Компании daheng MER2-630-60U3M/C-L 6.3MP
- Категория: Optical Instruments >>>
- Поставщик: Shenzhen,Zhixiang,Shijue,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-19-2025 | 220.80 $* | 224.34 $* |
| Jul-19-2025 | 178.19 $* | 182.80 $* |
| Jun-19-2025 | 216.43 $* | 220.31 $* |
| May-19-2025 | 215.1 $* | 219.88 $* |
| Apr-19-2025 | 171.47 $* | 174.35 $* |
| Mar-19-2025 | 211.45 $* | 215.71 $* |
| Feb-19-2025 | 209.2 $* | 213.43 $* |
| Jan-19-2025 | 208.16 $* | 212.61 $* |
Характеристики
Product Features
1：USB3.0 interface
2：6.3 megapixel, 1/1.8" line exposure CMOS sensor
3：Compact, compact, lightweight and rugged
4：GenICam ™ and USB3 Vision® compatible
5：Competitively priced
2：6.3 megapixel, 1/1.8" line exposure CMOS sensor
3：Compact, compact, lightweight and rugged
4：GenICam ™ and USB3 Vision® compatible
5：Competitively priced
Products Description
Spectral Response
Specifications
Model | MER2-630-60U3M-L | MER2-630-60U3C-L | |
Brand | DAHENG Image | ||
Resolution | 3088×2064 | ||
Frame rate (fps) | 60 | ||
Sensor Manufacturer | Sony | ||
Sensor | 1/1.8" IMX178 Rolling Shutter CMOS | ||
Image size | 2.4μm | ||
Pixel depth | 8 bit，10 bit | ||
Data interface | USB3 | ||
Lens interface | C, CS | ||
Spectrum | Black and white | Color | |
Image data format | Mono8，Mono10 | Bayer RG8，Bayer RG10 | |
Signal to noise ratio | 40.18 dB | 40.19 dB | |
Power supply requirements | 5 VDC | ||
Power rating | < 2.7 W @ 5 VDC | ||
Operating temperature | 0°C ~ +45°C | ||
Storage temperature | -20°C ~ +70°C | ||
Operating Humidity | 10% ~ 80% | ||
Mechanical dimensions (W x H x L) | 29 mm × 29 mm × 29 mm (excluding C connector length) | ||
Weight | 61 g | ||
Certifications and standards | CE，RoHS，FCC，USB3 Vision，GenICam | ||
