Алюминиевые трубки и фитинги pex-al-pex
US $49.50-$55.00
Двухуровневая водопроводная труба PEX Al Aenor CSTB
- Категория: Composite Pipes >>>
- Поставщик: Zhejiang,Mingshi,Xingxin,Hvac,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.97 $* | 0.26 $* |
| Aug-18-2025 | 0.96 $* | 0.57 $* |
| Jul-18-2025 | 0.72 $* | 0.67 $* |
| Jun-18-2025 | 0.6 $* | 0.49 $* |
| May-18-2025 | 0.73 $* | 0.20 $* |
| Apr-18-2025 | 0.51 $* | 0.5 $* |
| Mar-18-2025 | 0.67 $* | 0.35 $* |
| Feb-18-2025 | 0.33 $* | 0.65 $* |
| Jan-18-2025 | 0.65 $* | 0.59 $* |
Характеристики
Multilayer PEX-AL-PEX/ PERT-AL-PERT Pipe | ||
Warranty | More than 10 years | |
Certification | AENOR, WRAS, CSTB, ACS, WATERMARK, SKZ | |
Application | Water/ Gas/ Underfloor heating (UFH) | |
Customized support | OEM, ODM | |
Place of Origin | China, Zhejiang | |
Brand Name | OEM/MINGSHI/MSP | |
Model Number | S-1 | |
Standard | ISO 21003/ other | |
Welding types | Buttwelding/ Overlapped | |
OD (mm) | 15/ 16/ 18/ 20/ 22/ 25/ 26/ 28/ 32/ 40/50/63 | |
Colors | White/ Black/ Red/ Blue/ Yellow/ Orange | |
Working pressure | Max. 10 bars | |
Working temperature | Max. 95℃ | |
Crosslinking degree | ≥65 | |
1. For Plumbing water(cold & hot)/gas / underfloor heating systems, Composed of 5 layers:
-External Plastic/external Glue/Aluminum/internal Glue/internal Plastic
2. Certificates we have: AENOR, CSTB, SKZ, ACS, WATERMARK, JASWIC, ISO9001
3. Material: CONSTAB/ Other PEX
4. QC: Including materials checking and test, spot inspection on production lines, and all the tests required by each standard done on the finished products in our lab rooms
5. Overlapped/buttwelding
-Spec. (mm)
16*2.0
18*2.0
20*2.0
20*2.25
25*2.5
26*3.0
32*3.0
40*4.0
50*4.5
63*6.0
6. Lead time: 15-30days
7. Main makets: Europe, South Africa, South America, Asia, Australia
8. Applications:
-Cool & Hot Water Pipe System
-Housing Gas Pipe System
-Under floor heating System
-Solar Energy & Air-conditioning Matching Pipe System
-Medical, Foodstuff & Chemical Industry Pipe System
9. Characters & Advantages:
-Wide range working temperature(-10C~95C), Hi-pressure resistance
-30% more flow than metal pipe
-50 year working life
-Non-corrosive, scale-free
-Hygiene, no oxygen permeability, no growth of Microorganism
-Non-inflammable, non-static
-Easy bending but never spring back
-Light in weight, easy to carry and store
-Few pipe fitting applying leading to little leakage
-Economical price.
-External Plastic/external Glue/Aluminum/internal Glue/internal Plastic
2. Certificates we have: AENOR, CSTB, SKZ, ACS, WATERMARK, JASWIC, ISO9001
3. Material: CONSTAB/ Other PEX
4. QC: Including materials checking and test, spot inspection on production lines, and all the tests required by each standard done on the finished products in our lab rooms
5. Overlapped/buttwelding
-Spec. (mm)
16*2.0
18*2.0
20*2.0
20*2.25
25*2.5
26*3.0
32*3.0
40*4.0
50*4.5
63*6.0
6. Lead time: 15-30days
7. Main makets: Europe, South Africa, South America, Asia, Australia
8. Applications:
-Cool & Hot Water Pipe System
-Housing Gas Pipe System
-Under floor heating System
-Solar Energy & Air-conditioning Matching Pipe System
-Medical, Foodstuff & Chemical Industry Pipe System
9. Characters & Advantages:
-Wide range working temperature(-10C~95C), Hi-pressure resistance
-30% more flow than metal pipe
-50 year working life
-Non-corrosive, scale-free
-Hygiene, no oxygen permeability, no growth of Microorganism
-Non-inflammable, non-static
-Easy bending but never spring back
-Light in weight, easy to carry and store
-Few pipe fitting applying leading to little leakage
-Economical price.
Product details
Essential details | ||||||||
Place of Origin: | Zhejiang,China | Material: | Pex | |||||
Specification: | 16-63MM | Length: | 25/50/ 100/200/300/500 or OEM | |||||
Thickness: | 2.0, 2.5, 3.0, 4.0, 4.5, 6.0 | Standard: | AENOR,SKZ,WRAS,WATERMARK | |||||
Processing Service: | Cutting | Product name: | Pex-Al-Pex pipe | |||||
Application: | Gas system,Water system, Under floor heating. | Type: | Plastic Building Material | |||||
Raw Material: | Pex, Aluminum | Colors: | White,Red,Blue,Orange,Red or OEM | |||||
Logo: | Support custom logo | Features: | Corrosion Resistant,fire resistant,high pressure | |||||
MOQ: | 10000m | Shape: | Round | |||||
Advantage: | Flexible,easy to install | |||||||
Supply Ability | ||||||||
Supply Ability: | 3000000 Meters per month | 3000000 Meters per month | ||||||
Packing&Delivery | ||||||||
Packing Details: | With craft paper, then plastic film outside/Plastic bag | With craft paper, then plastic film outside/Plastic bag | ||||||
Port: | Ningbo or Shanghai | Ningbo or Shanghai | ||||||
International Standards | ||||||||
1 | EN ISO 21003 | Multilayer piping systems for hot and cold water installations inside buildings | ||||||
2 | AS 4176.2 & 3 | Multilayer piping systems for hot and cold water plumbing applications- PIPES & FITTINGS | ||||||
3 | ISO17484-2:2009 | Multilayer Plastics piping systems for indoor gas installations | ||||||
International Certificates | ||||||||
1 | AENOR | refers to EN ISO 21003 ，UNE-EN ISO 53007 | ||||||
2 | CSTB | refers to EN ISO 21003 | ||||||
3 | ACS | refers to XP P41-250 | ||||||
4 | Watermark | refers to AS 4176.2 & 3 | ||||||
5 | WRAS | refers to Regulators’ Specification | ||||||
6 | ISO 9001:2015 | Quality management system | ||||||
