Одиночный компактный блок предохранителей MRBF для судового аккумуляторного
- Категория: Fuses >>>
- Поставщик: Dongguan,Yigao,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 2.63 $* | 2.97 $* |
| Aug-17-2025 | 2.55 $* | 2.13 $* |
| Jul-17-2025 | 2.98 $* | 2.59 $* |
| Jun-17-2025 | 2.80 $* | 2.52 $* |
| May-17-2025 | 2.83 $* | 2.93 $* |
| Apr-17-2025 | 2.45 $* | 2.28 $* |
| Mar-17-2025 | 2.22 $* | 2.20 $* |
| Feb-17-2025 | 2.20 $* | 2.7 $* |
| Jan-17-2025 | 2.62 $* | 2.43 $* |
Характеристики
Product Description
58V 50A 75A 125A 150A 200A 300A 400A 500A 5/16" M8 BUSS Battery Fuse With Fuse Holder Marine Rated Battery Fuse Block
The Parameters of 58V 50A 75A 125A 150A 200A 300A 400A 500A 5/16" M8 BUSS Battery Fuse With Fuse Holder Marine Rated Battery Fuse Block
Product Name | 58V 50A 75A 125A 150A 200A 300A 400A 500A 5/16" M8 BUSS Battery Fuse With Fuse Holder Marine Rated Battery Fuse Block | ||||||
Rating Current | 30A 40A 50A 60A 70A 80A 100A 120A 150A 200A 300A 400A 500A | ||||||
Rating Voltage | 58V DC | ||||||
Base | ThermopIastic | ||||||
Housing | Plastic | ||||||
Insulated Material | Ceramic | ||||||
Stud | Stainless Steel | ||||||
Screw | Steel, Zinc PlaCopper Alloy | ||||||
Melting Element | Copper Alloy | ||||||
Application | Automotive, Marine, RV, Yacht, etc | ||||||
Description of 58V 50A 75A 125A 150A 200A 300A 400A 500A 5/16" M8 BUSS Battery Fuse With Fuse Holder Marine Rated Battery Fuse
Block
Marine-grade, ignition-protected fuse blocks accommodate high amperage MRBF fuses. Suitable for protecting DC main, inverter,
windlass, and bow thruster circuits. Mounts on a 3/8" battery post, battery switch or busbar, allowing for easy installation in
tight space constraints and satisfies circuit protection rule. Includes insulating cap to prevent accidental shorts.
Surface mount fuse blocks accommodate 1 MRBF fuses, for consolidated high amperage circuit protection. Utilizes marine-grade
stainless steel and UV-stabilized plastics, and are ignition protected. Clip-on cover insulates terminal connections and includes
label recesses for easy circuit identification.
Features of Single Compact Mount MRBF Terminal Fuse Block for Marine Rated Battery Fuse
Marine-grade, ignition-protected fuse blocks accommodate high amperage MRBF fuses. Suitable for protecting DC main, inverter,
windlass, and bow thruster circuits. Mounts on a 3/8" battery post, battery switch or busbar, allowing for easy installation in
tight space constraints and satisfies circuit protection rule. Includes insulating cap to prevent accidental shorts.
Surface mount fuse blocks accommodate 1 MRBF fuses, for consolidated high amperage circuit protection. Utilizes marine-grade
stainless steel and UV-stabilized plastics, and are ignition protected. Clip-on cover insulates terminal connections and includes
label recesses for easy circuit identification.
Features of Single Compact Mount MRBF Terminal Fuse Block for Marine Rated Battery Fuse
•CIRCUIT PROTECTION: This high-amp fuse block kit is suitable for main and auxiliary circuit protection such as alternator
outputs, starter motor inputs and accessory circuits. Appropriate for DC Main, inverters, windlass, and bow thruster, it can bring
full range circuit protection for automotive and marine applications, free from worrying about circuit burnout or even fire.
•TERMINAL FUSES BLOCK KIT: Max voltage rating of fuse: 58V; Amperage Rating of fuse holder: 200A; Fuses Holder Stud Size: M8
(5/16"); Fuse Holder Mounting Hole: M10 (3/8"). Fuses are REPLACEABLE and allow tacking of terminals-- Easy to use, multifaceted
to meet your needs.
•COMPACT & SIMPLE: The specially compact designed makes this fuse block kit perfect for any tight space, and easy to install to
provide high current protection for the tightest space constraints. Installed directly on the battery, alleviating having to make
up a short wire to connect to a standard fuse block to the battery, and maintaining the integrity of the cable.
•WEATHERPROOF: IP66, designed for the harshest environment to protect against powerful water jets, suitable for small open cockpit
boats and other harsh environments. The insulating cap can also prevent accidental short circuits, ensuring safety.
•IGNITION PROTECTED: 10,000 AIC at 14V DC satisfies ABYC requirements for DC Main circuit protection on large battery banks.
Ignition protected, safe for installation aboard gasoline powered boats.
The Details of Compact Marine Rated Battery Terminal Fuses 58V DC Maximum IP66 for Boat Solar
outputs, starter motor inputs and accessory circuits. Appropriate for DC Main, inverters, windlass, and bow thruster, it can bring
full range circuit protection for automotive and marine applications, free from worrying about circuit burnout or even fire.
•TERMINAL FUSES BLOCK KIT: Max voltage rating of fuse: 58V; Amperage Rating of fuse holder: 200A; Fuses Holder Stud Size: M8
(5/16"); Fuse Holder Mounting Hole: M10 (3/8"). Fuses are REPLACEABLE and allow tacking of terminals-- Easy to use, multifaceted
to meet your needs.
•COMPACT & SIMPLE: The specially compact designed makes this fuse block kit perfect for any tight space, and easy to install to
provide high current protection for the tightest space constraints. Installed directly on the battery, alleviating having to make
up a short wire to connect to a standard fuse block to the battery, and maintaining the integrity of the cable.
•WEATHERPROOF: IP66, designed for the harshest environment to protect against powerful water jets, suitable for small open cockpit
boats and other harsh environments. The insulating cap can also prevent accidental short circuits, ensuring safety.
•IGNITION PROTECTED: 10,000 AIC at 14V DC satisfies ABYC requirements for DC Main circuit protection on large battery banks.
Ignition protected, safe for installation aboard gasoline powered boats.
The Details of Compact Marine Rated Battery Terminal Fuses 58V DC Maximum IP66 for Boat Solar
Application of Single Compact Mount MRBF Terminal Fuse Block for Marine Rated Battery Fuse
Full range circuit protection for automotive and marine applications. The breaking capacity meets the requirements of conventional
vehicle batteries and 12V, 24V and 42V electrical networks. Compact, high-amp fuse appropriate for DC Main, inverters, windlass,
and bow thruster circuit protection. Provides high current protection in tight space constraints. Ignition protected when used
with MRBF Terminal Fuse Blocks. Isolated stud design uses standard M8 hardware and permits stacking of terminals.
vehicle batteries and 12V, 24V and 42V electrical networks. Compact, high-amp fuse appropriate for DC Main, inverters, windlass,
and bow thruster circuit protection. Provides high current protection in tight space constraints. Ignition protected when used
with MRBF Terminal Fuse Blocks. Isolated stud design uses standard M8 hardware and permits stacking of terminals.
Name | Battery Auto Fuse/Fuse Holder | ||||||
Rating | 30A-500A/580VDC | ||||||
Base | Thermomplastic PPS UL94-V0, Color: Black | ||||||
Screw | Steel (Zinc Plated), Self-locking | ||||||
Stud | Stainless Steel | ||||||
Cover | Plastic; Color: Red | ||||||
Insulated Material | Ceramic | ||||||
Melting Element | Copper Alloy (Nickel Plated) Color: Silver | ||||||
Housing | Plastic Color: Transparent | ||||||
Breakiing Capacity | 2000A, 58VDC | ||||||
Maxium Torque | 12N.m (122 4Kgf-cm) | ||||||
High Carrying Capacity
Exquisite manufacturing technology， professional productiontechnology，excellent selection of materials, capable ofcarrying current range of 30A-500A, interruption levelmeets the requirements of large-scale battery pack DC main
circuit protection.
circuit protection.
Structure
This fuse and holder are safety devices for ignitionprotection,safe to use, small size, and can greatlysave installation space
Excellent Materials
The material of base is thermoplastic PPS.which is resistant to temperature andabrasion. The stainless steel material ofthe stud and screw has good electricalconductivity and strong oxidationresistance. The ceramic material of thefuse is resistant to high temperature. andthe copper nickel-plated melting elementisresistant to oxidation, and has goodelectrical and thermal conductivity.
Exquisite Design
The insulating cover can preventaccidental short circuits,dustproof, and reduce the impactof the environment on productperformance. The fuse provideshigh current protection under thenarrow space limitation, and canachieve ignition protection whenthe fuse and the holder are usedtogether.
Visible Window
The melting condition can beobserved / through the visible window, and each amperage will be clearly printed on the fuse.
Why choose us?
1. Quality assurance: All the products will go through lots of tests carefully before dispatch.
2. Competitive production capacity and fast shipping.
3. Manufacturer's price: Factory direct sale, most competitive price.
4. Small order acceptable.
FAQ:
Q1. What is your terms of packing?
A: Generally, we pack our goods in PE bag and brown carton.
Q2. What is your terms of payment?
A: T/T 50% deposit, and 50% balance before delivery.
Q3. What is your trade terms?
A: EXW, FOB, CIF, DDU, DDP, etc.
Q4. How about your delivery time?
A: Generally, it will take 3-7 days after receiving your advance payment. The specific delivery time depends on the items and the
quantity of your order.
1. Quality assurance: All the products will go through lots of tests carefully before dispatch.
2. Competitive production capacity and fast shipping.
3. Manufacturer's price: Factory direct sale, most competitive price.
4. Small order acceptable.
FAQ:
Q1. What is your terms of packing?
A: Generally, we pack our goods in PE bag and brown carton.
Q2. What is your terms of payment?
A: T/T 50% deposit, and 50% balance before delivery.
Q3. What is your trade terms?
A: EXW, FOB, CIF, DDU, DDP, etc.
Q4. How about your delivery time?
A: Generally, it will take 3-7 days after receiving your advance payment. The specific delivery time depends on the items and the
quantity of your order.
