FR4 PCB програмная панель/CEM-3 печатная плата/алюминиевая основа
- Категория: Rigid PCB >>>
- Поставщик: Dongguan,Heart,Electronic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.85 $* | 0.51 $* |
| Aug-16-2025 | 0.92 $* | 0.72 $* |
| Jul-16-2025 | 0.66 $* | 0.20 $* |
| Jun-16-2025 | 0.77 $* | 0.76 $* |
| May-16-2025 | 0.66 $* | 0.20 $* |
| Apr-16-2025 | 0.58 $* | 0.93 $* |
| Mar-16-2025 | 0.26 $* | 0.94 $* |
| Feb-16-2025 | 0.64 $* | 0.80 $* |
| Jan-16-2025 | 0.67 $* | 0.59 $* |
Характеристики
FR4 PCB circuit board/CEM-3 circuit board/Aluminum based circuit board
Product Description
Send us your PCB file,Please click here.
| PCB capability | |||
| Item | PCB capability | PCB capability | PCB capability |
| Max Layer | 60L | 8L | 36L |
| Inner Layer Min Trace/Space | 3/3mil | 3/3mil | 3/3mil |
| Out Layer Min Trace/Space | 3/3mil | 3.5/4mil | 3.5/4mil |
| Inner Layer Max Copper | 6oz | 2oz | 6oz |
| Out Layer Max Copper | 6oz | 2oz | 3oz |
| Min Mechanical Driling | 0.15mm | 0.1mm | 0.15mm |
| Min Laser Drilling | 0.1mm | 0.1mm | 0.1mm |
| Max Aspect Ratio(Mechanical Driling) | 20:01 | 10:01 | 12:01 |
| Max Aspect Ratio(Laser Drilling) | 1:01 | / | 1:01 |
| Press Fit Hole Ttolerance | ±0.05mm | ±0.05mm | ±0.05mm |
| PTH Tolerance | ±0.075mm | ±0.075mm | ±0.075mm |
| NPTH Tolerance | ±0.05mm | ±0.05mm | ±0.05mm |
| Countersink Tolerance | ±0.15mm | ±0.15mm | ±0.15mm |
| Board Thickness | 0.4-8mm | 0.1-0.5mm | 0.4-3mm |
| Board Thickness Tolerance(<1.0mm) | ±0.1mm | ±0.05mm | ±0.1mm |
| Board Thickness Tolerance(≥1.0mm) | ±10% | / | ±10% |
| Min Board SizeMin Board Size | 10*10mm | 5*10mm | 10*10mm |
| Max Board Slze | 22.5*30 inch | 9*14 inch | 22.5*30 inch |
| Contour Tolerance | ±0.1mm | ±0.05mm | ±0.1mm |
| Min BGA | 7mil | 7mil | 7mil |
| Min SMT | 7*10mil | 7*10mil | 7*10mil |
| Min Solder Mask Clearance | 1.5mil | 3mil | 1.5mil |
| Min Solder Mask Dam | 3mil | 8mil | 3mil |
| Min Legend Width/Height | 4/23mil4/23mil | 4/23mil | 4/23mil |
| Strain Fillet Width | / | 1.5±0.5mm | 1.5±0.5mm |
| Bow &Twist | 0.003 | / | 0.0005 |
Any more you want to know.Please click here.
OUR FACTORY
Dongguan Heart Electronics technology Co., Ltd is a PCB and PCBA manufacturer providing all kinds of PCB and PCBA solutions, We can provide our customers with high-quality, high-precision single-side pcb,double-side pcb,and multi-layer pcb, Also components procurement and circuit board assembly (SMT), we have a lot of advantages.
Learn more about us,Please click here.
OUR EQUIPMENT
Our Services
LEAD TIME
| Lead Time of Our PCB | ||
| Layers of PCB | Sample, Quick Turn / Usual Time | Mass order(>5square meter) (Days) |
| 1-2 Layer PCB | 24 hours / 4-5days | 5-7 days |
| 4 Layer PCB | 48 hours / 6-7days | 7-12 days |
| 6 Lyer PCB | 72 hours / 7-8days | 12-15 days |
| 8 Lyer PCB | 72 hours / 8-10days | 16-18 days |
| 10Layer PCB | 96 hours / 12-14days | 18-20days |
Any questions tell me, please. We can do best for you.
OUR CUSTOMER
Packaging & Shipping
