AT50C1500L-25 перечисленных 50 Вт Светодиодный драйвер с 1500ma Выход постоянного тока Ассоциацией по техническому надзору (TUV

input voltage:

90-264VAC/50HZ

output current:

1450ma ~ 1500MA

output voltage:

22-36V (can adjust automaticly )

output power:

50W led driver

power factor:

≥0.95 full load

effeciency:

>85%

drive mode:

Isolation led driver

Technology:

high PFC,constant current, led dirver

current accuracy:

350mA ≤±3%(can do customized )

Temperature rise:

10~15 degree

certificate:

CE,ROHS,GS,UL

protection:

overload protection ,short circuit protection,over current ,over voltage protection , over temperature protection , can recovery when remove

working temperature:

30°~ +60°C

storage temperature:

40°~ +85°C

Hnmidity:

5% ~ 95%RH

Cooling method:

Nature cool

vibration resistance:

5 ~ 55HZ/2g 30 mins

impact resistance:

1g/S

MTBF

50,000 hours with full load condition

Safty:

EN55015/ CLASS B , *EN61000-4-2, EN61000-4-4, EN61000-4-5, EN61000-3-2 , IEC/ EN60968-1:2004+A1:2006 , IEC/EN60968-2-1:1989, led driver standard
