Подвижная Лебедка для крана

Категория: Winches >>>
Поставщик: Jining,Enwei,Intelligent,Technology,Co.,Ltd.

Цена:3 300,00 $ - 3 800,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-20-2025	3927.13 $*	4123.8 $*
Aug-20-2025	3894.81 $*	4089.18 $*
Jul-20-2025	3267.49 $*	3430.38 $*
Jun-20-2025	3828.28 $*	4019.70 $*
May-20-2025	3333.91 $*	3500.27 $*
Apr-20-2025	3762.30 $*	3950.96 $*
Mar-20-2025	3729.86 $*	3915.82 $*
Feb-20-2025	3696.38 $*	3881.66 $*
Jan-20-2025	3663.59 $*	3846.58 $*

Характеристики

Products Description

JTB mining hoisting winches are mainly used for lifting coal, ore and lowering equipment and materials in inclined roadways and small shafts of coal mines, metal mines and non-metal mines, and can also be used for other traction and transportation purposes. It is suitable for non-excavation working faces in coal mines. The winch is composed of a main shaft device, a mechanical speed regulating device, a working brake, a hydraulic safety brake, a base and an electric motor. It has the characteristics of good performance, safety and reliability, mechanical speed regulation, and double brakes.

JTK series mining hoisting winches are mainly used for lifting coal, ore and lowering equipment and materials in inclined roadways and small shafts of coal mines, metal mines and non-metal mines, and can also be used for other traction and transportation purposes. The winch is composed of a main shaft device, a coupling, a hydraulic emergency brake device, a safety brake device, a base, an electric motor, etc. It has the characteristics of good performance, safety and reliability, adjustable speed, and double brakes.

Product Parameters

Lifting winch
Model	JTKB-1.0×0.8W	JTK-0.8×0.6	JTK-1.0×0.8	JTK-1.2×1.0
Max. static tension of rope (KN)	22	15	19	18KN/26KN
Wire rope speed (m/s)	1.8	1.2	1.8	2.0
Wire rope diameter (mm)	16	12	12	14
Drum size (diameter *wide band) (mm)	1000*800	800*600	1000*800	1200*1000
Rope capacity (mm)	380	480	503	669
Min. breaking tension of wire rope (KN)	222	125	125	170
Motor Type	YB2250M-6 37KW 980r/min 380/660V	YRT250M1-8 22KW 730r/min 380V	YRT280M-8 37KW 730r/s 380V	YRT315-6 55KW/75KW 960r/min 380/V
Size (LWH) (mm)	2930×1690×1624	2208×1424×1220	2863×1715×1633	4549×3200×1954
Machine weight (kg)	3800	2000	3800	6400
