Шикарная новая модель 10 м 72 пассажира бортовой мониторинг Автоматический Огнетушитель новый электрический городской

Шикарная новая модель 10 м 72 пассажира бортовой мониторинг Автоматический Огнетушитель новый электрический городской

Категория: City Buses >>>
Поставщик: Dongfeng,Huashen,Special,Vehicle,Co.,Ltd.

Цена:100 000,00 $ - 200 000,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	119000.6 $*	124950.89 $*
Aug-16-2025	118000.84 $*	123900.95 $*
Jul-16-2025	99000.69 $*	103950.86 $*
Jun-16-2025	116000.45 $*	121800.78 $*
May-16-2025	101000.40 $*	106050.57 $*
Apr-16-2025	114000.39 $*	119700.32 $*
Mar-16-2025	113000.59 $*	118650.49 $*
Feb-16-2025	112000.85 $*	117600.87 $*
Jan-16-2025	111000.62 $*	116550.34 $*

Характеристики

PRODUCT OVERVIEW

Dongfeng Luxury New Model 10m 72 Passengers on-board monitoring Automatic extinguisher New Energy Electric City Bus

PRODUCT SPECIFICATIONS

Dimension	L× W× H（mm）	10480×2500×3040,3170
		Wheelbase（mm）	5000
		Tread F/R（mm）	2100/1860
		F/R overhang（mm）	2680/3320
weight	curb weight（kg）	10650/10950
		G.V.W（kg）	16500
		seats/passengers	72/10-38
performance	Max. speed（km/h）	69
		Max. grade ability (%)	17%
		Min. turning diameter(m)	24
		Approach/departure angle	8/7°
		Drive range	300km
front axle	Dongfeng Dana axle, Max load capacity:5500Kg Self-adjusting clearance, with ABS
Rear axle	Dongfeng Dana bridge, maximum load mass: 11000Kg; main reduction ratio: 6.14, clearance self-adjustment, with ABS
Suspension	air suspension front 2 / rear 4 as optional
Steering	Electro-hydraulic power steering
Brake	Front disc/rear disc brake，duel-circuit air brake , Parking brake function on rear wheel
tire	295/80R22.5-18PR
Drive motor	rated power/peak power（Kw）	135/196
		rated torque/ peak torque（N.m）	1520/2800
		protection level	IP67
Motor controller	rated voltage（Vdc）	DC 576
Motor controller		rated/peak capacity（kVA）	147/213
power battery	battery brand and type	CATL LFP
		battery pack power capacity（Ah）	456
		battery pack rated voltage（Vdc）	560.28
		total battery power capacity	255.5kWh

MORE DETAILS

COMPANY PROFILE

Dongfeng Huashen Special Vehicle Co., Ltd. is mainly engaged in the research and development of engineering dump trucks, environmental protection muck trucks, various types of vans (composite panel vans, iron corrugated vans), refrigerated trucks, truck-mounted cranes, military off-road trailers and other series of special vehicles, Production and sales, with an annual production capacity of 15,000 vehicles. The company is located in Shiyan Industrial New Zone, Hubei Province, covering an area of 290 acres, with a construction area of 62,000 square meters, a total investment of 210 million yuan, and more than 200 employees . Committed to building a leader in the domestic dump and van special-purpose vehicle industry.

OUR FACTORY

PRODUCT PACKAGING

FAQ

Q1. How to purchase the truck from our company?

A1: You can choose the model from our website. Also, you can tell our sales manger your specific requirements and we will recommend the suitable model to you. After you confirm the model and price, we can sign the contract.

Q2. How to ensure product quality?
A2: Firstly, we passed the international quality system certification. Secondly, Alibaba Group has conducted field certification for our factory. Finally, you can entrust third party individuals or organizations to inspect our products before delivery.

Q3. Can you offer customized service?
A3: Yes, we can produce according to your samples or technical datas. We can build the molds and fixtures.

Q4.What is the warranty term?
A4: We can supply you with original parts. And we can provide phone or email support. If necessary, our experienced engineers can go abroad to provide technical support to your company.

Q5. How to visit our factory?
A5: After you arrive in China, you can fly to Shiyan Wudangshan Airport located in Shiyan City, Hubei Province. Our driver will meet you at the airport and take you to our city by car.
