Новая EATON 145487AA AIRFLEX ROTO SEAL

Категория: Other Power Transmission Parts >>>
Поставщик: Henan,Dalin,Rubber,And,Telecommunications,Apparuts,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	0.30 $*	0.44 $*
Aug-18-2025	0.91 $*	0.80 $*
Jul-18-2025	0.8 $*	0.8 $*
Jun-18-2025	0.51 $*	0.16 $*
May-18-2025	0.83 $*	0.38 $*
Apr-18-2025	0.23 $*	0.32 $*
Mar-18-2025	0.16 $*	0.35 $*
Feb-18-2025	0.41 $*	0.1 $*
Jan-18-2025	0.12 $*	0.57 $*

Характеристики

NEW EATON 145487AA AIRFLEX ROTO SEAL 3/4 RH

rotor seal (1).jpg rotor seal (2).jpg rotor seal (3).jpg rotorseal (6).jpg rotorseal (7).jpg rotorseal (8).jpg

The Airflex rotorseal is a rotary union (rotary joint) which permits the transfer of gases or liquids, under pressure or vacuum, into or out of the exposed end of a rotating shaft or body.

It was designed primarily for the passage of compressed air or hydraulic fluid to control clutches or brakes. Other applications include the transmittal of cutting fluid to machine tools, lubrication of shaft-mounted components and circulation of oil for cooling systems.

The rotating seal is established by a non-metallic sealing ring, held against the rotorseal shaft by a light spring force. The sealing ring is designed so that media pressure acts on both of its ends to minimize the force on the sealing surface.

Description	3/4 RH	1 RH	1 1/4 RH	1 1/2 RH	2RH
Rotorseal	145487AA	145488AA	145489AA	145461AA	46175AA
Hose used in all arrangements	318*4	250*20	250*37	250*38	250*25
Insulating coupling	153*264	153*267	153*265	153*266	153*782
Quick Release Valve	146506BR	146506BR	146506BR	N/A	N/A
Assembly with insulating coupling	146506BR	104909AA	104910AA	105519AA	07815AA
Assembly with insulating coupling and QRV	104908AB	104909AB	104910AB	105519AB	N/A
