Индивидуальный высокомощный 2000 Вт импульсный источник питания 12 В 24 в 36 48 трансформатор

   Model

Specification

S-2000-12

S-2000-15

S-2000-24

S-2000-36

S-2000-48

DC Output voltage

12V

15V

24V

36V

48V

Output voltage range(Note:2)

±1%

±1%

±1%

±1%

±1%

Rated output current

130A

120A

83A

55.5A

42A

Output current range

0~130A

0~120A

0~83A

0~55.5A

0~42A

Wave and noise(Note:3)

200mVp-p

200mVp-p

200mVp-p

200mVp-p

200mVp-p

Inlet stability(Note:4)

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

Load stability(Note:5)

±0.5%

±0.5%

±0.5%

±0.5%

±0.5%

DC output power

1560W

1800W

2000W

2000W

2000W

Efficiency

84%

85%

85.5%

86.5%

87%

Adjustable range for DC voltage

0~12V

0~15V

0~24V

0~36V

0~48V

AC input voltage range

200~240VAC ( 100~130 VAC Customize)  47~63Hz,250~340VDC

Input current

18A/230V

AC Inrush current

50A/230V

Leakage current

<3.5mA/240VAC

Overload protection

105%-150% Type:Constant current mode, Reset: auto recovery

High-temperature protection

≥85℃ Cut off output(0~50℃)

Temperature coefficient

±0.03%/℃(0~50℃)

Setup, rise, hold up time

200ms, 50ms, 20ms:230VAC

Vibration

10~500Hz, 2G 10min,/1 cycle. Period for 60min,Each axes

Withstand voltage

I/P-O/P:1.5KVAC  I/P-FG:1.5KVAC  O/P-FG:0.5KVAC

Isolation resistance

I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC

Working temperature and humidity

-10℃~+60℃,10%~95%RH

Store temperature and humidity

-20℃~+85℃,10%~95%RH

Overall dimension

291X132X68mm (L*W*H)

Weight

2.7kgS

Note

1. The parameter under the testing condition:230vAC input ,rated load,25℃70% RH. Temperature.

2. Tolerance the setting tolerance, circuit stability and load stability.(Note:5).

3. Wave test: adopting "A12"double wire for 20MHz, and 0.1 UF&47UF capacitor short-circuit for interrupting.

4. Inlet voltage stability test : the lowest voltage will be up to the highest voltage when the circuit overload.

5. Load stability test: The load is from 0% to 100%.
