Ультракомпактный GPS-трекер печатная плата ZX310 GSM GPRS sim-карта Wi-Fi LBS чип отслеживания совместимый с nano

Описание и отзывы

Трекер стоимости

Характеристики

Main specification:

You Can Track The Devices Via Phone/PC
1.Topin official service free tracking platform: www.365gps.net
2.Android/IOS application: 365gps/GPS365
3.Login ID: IMEI number, Default Password: the last 6 digits of the IMEI number



CPU	2503D Assisted Chip: 3333 5931
ROM	32MB
RFPA	6625E
Size	19.8*12.5*3.5mm
Working Temperature	-20°C - 70°C
Network	GSM850/900/1800/1900MHz, working with GPRS 12
GSM Antenna	PIFA Antenna
SIM slot	Support NANO sim card or eSIM
Track	The user's specific location can be inquired through the cell phone APP or PC Web
Fence	Designate an area on the map by setting the device as the center point and the alarm will be triggered off immediately once the user of the device goes into or out of this area
PlayBack	Inquire the moving routes of the device during a certian period
GPSPositioning Accuracy	Within 10 meters outdoor
WIFI Positioning Accuracy	Within 50Metres
GSM Positioning Accuracy	Above 100 Metres (Depending on the network)
Battery	It can work with any capacity DC 3.7V rechargeable battery, mobile phone battery or power bank 18650 battery are preferred
Charging port	Android USB port
Charging Current:	DC 5V/0.5A-1A(depend on your devices)
MIC	No



Attention:
1: This modelcan only work with 2G GSM network(GSM 850/900/1800/1900,support Nano sim card), make sure the GPRS network is available,please confirm your network with your local telecom operators.
2: Before your large scale quantity orders, we kindly suggest testing our samples in advance.
3: We offer free apps for our users for all our GPS/LBS tracker products.
4: For your own server, we are able to help you to transfer the communication protocol.
5: We are able to offer any necessary firmware & software technical assistance.

Note:
Our GPS tracker & PCB technology is upgrading day by day, for one certain model, the new version may be have a bit appearance difference from the old versions, we will send you the latest version to our customers for better user experience.
