Переключатель уровня воды в стиральной машине
US $1.00-$3.00
Tianxiang реле давления 505/18D диапазон 40-400bar подключение:
- Категория: Pressure Switches >>>
- Поставщик: Changzhou,Tianli,Intelligent,Control,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-17-2025 | 37.58 $* | 38.64 $* |
| Jul-17-2025 | 30.15 $* | 31.56 $* |
| Jun-17-2025 | 36.74 $* | 37.52 $* |
| May-17-2025 | 36.99 $* | 37.72 $* |
| Apr-17-2025 | 29.45 $* | 30.0 $* |
| Mar-17-2025 | 35.1 $* | 36.3 $* |
| Feb-17-2025 | 35.56 $* | 36.35 $* |
| Jan-17-2025 | 35.59 $* | 36.81 $* |
Характеристики
505/18D Series of Pressure Switch
The Sensor of Switches utilize Diaphragm-Piston Conbination, 500/18D Switches use Diaphragm Sensor can be suitable for neutral gas, lubricating oil,light fuel ect. Fluid medium. 505/18D Switches use no-leak piston sensor,can be fit for lubricating oil, light fuel such neutral lube medium. the Set Point is adjustable, and its adjustable range is from 0.5MPa to 40MPa.
| Specification | ||||||||||
| Dead Band Non-Adjustable | ||||||||||
| Set Point adjustable range Bar | Dead Band No Greater Than | Max. Allowable pressure* Bar | Material of sensor | Process Connection Type | Connection(F) | Weight Kg | Order Content No. | |||
| Lower limit of Set Point Range Bar | Upper limit of Set Point Range Bar | Shell | Sealing Ring | Piston | ||||||
| 505/18D Piston Type Pressure Switch | ||||||||||
| 5…70 | 8 | 20 | 400 | Al | Nitrile Rubber | Steel | I | G1/4" | 0.2 | 0882100 |
| 5…70 | 8 | 20 | P | 0883100 | ||||||
| 10…160 | 12 | 35 | I | G1/4" | 0882200 | |||||
| 10…160 | 12 | 35 | P | 0883200 | ||||||
| 25…250 | 15 | 40 | I | G1/4" | 0882300 | |||||
| 25…250 | 15 | 40 | P | 0883300 | ||||||
| 40…400 | 18 | 45 | 400 | I | G1/4" | 0882400 | ||||
| 40…400 | 18 | 45 | 400 | P | 0883400 | |||||
