Заводская поставка оптимизатор солнечных батарей PV по низкой цене панелей с функцией быстрого
- Категория: Solar Related Products >>>
- Поставщик: Taizhou,Sungo,Power,Energy,Technology,Co.,ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 21.23 $* | 22.12 $* |
| Aug-16-2025 | 21.2 $* | 22.29 $* |
| Jul-16-2025 | 18.68 $* | 19.29 $* |
| Jun-16-2025 | 21.67 $* | 22.53 $* |
| May-16-2025 | 18.3 $* | 19.23 $* |
| Apr-16-2025 | 21.95 $* | 22.82 $* |
| Mar-16-2025 | 20.44 $* | 21.85 $* |
| Feb-16-2025 | 20.76 $* | 21.99 $* |
| Jan-16-2025 | 20.19 $* | 21.74 $* |
Характеристики
Hot sell
Products Description
▌Product specification
Power Optimizer | ||||||||
DC input | DC output | |||||||
Max input power | 600W | Max output current | 16A | |||||
Operation voltage range | 7 ~ 60V | Output voltage limit | 42V | |||||
MPPT voltage range | 7 ~ 60V | Max system voltage | 1500V | |||||
Max input current | 16A | 72-cell module in serial @1500V | 36 pcs | |||||
Over-current protection | 16A | 72-cell module in serial @1100V | 26 pcs | |||||
Over-temperature protection | 150°C | 72-cell module in serial @1000V | 24 pcs | |||||
Efficiency | General data | |||||||
Peak efficiency | 99.5% | Dimensions ( L*W*H ) | 103*105.3*21.3mm | |||||
Power loss @5A | 0.9W | Weight | 0.65Kg | |||||
Power loss @8A | 1.4W | Input/output cable length | 150/1050mm | |||||
Power loss @12A | 2.9W | Input/output cable size | 4mm²(12AWG) / 4mm²(12AWG) | |||||
Power loss @15A | 4.5W | Terminals | MC4(compatible) | |||||
Power loss @20A | 7.2W | Environmental Protection Rating | IP67/NEMA6 | |||||
Relative humidity | 0~100%RH | |||||||
Operating temperature range | -40~+65°C Natural cooling | |||||||
▌Product features
— Parallel arc and leakage detection, proactively protect and locate faults
— Module-level MPPT, 5~25% more power generation
— 25-year use life, as long as the use life of PV module
— For the PV power station which is in operation or under construction
— Easy to install
— For the PV power station which is in operation or under construction
— Easy to install
▌Product details
▌Applications
For a variety of complex application scenarios, the power generation of the components equipped with the optimizer increases by more than 30% compared to the normal components.
▌Installation instructions
6 steps 2 options, easy to install
Main Products
Company Profile
▌About us
Based on industry-leading technology, SUNGO is a professionalmanufacturer specialized in solar energy and battery industry with morethan 15 years experience. We provide a wide range products like: solarmodule, optimizer, inverter and portable power station, etc.
Sungo team helps residential and businesses reduce their electricity costsand achieve energy independence through their own power generation.storage, and optimization.
FAQ
1. Are you a factory or trading company ? |
We are a factory with our own R&D and technical team; MOQ is 20 PCS. |
2. How is the product shipped and what are the terms of payment? |
Each box contains 20 optimizers. Customers can use credit card, TT, Paypal and other methods of payment |
3. What does the PV optimizer do? Under what circumstances does it work ? |
Optimizer can improve the overall reduction in power generation caused by shadow occlusion, hidden component cracks, ash, accumulation, snow, etc., and solve inconsistent power generation problems for every solar module, effectively preventing the hot spot effect and reversing current damage to the component. When the affected PV module uses our SunGO-OPT 600W optimizer, its power generation efficiency will be improved by 5-30%. |
4. What brand of inverter can your optimizer fit? |
At present, our SUNGO-OPT 600W optimizer can be adapted to most inverters, except SolarEdge inverter (because some technical reasons, only their own brand products can match each other). |
5. I bought it myself and installed it on my PV system. What if I don't know how to use the optimizer? |
After you purchase the SUNGO optimizer, we will provide the user manual and installation guide video for you to refer to. |
6. Does the SUNGO PV optimizer come with monitoring? |
This SUNGO-OPT 600W has no monitoring function. Buyers can view the photovoltaic module's power generation directly through the inverter's monitoring program. |
