Topcon GM52 36 часов Высококачественная Роботизированная

Topcon GM52 36 часов Высококачественная Роботизированная

Категория: Other Optics Instruments >>>
Поставщик: Shangrao,Haodi,Imp&Exp,Trading,Co.,Ltd.

Цена:3 750,00 $ - 3 850,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-19-2025	4463.20 $*	4686.7 $*
Aug-19-2025	4425.47 $*	4646.53 $*
Jul-19-2025	3713.21 $*	3899.96 $*
Jun-19-2025	4350.27 $*	4568.17 $*
May-19-2025	3788.81 $*	3977.65 $*
Apr-19-2025	4275.87 $*	4489.57 $*
Mar-19-2025	4238.24 $*	4450.25 $*
Feb-19-2025	4200.63 $*	4410.24 $*
Jan-19-2025	4163.64 $*	4371.57 $*

Характеристики

Company Information

reflectorless

elescope
Magnification / Resolving power	30x / 2.5"
Others	Length : 171mm (6.7in.), Objective aperture : 45mm (1.8in.) (48mm (1.9in.) for EDM), Image: Erect, Field of view: 1°30' (26m/1,000m), Minimum focus: 1.3m (4.3ft.) Reticle illumination: 5 brightness
Angle measurement
Minimum Display	1”/5” (0.0002 / 0.001gon, 0.005 / 0.02mil)
Accuracy (ISO 17123-3:2001)	2"
Dual-axis compensator /	Dual-axis liquid tilt sensor, working range: ±6'
Collimation compensation	On/Off (selectable)
Distance measurement
Laser output*1	Reflectorless mode : Class 3R / Prism/sheet mode : Class 1
Measuring range Reflectorless	0.3 to 500m (1,640ft.)
Measuring range Reflective sheet	RS90N-K: 1.3 to 500m (4.3 to 1,640ft.), RS50N-K: 1.3 to 300m (4.3 to 980ft.), RS10N-K: 1.3 to 100m (4.3 to 320ft.)
Mini prism	1.3 to 500m (4.3 to 1,640ft.)
One prism	1.3 to 4,000m (4.3 to 13,320ft)
Minimum Display	Fine / Coarse : 0.0001m (0.001ft. / 1/8 in.) / 0.001m (0.005ft. / 1/8 in.) (selectable) Coarse : 0.001m (0.005ft. / 1/8 in.) / 0.01m (0.02ft. / 1 in.)
Accuracy
Reflectorless	(2 + 2ppm x D) mm*
Reflective sheet	(2 + 2ppm x D) mm
Prism	(1.5 + 2ppm x D) mm
Fine	0.9s (initial 1.5s)
Coarse	0.6s (initial 1.3s)
Tracking	0.4s (initial 1.3s)
OS, Interface and Data management
Operating system	Linux
Display / Keyboard	Graphic LCD, 192 x 80 dots, backlight : on/off (Selectable) / Alphanumeric keyboard / 28 keys with backlight
Control panel location	On both faces
Internal memory	Approx. 50,000 points
Plug-in memory device	USB flash memory (max. 32GB)

Ultra-powerful advanced EDM	1000M non-prism range 6000M prism range
Easy Access USB2.0 memory	Up to 32GB storage Environmentally protected Compatible withindustry standard thumb driver
Advanced Angle encoder system	"best-in-class" 1'' angle accuracy Incorporates exclussive IACS
Rugged,waterproof design	Waterproof IP66 design Magenesium-alloy housing providing stable angle accuracy Graphic dispaly and alphanumetric key board
On-board TopBasic program	Run onboard basic layout and topo program with the gm sereis total station

Advanced Accuracy, Faster Workflows

This powerful, cost efficient Manual Total Station was designed from the ground up to deliver the latest technological advantages in a small, sleek design. It features an ultra-powerful EDM, best-in-class angle accuracy encoder system to provide the accuracy,speed, and endurance needed on the most demanding job sites. Plus, with a rugged housing and extended battery-life you’ll be able to handle even the toughest conditions.

The GM-100 series also features dual axis compensation, 32 GB USB, to 10m and TSshield™ telematics for ultimate security and investment protection.
