Промышленная маркировочная машина dot peen Номер vin лазерная пневматическая для маркировки
- Категория: Metal Engraving Machinery >>>
- Поставщик: Guangzhou,Ling,Jueding,Intelligent,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 1547.38 $* | 1624.67 $* |
| Aug-19-2025 | 1534.28 $* | 1611.86 $* |
| Jul-19-2025 | 1287.36 $* | 1351.92 $* |
| Jun-19-2025 | 1508.28 $* | 1583.9 $* |
| May-19-2025 | 1313.98 $* | 1379.97 $* |
| Apr-19-2025 | 1482.54 $* | 1556.85 $* |
| Mar-19-2025 | 1469.35 $* | 1542.11 $* |
| Feb-19-2025 | 1456.82 $* | 1529.12 $* |
| Jan-19-2025 | 1443.22 $* | 1515.61 $* |
Характеристики
Welcome to contact krislyn for product inquiries and technical support.
Mobile/ WhatsApp/ WeChat: +86 18925153286/18922276329
Contact krislyn for discount and free testing
Specification
Brand | LJD |
Material | iron |
Color | green and black |
Function | Marking products |
Feature | 1. Computer control, windows system operation, powerful editing function, can arbitrarily edit the required characters and graphics, and support a variety of formats 2. Removable field printing - easy to move 3 .Easy to operate - easy to learn, easy to operate and easy to maintain 4 .Long service life 5. Small volume and light weight 6 .The printing effect is clear and fast |
Usage | It is suitable for engraving metal and non-metal products in automobile, motorcycle, electric vehicle, aviation, aerospace, steel, hardware, machinery manufacturing and other industries |
Marking speed | 3-5 characters(2x2mm)/s |
Marking area | 130*30mm |
Repeat printing accuracy | ≤0.01mm |
Marking depth | 0.01mm~2mm |
Marking contents | Chinese and English characters, Arabic numerals, arbitrary graphics (also CAD graphics files) |
Controller | 7"LCD touch screen controller |
Marking materials | below HRC60 metallic and nonmetallic materials , |
above HRC60 need special stylus | |
Power type | Pneumatic |
Impact frequency | 350 times / s, hardness HRC91 |
Connection | USB and RS-232 |
Gas consumption | 60L/min |
Compressed Air | 0.3MPa~0.6MPa |
( Pneumatic Air) | |
Work voltage | AC 110V 60HZ or AC220V 50HZ |
Power | 200W |
Working Environment | Temperature: 0-40 ℃ Humidity: ≤ 90 % |
Product Description
Provide signal interface
Our marking machine can provide a variety of interfaces, such as PLC, RS232, RS485, etc., which can connect with your equipment or upload data.
Marking machine parameters
1:Print range:Flat surface 135*80mm, 130*20mm, 500*500mm or custom print range
3~1500mm in the circumferential plane.
2:Engraving depth:0.1-2mm(The printing depth is determined by the hardness of the material) .
3:Air source pressure range:0.4-0.6Mpa.
4:The power supply requirements:AC220+10% or AC380+10% 50HZ
5:Speed of engraving:3 to 5 No. 2 characters per second and 1 to 110mm straight lines (adjustable)
6:Printing content: English letters, numbers, Chinese characters, graphics LOGO.
7: Direction of engraving: Planes and circumferential surfaces.
8: Input mode: manual, automatic serial number increment.
9: Marking needle: specially made of high hard alloy, hardness of HRC91.
Our marking machine can provide a variety of interfaces, such as PLC, RS232, RS485, etc., which can connect with your equipment or upload data.
Marking machine parameters
1:Print range:Flat surface 135*80mm, 130*20mm, 500*500mm or custom print range
3~1500mm in the circumferential plane.
2:Engraving depth:0.1-2mm(The printing depth is determined by the hardness of the material) .
3:Air source pressure range:0.4-0.6Mpa.
4:The power supply requirements:AC220+10% or AC380+10% 50HZ
5:Speed of engraving:3 to 5 No. 2 characters per second and 1 to 110mm straight lines (adjustable)
6:Printing content: English letters, numbers, Chinese characters, graphics LOGO.
7: Direction of engraving: Planes and circumferential surfaces.
8: Input mode: manual, automatic serial number increment.
9: Marking needle: specially made of high hard alloy, hardness of HRC91.
Applications
This model is Dot Matrix Pneumatic Marking Machine
1. This model can be used for VIN code engraving of trailer, truck or car. 2.This model can be used for steel plate number marking.
3.This model can be used for the engraving of industrial mold number.
4.This model can be used for coding and engraving of oil pipe and oil cylinder.
5. If you don't know whether this model is suitable for you, please feel free to contact us.
Company Profile
Guangzhou Ling Jue Ding Intelligent Equipment Co., Ltd. headquartered in Guangdong, China, is a collection of optics, electronics, computers, machinery as one of the R & D enterprises, with a number of invention patents, is also a service-oriented enterprise.
We are mainly engaged in the production of laser marking machines, pneumatic marking machine, multi-function machine, tire machine, laser welding machine, Laser nameplate machine, non-standard custom laser machine. Widely used in printing plate making, electronic circuits, integrated circuits, instrumentation, printed circuits, computer manufacturing, auto parts, precision equipment, gold and silver jewelry, craft gifts and other industries. Can provide OEM, ODM services for agents.
We have professional engineer support, high efficiency sales team and competitive price superiority, and attract customers from all over the world. Its products are sold to Europe, Poland, Serbia, Turkey, USA, Mexico, Brazil, India, Thailand ,Middle east and South Africa,serving more than 150 countries and regions on six continents.
Division I adhere to continuous technological innovation, pay close attention to quality management, and constantly improve the level of service, In the long-term development process with excellent product quality, good product performance, quality service system and many large manufacturers at home and abroad have established a long-term good partnership. We also warmly welcome customers at home and abroad to visit our company and technical exchanges.
Company vision: to provide manufacturing with reduced labor production equipment, so that production becomes easy and efficient. We look forward to more cooperation!
We are mainly engaged in the production of laser marking machines, pneumatic marking machine, multi-function machine, tire machine, laser welding machine, Laser nameplate machine, non-standard custom laser machine. Widely used in printing plate making, electronic circuits, integrated circuits, instrumentation, printed circuits, computer manufacturing, auto parts, precision equipment, gold and silver jewelry, craft gifts and other industries. Can provide OEM, ODM services for agents.
We have professional engineer support, high efficiency sales team and competitive price superiority, and attract customers from all over the world. Its products are sold to Europe, Poland, Serbia, Turkey, USA, Mexico, Brazil, India, Thailand ,Middle east and South Africa,serving more than 150 countries and regions on six continents.
Division I adhere to continuous technological innovation, pay close attention to quality management, and constantly improve the level of service, In the long-term development process with excellent product quality, good product performance, quality service system and many large manufacturers at home and abroad have established a long-term good partnership. We also warmly welcome customers at home and abroad to visit our company and technical exchanges.
Company vision: to provide manufacturing with reduced labor production equipment, so that production becomes easy and efficient. We look forward to more cooperation!
Recommend Products
Packing & Delivery
FAQ
Q1: I know nothing about this machine, what type of machine should I choose?
A: We will help you choose the suitable machine and share you the solution; you can share us what material will you marking / engraving and the depth of MARKING/ ENGRAVING.
Q2: When I got this machine, but I don’t know how to use it. What should I do?
A:We will send operation video and manual for the machine. Our engineer will do training online. If needed, we can send our engineer to your site for training or you can send the operator to our factory for training.
Q3: If some problems happen to this machine, what should I do?
A:We provide 13 months machine warranty. If there are any problems during warranty, we will provide free after-sales service. After the warranty, we still provide whole lifetime service.Please contact us if any questions.
Q4: What’s consumables of Pneumatic marking machine?
A: The main consumable is the marking needle.
Q5: How will you make package of the machines?
A: We have 3 layers package. For the outside, we adopt wooden cases free of fumigation. In the middle, the machine is covered by foam, to protect the machine from shaking. For the inside layer, the machine is covered by waterproof plastic film.
Q6: What’s the delivery time?
A: Normally the lead time is about 3-7 working days after receiving the payment.
Q7: What payment terms can you accept?
A: Any payment way is possible for us , like TT,Cash etc.
Q8: What shipping way will be included?
A: As per your actual address, we can effect shipment by sea, by air, by truck or railway. Also we can send the machine to your office as per your requirement .
