Взрывозащищенный кориолисовый расходомер часть кориолисового расходомера массы

Взрывозащищенный кориолисовый расходомер часть кориолисового расходомера массы

Категория: Flow Meters >>>
Поставщик: Q&,T,Instrument,Co.,Ltd.

Цена:580,00 $ - 599,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	690.85 $*	725.10 $*
Aug-17-2025	684.56 $*	718.98 $*
Jul-17-2025	574.13 $*	603.45 $*
Jun-17-2025	673.17 $*	707.71 $*
May-17-2025	586.33 $*	615.17 $*
Apr-17-2025	661.42 $*	694.46 $*
Mar-17-2025	655.52 $*	688.25 $*
Feb-17-2025	650.9 $*	683.58 $*
Jan-17-2025	644.81 $*	676.74 $*

Характеристики

Explosion Proof coriolis mass flow meter part corioliss mass flowmeter digital coriolis mass flow meter

Coriolis Mass (1)

Coriolis Mass (2)

Petroleum, such as crude oil, coal slurry, lubricant and other fuels

High viscosity materials, such as asphalt, heavy oil and grease

Suspended and solid particulate matter materials, such as cement slurry and lime slurry;

Easy-to-solidified materials, such as asphalt

Micro-flow measurements, such as fine chemical and pharmaceutical industries;

Coriolis Mass (3)

Coriolis Mass (4)

Coriolis Mass (5)

Coriolis Mass (6)

Independent of density changes, ability to measure undefined or

variable mixtures

Coriolis Mass (7)

Coriolis Mass (8)

Coriolis Mass (9)

SPECIFICATION

Flow accuracy	±0.2% Optional ±0.1%
Diameter	DN3~DN200mm
Flow repeatability	±0.1~0.2%
Density measuring	0.3~3.000g/cm³
Density accuracy	±0.002g/cm³
Temperature measuring range	-200~300℃ (Standard Model -50~200℃)
Temperature accuracy	+/-1℃
Output of current loop	4~20mA; Optional signal of flow rate/Density/Temperature
Output of frequency/pulse	0~10000HZ; Flow signal (Open collector)
Communication	RS485, MODBUS protocol
Power supply of transmitter	18~36VDC power≤7W or 85~265VDC power 10W
Protection class	IP67
Material	Measuring tube SS316L housing:SS304
Pressure rating	4.0Mpa (Standard pressure)
Explosion-proof	Exd(ia) IIC T6Gb
Enviroment Specifications
Ambient temperature	-20~-60℃
Enviroment humidity	≤90%RH

FLOW RANGE

Specification	DN (mm)	Flow range (kg/h)	Zero stability, kg/h			NW (kg)	GW (kg)
Specification	DN (mm)	Flow range (kg/h)	0.2%	0.15%	0.1%	NW (kg)	GW (kg)
QTCMF-003	3	0~96~120	0.018	0.012	0.012	8	19
QTCMF-006	6	0~540~660	0.099	0.066	0.066	12	22
QTCMF-008	8	0~960~1200	0.18	0.12	0.12	12	23
QTCMF-010	10	0~1500~1800	0.27	0.18	0.18	11	24
QTCMF-015	15	0~3000~4200	0.63	0.42	0.42	12	25
QTCMF-020	20	0~6000~7800	1.17	0.78	0.78	20	34
QTCMF-025	25	0~10200~13500	2.025	1.35	1.35	21	35
QTCMF-032	32	0~18000~24000	3.6	2.4	2.4	27	45
QTCMF-040	40	0~30000~36000	5.4	3.6	3.6	35	55
QTCMF-050	50	0~48000~60000	9	6	6	40	60
QTCMF-080	80	0~120000~160000	24	16	16	90	150
QTCMF-100	100	0~222000~270000	40.5	27	27	170	245
QTCMF-150	150	0~480000~600000	90	60	60	255	350

Coriolis Mass (10)

Coriolis Mass (11)

Coriolis Mass (12)

Coriolis Mass (13)

Coriolis Mass (14)

Coriolis Mass (15)
