Автоматическая 4 вида цветов Slotter вырубных станков высокоскоростной принтер картонная слот высечки

Автоматическая 4 вида цветов Slotter вырубных станков высокоскоростной принтер картонная слот высечки

Цена:1 322 535,60 ₽*

Количество:

Automatic 4 Colors Slotter Die Cutting Machines High Speed Printer Cardboard Carton Slot Die Cut Machinery

1.It is suitable for single ,double ,or more layers corrugated carton producing

2.It can divide paper ,cut sides ,press mark at one time

3.The main wallboard adopts high quality Cast iron ,high precision processing

4.Drive roller adopts high quality 45#steel ,hard chromium plating and the surface treated by lapping finish

5.The blades are made in qingdao ,Bowl type design ,the blades are sharp and durable

Hand wheel ,turn the machine convenient ,can adjust size ,convenient and fast

6.The blades are made in qingdao ,adopt high quality steel material ,processed by

forging technology ,high frequency quenching ,Bowl type design ,the blades are sharp and durable

1	Color group	to be configured according to user’s needs
2	Printing paper	A,B,C,A/B,B/C and A/B/C type corrugated paperboard(the maximum interval 11mm)
3	Width of machine inside	2600mm	2800mm	3000mm
4	max.paper size	1200×2400mm	1400 ×2600mm	1600×2800mm
5	Max.printing size	1200×2300mm	1400 ×2500mm	1600×2600mm
6	Skip feeding paper	1400×2400mm	1600 ×2600	1800×2800
7	positive knife Min.paper size negative knife	350×720mm 350×740mm	400 ×720mm 400 ×740mm	450 ×720mm 450 ×740mm
8	Printing plate thickness	7.2mm	7.2mm	7.2mm
9	Design speed(piece/min)	180pcs/min	150pcs/min	150pcs/min
10	Economic speed(piece/min)	80-160pcs/min	80-130pcs/min	80-100pcs/min
11	Tinted precision	4( color) ±0.5mm	4( color) ±0.5mm	4( color) ±0.5mm
12	Slotting precision	±1.5mm	±1.5mm	±1.5mm
13	Max.slotting depth	7×300mm	7×350mm	7×400mm
13	Max.slotting depth	increase the blade, increase the slot depth
14	positive knife Min. Slot distance negative knife	170×170×170×170mm 280×80×280×80mm	170×170×170×170mm 280×80×280×80mm	170×170×170×170mm 260×90×280×80mm
15	Max.die-cutting size	1200×2300mmmm	1400×2500mm	1600×2700mm
16	Printing plate diameter(contain plate thickness)	405mm	480mm	530mm
