Высококоррозионно-стойкая плетеная титановая проволочная сетка Gr5

Высококоррозионно-стойкая плетеная титановая проволочная сетка Gr5

Категория: Steel Wire Mesh >>>
Поставщик: Baoji,Hanz,Metal,Material,Co.,Ltd.

Цена:65,00 $ - 150,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-19-2025	83.44 $*	85.39 $*
Jul-19-2025	67.56 $*	68.32 $*
Jun-19-2025	81.41 $*	83.37 $*
May-19-2025	81.33 $*	83.13 $*
Apr-19-2025	64.20 $*	65.19 $*
Mar-19-2025	79.46 $*	81.75 $*
Feb-19-2025	79.47 $*	81.92 $*
Jan-19-2025	78.25 $*	80.40 $*

Характеристики

Product Description

Titanium wire mesh

Titanium woven wire mesh/Titanium Expanded Mesh is a kind of products with outstanding corrosion resistance, low density and nontoxic performance. In the corrosion environment, the surface of high purity titanium mesh will form an oxidation film layer to protect wire mesh from being corroded. The layer is compact and inert, which has strong resistance to the corrosion. It has
excellent corrosion resistant performance in below environment: Seawater, wet chlorine, chlorite and hypochlorite solution, nitric
acid, chromic acid, metal chlorides and organic salts.

Details Images

High corrosion resistance plain twill dutch weave gr2 titanium wire mesh in stock
Type	Wire diameter	OD0.1mm~OD6mm
	Substrate	Weaving method	Plain weave, twill weave, dense weave
		Mesh count	Plain weave up to 100 mesh Dutch weave up to 70*400 mesh
Surface	black titanium wire mesh or bright titanium wire mesh
Material	Gr1, Gr2, Gr5, Gr9 etc.
Product Features	1)Low density and high specific strength
		2)Excellent corrosion resistance, in the corrosion environment,
		3)it will form an oxidation film layer to protect wire msh from being corroded.
		4)Effectively production efficiency
		5)Strong corrosion resistance,long working life
Production time	15-20 days.Cause the longer production time, pls place order in advance.
Applications	Shipbuilding ,industry manufacturing , chemical filter , mechanical filter , desalination filter , high temperature vacuum equipment , and medicine filtration industries ect.

High corrosion resistance plain twill dutch weave gr2 titanium wire mesh in stock

Weaving method

High corrosion resistance plain twill dutch weave gr2 titanium wire mesh in stock

Product regular size

Mesh/inch	Wire Diameter (mm)	Aperture (mm)	Mesh/inch	Wire diameter (mm)	Aperture (mm)
2mesh	1.8	10.9		60mesh	0.15	0.273
3mesh	1.6	6.866		70mesh	0.14	0.223
4mesh	1.2	5.15		80mesh	0.12	0.198
5mesh	0.91	4.17		90mesh	0.11	0.172
6mesh	0.8	3.433		100mesh	0.1	0.154
8mesh	0.6	2.575		120mesh	0.08	0.132
10mesh	0.55	.99o		140mesh	0.07	0.111
12mesh	0.5	1.616		150mesh	0.065	0.104
14mesh	0.45	.362		160mesh	0.065	0.094
16mesh	0.4	1.188		180mesh	0.053	0.088
18mesh	0.35	.060		200mesh	0.053	0.074
20mesh	0.3	0.97		250mesh	0.04	0.061
26mesh	0.28	0.696		300mesh	0.035	0.049
30mesh	0.25	0.596		325mesh	0.03	0.048
40mesh	0.21	0.425		350mesh	0.03	0.042
50mesh	0.19	0.318		400mesh	0.025	0.0385

Our Advantages

Raw material

The raw materials are titanium wires that are rolled with sponge titanium and conform to ASTM B265. Ensure that the titanium content reaches more than 99.6%.

Production process

According to the knitting method and mesh number required by the customer, processing and tailoring are carried out. Ensure that it does not break during the weaving process.

Quality Inspection

Professional testing equipment, testing the information of the mesh number of the screen. Make sure that the specifications of the screen are not wrong.

Product packaging

1.Packaging

Packing Details : After being tested, qualified products will be packed with Pack OPP in carton box for collision prevention or we can according your specific needs.
Delivery Details : 3-15 working days after order
The package of titanium wire mesh is very professional, careful and safety.

2.Shipping

We will choose the fastest ,cheapest and safest shipment way for you, such as Express, air transportation and sea transportation.
Before delivery, the pictures of finished products ,packaging details and MTC will be send to our customer, When the customer satisfied with our product.
We will promptly deliver goods. There is no deception, the pictures you see are consistent with the goods you receive.

Company Profile

Baoji Hanz Advantage

High corrosion resistance plain twill dutch weave gr2 titanium wire mesh in stock

* 1. Ability to customize;
* 2. Has items in stock;
* 3. Short lead time;
* 4. Exported to many counrises before;
* 5. Has a factory.

High corrosion resistance plain twill dutch weave gr2 titanium wire mesh in stock

Baoji Hanz Metal Material Co., Ltd located in Baoji, China.With high preciously equipment and rich experience, our company specilizes in manufacturing all shapes of titanium, tungsten, aluminum, stainless steel products and other alloy.

Other info

Our Service
* 1. Competitive price.
* 2. Our strengths over other suppliers.
* 3. Reliable quality on the base of the same price.
* 4. 100% Timely delivery as your as your requirements.
* 5. Professional service to cut much purchasing costs down.
* 6. We offer discount for old customers.
* 7. We do our best to meet the requirements of customers.
* 8. Faced with problems related with products, please feel free to contact us.
We will try our best to help you.
High corrosion resistance plain twill dutch weave gr2 titanium wire mesh in stock
FAQ
1: I want to buy titanium wire mesh. What is the price?
A: Titanium wire mesh is a conventional product, you need to tell us the mesh, quantity, surface, and we can quote for you.
2: What is the MOQ ?
A:When size is stocked, we can supply 1 ㎡, if size not stock, MOQ should be 30 ㎡.
3.Do you accept customed?
Yes, we can according to your application or drawings processing.
4.What's your shipment term?
DHL, UPS, TNT, FedEx, SF-Express, Deppon, EMS, 5-8 days will arrived.
5.What is the shipping cost?
It mainly depends on weight, volume, packing size and destination port.

High corrosion resistance plain twill dutch weave gr2 titanium wire mesh in stock
Payment terms
* Sample order: west-union, Paypal, Escrow and T/T 100% are accepted.
* Big order: T/T100%, full payment advanced, L/C are accepted.

Customer Reviews

Recommend Products

Titanium plate

Titanium mesh plate

Titanium wire

If you have any interested in our products, contact us freely by click the left bottom,
We also can supply MMO flexible anodes, filament anodes for cathodic protection, tubular anodes, mesh anodes and so on.
Send us your dimensions, requirements, quantity, application and drawings, we will reply within 24 hours.
