Энергосберегающий комплект для дома сборный складной контейнер дом
- Категория: Prefabricated Buildings >>>
- Поставщик: Shandong,Shanghe,Economic,And,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 1190.15 $* | 1250.72 $* |
| Aug-20-2025 | 1180.6 $* | 1239.36 $* |
| Jul-20-2025 | 990.2 $* | 1040.70 $* |
| Jun-20-2025 | 1160.28 $* | 1218.65 $* |
| May-20-2025 | 1010.34 $* | 1061.61 $* |
| Apr-20-2025 | 1140.6 $* | 1197.69 $* |
| Mar-20-2025 | 1130.58 $* | 1187.55 $* |
| Feb-20-2025 | 1120.44 $* | 1176.15 $* |
| Jan-20-2025 | 1110.23 $* | 1166.55 $* |
Характеристики
Energy Saving House Kit Prefabricated Folding Container House Living Mobile Home
Product introduction
The foldable packaged box house is composed of top frame components, bottom frame components, corner columns and several interchangeable wall panels. Using modular design concept and production technology, a box room is modularized into standard parts, and then reused at the site of use. On-site assembly or hoisting can be done. The product takes the box as the basic unit. The box structure is made of special cold-formed galvanized steel components. The enclosure and insulation materials are all made of non-combustible materials. On-site assembly or overall hoisting and placement can be used for occupancy. It can be used alone, or through different combinations of horizontal and vertical directions to form a spacious use space and stacking.
Product Paramenters
Function series | folding dormitory | |
Frame size | 6-3-2.75M | |
Layout series | single room type | |
Frame color | white | |
Wall panel thickness | 75mm | |
Wall panel filling | glass wool | |
Iron sheet of wallboard | 0.3mm | |
Wallboard texture | smooth reinforcement | |
Wallboard color | gray | |
Floor material | glass magnesium plate 15mm | |
Floor color | gray,yellow, red | |
Floor thickness | 15mm | |
Door type | iron sheet anti-thsft door | |
The above parameters are factory default parameters, if you can not meet your needs, please contact customer service to customize products. | ||
Core material selection
Option Size | 20 feet, 40 feet, etc. We also have a special size of 2.9 meters high |
Main materials | Galvanized steel structure with sandwich panel walls, doors and windows, etc |
Weight | 1.8T |
Service life | 30-40 years |
Color | White, Blue, Green, Brown or Custom |
Columns | 3mm hot galvanized steel structure |
Wall | 50/75/100mm EPS/Rock woll/PU sandwich panel |
Door | Made of steel/aluminum frame,dimension W870*H2040mm,furnish with a handle lock with 3 keys,or sliding glass door W1500*2000mm. |
Window | Made of PVC/aluminum fame,dimension W930*H1100mm,glazed with double glass in a thickness of 5/8/5mm or custom |
Connection kits | PVC connection kit for ceiling, floor and walls |
Electricity | 3C/CE/CL/SAA Standard,with distribution box,lights,switch,sockets,etc. |
Optional Accessories | Furniture,sabnitary,kitchen,A/C,electrical appliance for accomodation,office,dormitory,toliet,kitchen,bathroom,shower,steel roof,cadding panels,decorative material,etc |
Advantage | (1) Fast installation: 2 hours/set, save labor cost; (2) Anti-rust: all material use hot glavanized steel; (3) Waterproof: without wood ceiling,wall; (4) Fireproof:Fire rating A grade (5) Simple foundation:just need 12pcs concrete bolck foundation; (6) Wind-resistant(11 level) and anti-seismic(9 grade) |
The wall panels of the prefabricated house are made of new building insulation materials polyurethane sandwich panels, rock wool sandwich panels, glass fiber sandwich panels and metal carved panels with customizable colors, which have excellent thermal insulation, fire prevention, sound insulation, and hurricane-proof effects. High-quality boards have an absolute advantage in the transportation process.
Advantages of Sandwich Panel
Polyurethane
Polyurethane sandwich panel has beautiful appearance and good overall effect. It integrates load bearing, heat preservation, fire prevention and waterproof, and does not require secondary decoration. It is quick and convenient to install, short construction period, good comprehensive benefits, and has good cost-effective advantages. It is a high-efficiency and energy-saving building envelope material with a wide range of uses and great potential, and it is also a new type of energy-saving panel that is worth advocating and promoting.
Rock Wool
Shanghe's new fire-proof rock wool sandwich panel is made of two layers of high-quality color coated steel plates or other precision-shaped metal plates. Vertical to the upper and lower layers of steel plates), high-strength, high-adhesion, and high-fire-proof adhesives are used to bond high-quality rock wool and metal panels to form a beautiful, flat, rigid and tough building board. The formed board has excellent fire protection, thermal insulation, environmental protection and other characteristics, providing an excellent choice for industrial building envelope systems.
Product Application
Wide range of applications
According to different needs, the packaged container house can be designed as various
functional units such as office, accommodation, lobby, toilet, kitchen, dining room, entertainment room, meeting room, clinic,
laundry room, storage room, command post, etc.
functional units such as office, accommodation, lobby, toilet, kitchen, dining room, entertainment room, meeting room, clinic,
laundry room, storage room, command post, etc.
Prefabricated box house is a modular building product based on steel frame and light wall panel structure system. This product adopts the proprietary third-generation packing box technology, which is composed of top frame, bottom frame, corner post and interchangeable wall panels. It can be packaged, easy to install, and convenient for land or sea transportation. It can be used as an office, accommodation, restaurant , sanitary ware and combined large space use, which can meet the needs of construction site barracks, field work barracks, municipal resettlement houses and various commercial houses. It is currently widely used in Europe, Africa, Southeast Asia, North America, South America and the Middle East and other regions .
Company Profile
Shandong Shanghe Economic and Trade Co., Ltd.
We are a powerful enterprise focusing on new thermal insulation composite materials, integrating the R&D and production of metal surface enclosure systems and the R&D and manufacturing of metal surface external wall thermal insulation systems. The energy-saving decoration integrated system integrates the functions of decoration, heat preservation, heat insulation, fire prevention and rainproof.
FAQ
Q: What kinds of wall panels are commonly used in your company?
A: The commonly used colors are off-white, red brick pattern, camouflage, mahogany pattern.
Q: What kinds of wallboard textures are commonly used in your company?
A: flat board, corrugated board, orange peel.
Q: What kinds of floors are commonly used in your company?
A: Commonly used floors include glass magnesium board, cement fiber board, bamboo plywood, steel anti-skid board, and the colors
are gray, yellow and red.
Q: What kinds of plastic floor designs and colors are commonly used in your company?
A: Marble gray, mahogany grain, etc., can also be customized according to requirements
Q: What kinds of folding roof structures are commonly used in your company?
A: According to the structure, it can be divided into steel-lined assembled roof (outer roof/skeleton x insulation layer/inner
roof), and non-steel-lined composite board roof (polystyrene or polyurethane composite board).
A: The commonly used colors are off-white, red brick pattern, camouflage, mahogany pattern.
Q: What kinds of wallboard textures are commonly used in your company?
A: flat board, corrugated board, orange peel.
Q: What kinds of floors are commonly used in your company?
A: Commonly used floors include glass magnesium board, cement fiber board, bamboo plywood, steel anti-skid board, and the colors
are gray, yellow and red.
Q: What kinds of plastic floor designs and colors are commonly used in your company?
A: Marble gray, mahogany grain, etc., can also be customized according to requirements
Q: What kinds of folding roof structures are commonly used in your company?
A: According to the structure, it can be divided into steel-lined assembled roof (outer roof/skeleton x insulation layer/inner
roof), and non-steel-lined composite board roof (polystyrene or polyurethane composite board).
