Кран для туалета и кухни TB6120, латунный, 1/2 градусов
US $1.52-$1.64
Производитель клапанов DN15 DN20 DN40 DN50 шаровой кран высокого давления с электрическим
- Категория: Valves >>>
- Поставщик: Jiangsu,Huagong,Automatic,Control,Valve,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 2054.14 $* | 2157.73 $* |
| Aug-19-2025 | 2037.43 $* | 2139.64 $* |
| Jul-19-2025 | 1709.18 $* | 1794.87 $* |
| Jun-19-2025 | 2002.92 $* | 2102.47 $* |
| May-19-2025 | 1743.42 $* | 1830.84 $* |
| Apr-19-2025 | 1968.37 $* | 2066.66 $* |
| Mar-19-2025 | 1950.46 $* | 2048.65 $* |
| Feb-19-2025 | 1933.34 $* | 2030.77 $* |
| Jan-19-2025 | 1916.35 $* | 2012.16 $* |
Характеристики
item | value |
Warranty | 1 year |
Type | BALL VALVES |
Customized support | OEM, ODM |
Place of Origin | China |
Jiangsu | |
Brand Name | HGZK |
Model Number | HGZK001 |
Application | General |
Temperature of Media | Normal Temperature |
Power | Electric |
Media | Water |
Port Size | 1/2"~4", DN15~DN100 |
Structure | BALL |
Product name | Electric Ball Valve |
Pressure | PN1.6MPa |
Voltage | DC12~24V (±10%), AC110-220V, 50/60Hz |
End Connection | Double Union, Threaded |
Body material | SS316, SS304 |
Control Mode | On Off Type or Regulation Type |
Seal Material | PTFE |
OEM | Avaiable |
MOQ | 1 |
Delivery | Payment Received |
Hand wrench
Switch indication
Electrical interface
Switch type | Only the switch can be controlled，Switch signal. | ||||
Regulating type | The opening can be controlled.Input & Output Signal: DC 4-20mA, DC 0-10V, DC 0-5V | ||||
Field Operation | The Field, Remote Control Switch Regulation and MODBUS, PROFIBUS Field Bus | ||||
Output Torque | 50 - 4000Nm | ||||
Angle of Rotation | 0-90° ± 3° | ||||
Action time | 15S/30S/60S | ||||
Optional Voltage | DC12V , DC24V , AC24V , AC110 , AC220V , AC380V | ||||
Shell Material | Die-Cast Aluminum Alloy | ||||
Protection Class | IP65 | ||||
Ambient Temp | Range from -20°C to +60°C | ||||
Appearance color: | White , Blue or Customize other colors | ||||
More wiring circuit ways contact merchants, support customized control circuits
1. Which voltage of the electric actuator?
DC24V ，AC220V
AC24V/AC110VAC380V can be customized.
AC24V/AC110VAC380V can be customized.
2. What type of electric actuator you provide?
ON/OFF type, Regulation type and Intelligent type.
3. What model is selected to control the flow
Regulating type can Control the valve opening through electric signal.
4. Is there any manual override of electric valve?
Yes, every electric valve includes the manual override.
5.Can the electric valve automatically reset (normally open / closed) when power is off?
The electric valve is maintained after power failure and has no automatic reset function. It can be customized with battery to realize power-off reset.
6. Are there any more intelligent products？
Yes, I can introduce it to you according to your needs，You can contact our sales staff.
7.Is the sample order acceptable?
Yes, of course.
8. Can you do OEM for me?
We accept all OEM orders,we can customize different colors, LOGO and so on according to customer's requirements.just contact us and give me your design.we will offer you a reasonable price and make samples for you ASAP.
9.Do you have more valve products？
We produce various valves, such as pneumatic valves, electric valves, control valves, ball valves, butterfly valves, gate valves,globe valves, check valves, etc.
10. Why Us?
Quality assurance: All the products will go through lots of tests carefully before dispatch
Competitive production capacity and fast shipping
Factory direct sale, most competitive price.
Competitive production capacity and fast shipping
Factory direct sale, most competitive price.
