Оборудование для домашней птицы 3000 кг малогабаритные бункеры грузоподъемностью 3 Тонны с автоматической линией подачи и питья

Оборудование для домашней птицы 3000 кг малогабаритные бункеры грузоподъемностью 3 Тонны с автоматической линией подачи и питья

Категория: Silos >>>
Поставщик: Qingzhou,Gongle,Electric,Fan,Co.,Ltd.

Цена:500,00 $ - 750,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-20-2025	595.0 $*	625.8 $*
Aug-20-2025	590.28 $*	620.5 $*
Jul-20-2025	495.58 $*	520.92 $*
Jun-20-2025	580.91 $*	609.53 $*
May-20-2025	505.44 $*	530.13 $*
Apr-20-2025	570.43 $*	599.31 $*
Mar-20-2025	565.47 $*	593.44 $*
Feb-20-2025	560.14 $*	588.3 $*
Jan-20-2025	555.57 $*	583.24 $*

Характеристики

Product Description

Poultry equipments 3000 kg small grain silos 3 ton capacity with poultry feeding and drinking line automatic for poultry shed

▶Gongle feed silo is made of 275g/ sqm hot dip galvanized sheet and all screws are made of 8.8 grade high-strength hot-dip galvanized bolts, which are corrosion resistant, anti-oxidation, high temperature resistance, high strength, long service life, and can withstand strong storm.

▶The feed silo is mainly composed of silo body, silo cover, mounting ladder, and silo legs etc. All parts are produced in strict accordance with drawing design by the advanced laser machine and precision molds, and then undergo strict quality inspections to
make each component more standard,more precise and more convenient to install to ensure easy assembly and use.

Specification

Capacity (T)	Capacity (CBM)	Diameter(mm)	Height (mm)	legs qty	legs height	layers
3	4.7	1860	4087	4	3370	1
4.5	7.3	1860	4977	4	3370	2
6.1	9.4	1860	5867	4	3370	3
7.7	11.9	1860	6757	4	3370	4
7.2	11.1	2750	4985	6	4000	1
11	16.9	2750	5875	6	4000	2
14.1	21.7	2750	6765	6	4000	3
17.5	27	2750	7655	6	4000	4
15.5	23.9	3660	6046	8	4800	1
21.5	33.1	3660	6936	8	4800	2
27.5	42.4	3660	7526	8	4800	3
33.8	52	3660	8716	8	4800	4

1- Roof Top:

The roof is designed to stand up even in the harshest environment of extreme snow disaster with the echo of top and down part strong structure and connecting radial ribs which is Z interconnected again itself. Roof panels incorporate with ribs with over

and under lap profiles ensuring a precise fit.

2-Roof panel & cone plate

1)Special designed 40 degree root panel,with high efficiency and easy to full of feed.

2)Special designed cone plate panel can reduce feed piled up.

3- Body Steel Plate:

A commercial 275g/m2 double galvanized steel coating increases life and durability.450g/m2 and 600g/m2 coating available for customized orders. Each sidewall sheet is manufactured from high-tensile steel that has the ability to overcome extreme power,pressure.

4-High strength bolts and screws:

Famtun’s high strength bolts paired with sealing washers, coated hardware provides added protection from rust to ensure your grain

bin stands the test of time.

5- Wide Flange H Beam Support Structure:

Wide flange H-Beam support structure has the strength and durability to support the heavy hopper silo loads long time, and with consideration of wind and seismic requirements.

The tape to avoid the leakage

Application

Packing & Delivery

1. Inner package is stretch film;
2. Outer package is corrugated paper cartons,Reinforced with strips.
3.Pallets
