Умный сетевой коммутатор CCTV 48 В PoE Ai 4 порта 10/100 Мбит/с широкополосный
- Категория: >>>
- Поставщик: Shenzhen,Sunsoont,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.77 $* | 0.79 $* |
| Aug-18-2025 | 0.34 $* | 0.48 $* |
| Jul-18-2025 | 0.60 $* | 0.16 $* |
| Jun-18-2025 | 0.89 $* | 0.94 $* |
| May-18-2025 | 0.4 $* | 0.37 $* |
| Apr-18-2025 | 0.9 $* | 0.47 $* |
| Mar-18-2025 | 0.3 $* | 0.89 $* |
| Feb-18-2025 | 0.13 $* | 0.95 $* |
| Jan-18-2025 | 0.12 $* | 0.13 $* |
Характеристики
Product Description
CCTV 48V PoE Ai smart network switch hub 4 port 10/100mbps broadband 10/100mbps ethernet switch
The PoE switch provides power and data from a single point, using Power over Ethernet (PoE) over a single Cat-5 cable. It can be used for any 10/100Mbps or 10/100/1000Mbps link and supply industry-standard IEEE 802.3af power. Advanced auto-sensing algorithm gives power to 802.3af end devices, In addition, the PoE switch automatically determines PoE requirements, speed, duplex, and cable type using Auto Uplink. Easy to operate and reliable.
The PoE switch is ideal for powering PoE devices such as IP cameras, WLAN access point, IP phones, office access control systems, and other PD devices and offers a line of high quality products that provide a total solution for Ethernet application in different environments.
The PoE switch is ideal for powering PoE devices such as IP cameras, WLAN access point, IP phones, office access control systems, and other PD devices and offers a line of high quality products that provide a total solution for Ethernet application in different environments.
POE Switch Features
◆ 4*100mbps RJ45 POE port,UP-Link 1*1000m RJ45 port
◆ 100m Transmission Distance,1-8 port support VLAN mode
◆ Compatible with IEEE802.3AF/AT
◆ Whole Power:48W (52V 2.3A) Full duplex
◆ All port supported by MDI/MDIX auto flip and self negotiation
◆ Supply 4*10/100Mbps adaptive high speed forwarding data packet non-lost port.
◆ Each port max. power supply reached 30W.
◆ Low heat design, safe and reliable, high stability
◆Application: Wireless Access Point, IP Camera, IP Phone, Computer Networks.
◆ 100m Transmission Distance,1-8 port support VLAN mode
◆ Compatible with IEEE802.3AF/AT
◆ Whole Power:48W (52V 2.3A) Full duplex
◆ All port supported by MDI/MDIX auto flip and self negotiation
◆ Supply 4*10/100Mbps adaptive high speed forwarding data packet non-lost port.
◆ Each port max. power supply reached 30W.
◆ Low heat design, safe and reliable, high stability
◆Application: Wireless Access Point, IP Camera, IP Phone, Computer Networks.
Specification
Product Name | 5 Port 10/100Mbps POE Switch | |
Product Model | SST-DP4EH1EH | |
DATA PIN | 1/2+ 3/6- ,4/5+ 7/8- | |
Power Supply Type | Build In, 1/2+,3/6- | |
PoE Output Power | 15.4W/30W | |
Connector | 4*100mbps POE port, 1*100mbps Uplink port | |
Network Medium | Cat5 (UTP) or more | |
Technology | ||
Network Standards | IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3x Flow Control IEEE 802.3af Power over Ethernet | |
PoE power | 15.4W per port(IEEE802.3af). Wiring: Data & power provided over pairs 1/2 and 3/6 or 4/5 (+) and 7/8(-) | |
Processing types | Store-and-forward Half-duplex back pressure and IEEE 802.3x full-duplex flow control | |
Address database Table Size | 2K MAC address | |
Buffer memory | 48Kb embedded memory per unit | |
Backboard Bandwidth | 1Gpbs Full duplex | |
Network Latency | Less than 20us for 64 byte frames in store-and-forward mode for 100Mbps to 100Mbps transmission | |
Power | ||
Input | External power supply DC52V | |
PoE power consumption | 15.4W per port(IEEE802.af) | |
Overload current protection | Present | |
Mechanical | ||
Casing | Metal | |
Installation | Wall mounting/ Desktop | |
Interface | ||
LED Indicators | System: Power, PoE Maximum power Per port: Link, Activity, Speed, PoE active, PoE error | |
Environment specification | ||
Operating temperature | -10-55℃(32-104℉) | |
Storage temperature | -40-70℃(14-158℉) | |
Operating humidity | 90% maximum relative humidity, non-condensing | |
Storage humidity | 95% maximum relative humidity, non-condensing | |
Regulatory Approval | ||
ISO | Manufactured in ISO9001 facility | |
Safety | CE/CCC/FCC | |
Warranty | 3 Years | |
Dimensions | 100*50*27mm (L*W*H) | |
Weight | N.W:0.4Kg G.W:0.5Kg | |
