzhou),Inverter,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 6.1 $* | 6.92 $* |
| Jul-16-2025 | 5.50 $* | 5.27 $* |
| Jun-16-2025 | 6.19 $* | 6.91 $* |
| May-16-2025 | 6.70 $* | 6.8 $* |
| Apr-16-2025 | 5.89 $* | 5.93 $* |
| Mar-16-2025 | 6.10 $* | 6.74 $* |
| Feb-16-2025 | 6.44 $* | 6.93 $* |
| Jan-16-2025 | 6.52 $* | 6.12 $* |
Характеристики
Supply Ability
Supply Ability :100000 Piece/Pieces per Month
Product Description
Features
(1)Starting current: active power≤0.4% (Power factor=1).
(2) Creeping: Under 115%Un voltage circuit, when the current in current loop is 0, the output impulse less than one.
(3) Power loss: The power loss of voltage loop＜0.8W, apparent power loss of current loop＜1VA.
(4) Working power supply voltage: 0.8Un～1.15Un.
(5)Working temperature: -20℃～55℃, relative humidity: 25%～95%
(6)Overall dimension: 225×112×59mm
(2) Creeping: Under 115%Un voltage circuit, when the current in current loop is 0, the output impulse less than one.
(3) Power loss: The power loss of voltage loop＜0.8W, apparent power loss of current loop＜1VA.
(4) Working power supply voltage: 0.8Un～1.15Un.
(5)Working temperature: -20℃～55℃, relative humidity: 25%～95%
(6)Overall dimension: 225×112×59mm
Specification
Rated voltage(V) | Rated frequency | Normal current & Rated max. current (A) | Accuracy |
230 | 50Hz | 5（20） | Class 1 |
5（40） | |||
5（60） | |||
10（40） | |||
10（60） | |||
20（80） | |||
30（100） |
Intrinsic error
Load current | Active power with class 1.0/ Power factor | Intrinsicerror(%)/ Class 1 |
0.05Ib≤I＜0.1Ib | 1.0 | ±1.5 |
0.1Ib≤I≤Imax | 1.0 | ±1.0 |
0.1Ib≤I＜0.2Ib | 0.5(L)or 0.8(C) | ±1.5 |
0.2Ib≤I≤Imax | 0.5(L)or 0.8(C) | ±1.0 |
Applications
About Us
Hangzhou Xizi Group Co., Ltd. is one of the earliest enterprises producing instruments in China, and is the designer,
manufacturer and leader of new instruments in the past. The company mainly produces leading products such as "Xizi" brand electric energy meters, transmitters and comprehensive protection devices for electric power automation.
manufacturer and leader of new instruments in the past. The company mainly produces leading products such as "Xizi" brand electric energy meters, transmitters and comprehensive protection devices for electric power automation.
The products have won many national, provincial and municipal awards for excellent technology and excellent new products.
Certificate
Packaging & Delivery
FAQ
1、Are you trading company or manufacturer ?
We are factory.
2、Do vou provide samples?
Yes, we could offer the sample
3、What's thenpayment term?
We accept T/T,L/C,WEST UNION, PAYPAL,CASH.
4、What is the standard of packaging?
Export standard packaging or special packaging according to customer requirements.
5、Can you accept to use our logo?
We accept OEM and your authorization or OEM/OEM&ODM, we can help you design and put into products any lighting you customize.
6、Can you accept small quantity sample order?
Of course
