Высокое качество 19 дюймов 2U стойки регистрации беспроводной конденсаторный микрофон конференц-системы для большой
- Категория: Conference System >>>
- Поставщик: Nanning,Hesheng,Sound,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 3994.54 $* | 4194.54 $* |
| Aug-19-2025 | 3960.52 $* | 4158.91 $* |
| Jul-19-2025 | 3322.97 $* | 3488.8 $* |
| Jun-19-2025 | 3893.33 $* | 4088.86 $* |
| May-19-2025 | 3390.62 $* | 3560.7 $* |
| Apr-19-2025 | 3826.60 $* | 4017.87 $* |
| Mar-19-2025 | 3792.95 $* | 3982.89 $* |
| Feb-19-2025 | 3759.18 $* | 3947.45 $* |
| Jan-19-2025 | 3725.69 $* | 3911.81 $* |
Характеристики
Product Description
Product Name | DG-S200 Wired Conference System | |
Applicable Scene | Conference rooms for enterprises, institutions, government agencies | |
Packaging 1 (L*W*H) | 528mm*333mm*185mm (20.79*13.12*7.29inches) | |
Packaging 2 (L*W*H) | 247mm*203mm*137mm (9.73*8.01*5.41inches) | |
Specification | ||
Control Unit (CU) Parameters | ||
Power Supply | DC 12V/1A | |
Frequency | call frequency: 640-692MHz, scheduling frequency: 315-316MHz | |
Receiving Sensitivity | -105dBm | |
S/N Ratio | > 80dB | |
THD | < 0.5%dB ＠ 1KHz | |
Effective Range | ≥ 30m (in open area) | |
Number of Discussion Channels | 4 X 83 | |
Network Communication Protocol | UDP | |
Camera Control Mode | RS-485, 9600 baud | |
Power Consumption | 6W | |
Product Dimensions | 430mm×100mm×220mm (16.93*3.94*8.67inches) | |
Net Weight | about 3.5Kg | |
Discussion Unit Parameters | ||
Power Supply | DC 3V, AA 1.5V*2 | |
Transmit Power(antenna port) | ≥ 10mW | |
Mic Capsule | condenser, unidirectional | |
Continuous Use Time: | 8 hours (subjectto battery capacity) | |
only one DG-U100T1 Chair Unit and one DG-U100T1 Delegate Unit in a set of products. If you need more DG-U100T1 or DG-U100T1, Please contact our store. | ||
Features of Control Unit
• Connects up to 83 mic units within signal coverage, allowing simultaneous speech from 1~4 persons
• Real-time tracking of speakers by connecting to cameras; controls up to 7 cameras atthe same time
• Supports multiple PTZ camera control protocols such as Sony Visca, Pelco-P and Pelco-D
• Smart LAN control software for managing all units in one integrated interface, easy to deploy
• Infrared sync for greater ease on setting up conference
• Built-in 15-band EQ for each channel, adjustable as required
• Remote gain control on discussion units, catering to different speakerrequirements
• SUBG band data scheduling technology, wireless digital audio/control signal processing, farther transmission and better
anti-interference
• Intelligent power management lowers battery consumption by auto shutdown of discussion units when control unitis powered off
• Remote frequency changer allows synchronizing frequency changes remotely between control unit and discussion units
• Supports two discussion modes: FIFO (First-in-First-out) or No-Delegate mode
• XLR/TRS/TRS-Isolated outputs for connection with various audio equipment
• 2U rack unit size installs into a standard 19" rack mount
Features of Discussion Units
• 12864 pixel matrix screen, with clear and intuitive indication of device status
• Discussion unit priority is set freely via lR Sync; no more physical distinction among chairman/guest/delegate units
• Condenser capsule offers high fidelity, long pickup distance, high sensitivity, low distortion and clear sound
• Chairman units are prioritized, unrestricted and able to interrupt speech of delegate units
• Guest unitscan speak independently, uninterrupted by chairman units or FIFO rules
• Delegate units are controlled by chairman units for conference management
• Delegate units display the speaking duration which serves as reference for speech speed adjustment
• Built-in antennas, elegant in looks, also provide strong stability and anti-interference
• Adjustable gain for each discussion unit, configurable on controlunit, adaptable to various speakers
Recommend Products
Product Content
Quantity | Control Unit Configuration |
1 PC | Control Unit |
4 PCS | Antenna (640~69OMHz) |
1 PC | 315 Antenna |
2 PCS | Corner Steel |
4 PCS | Extension Suction Cup Antenna |
1 PC | Power Adapter |
1 PC | User Manual |
Quantity | Discussion Unit Configuration |
1 PC | DG-U100T1 Mic Base |
1 PC | DG-U10OT2 Mic Base |
1 PC | U1 Pluggable Gooseneck Mic |
1 PC | U2 Pluggable Square Tube Mic |
