Оптовая продажа турбина для крыши воздушный радиальный вытяжной вентилятор
- Категория: Refrigeration & Heat Exchange Equipment >>>
- Поставщик: Shandong,Yichen,International,Trade,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 108.1 $* | 110.31 $* |
| Jul-18-2025 | 88.33 $* | 90.11 $* |
| Jun-18-2025 | 106.58 $* | 108.3 $* |
| May-18-2025 | 105.83 $* | 107.2 $* |
| Apr-18-2025 | 84.15 $* | 86.42 $* |
| Mar-18-2025 | 104.78 $* | 106.21 $* |
| Feb-18-2025 | 103.55 $* | 105.62 $* |
| Jan-18-2025 | 102.84 $* | 104.89 $* |
Характеристики
Product Application
Exhaust fan are widely used in Agriculture and industry ventilation and cooling. It is mainly used for animal husbandry, poultry house, livestock breeding, greenhouse, factory workshop, textile etc.
select panels and accessories, strict quality control, high quality testing
requirements make the fan produced by Big Herdsman has the following characteristics: high total pressure, large air volume, low noise, low energy consumption, smooth operation, long life and so on.
Exhaust fan are widely used in Agriculture and industry ventilation and cooling. It is mainly used for animal husbandry, poultry house, livestock breeding, greenhouse, factory workshop, textile etc.
select panels and accessories, strict quality control, high quality testing
requirements make the fan produced by Big Herdsman has the following characteristics: high total pressure, large air volume, low noise, low energy consumption, smooth operation, long life and so on.
Product Parameters
Push pull fan
Specification and model | Blade diameter (mm) | Frequency (Hz) | Motor speed r/min | Air volume m ³/ h | Noise (dB) | Input power w | Rated voltage（v） | Dimensions H W T | ||||||||
JWS-800 | 710 | 50 | ≥1400 | 22000 | ≤64 | 370 | 220/380 | 800*800*450 | ||||||||
JWS-1000 | 910 | 50 | ≥1400 | 32000 | ≤64 | 750 | 220/380 | 1000*1000*450 | ||||||||
JWS-1100 | 1000 | 50 | ≥1400 | 40000 | ≤64 | 750 | 220/380 | 1100*1100*450 | ||||||||
JWS-1380 | 1380 | 50 | ≥1400 | 45000 | ≤64 | 1100 | 220/380 | 1380*1380*450 | ||||||||
JWS-1530 | 1400 | 50 | ≥1400 | 52800 | ≤64 | 1500 | 220/380 | 1530*1530*450 | ||||||||
Other sizes can be customized. Please consult customer service for specific specifications | ||||||||||||||||
Heavy hammer fan
Specification and model | Blade diameter (mm) | Blade speed (r/min) | Motor speed r/min | Air volume m ³/ h | Noise (dB) | Input power w | Rated voltage（v） | Dimensions H W T（mm） | ||||||||
JWS-800 | 710 | 650 | 710 | 18000 | ≤70 | 370 | 220/380 | 800*800*370 | ||||||||
JWS-900 | 750 | 630 | 750 | 22000 | ≤66 | 550 | 900*900*400 | |||||||||
JWS-1000 | 910 | 610 | 900 | 23000 | ≤70 | 550 | 220/380 | 1000*1000*400 | ||||||||
JWS-1100 | 1000 | 600 | 1000 | 32500 | ≤70 | 750 | 220/380 | 1100*1100*400 | ||||||||
JWS-1220 | 1100 | 460 | 1100 | 35000 | ≤73 | 1100 | 1220*1220*400 | |||||||||
JWS-1380 | 1250 | 439 | 1250 | 41000 | ≤56 | 1100 | 220/380 | 1380*1380*400 | ||||||||
JWS-1530 | 1400 | 325 | 1400 | 50800 | ≤60 | 1500 | 220/380 | 1530*1530*400 | ||||||||
Other sizes can be customized. Please consult customer service for specific specifications | ||||||||||||||||
Main Features
1) Hot-dip galvanized plate adopt 275g/㎡ galvanized layer, not rust.
2) 95% of the parts are produced by ourselves, reducing the cost of processing ,sharing profits with customers, ensuring quality , utmost cost-effective globally
3) Complete CNC production line, the accuracy of assembling holes is 100%, easy to assemble, quality assured.
4) Wall-Mounting fan , easy installation and maintenance
5) Belt Drive, Big airflow
1) Hot-dip galvanized plate adopt 275g/㎡ galvanized layer, not rust.
2) 95% of the parts are produced by ourselves, reducing the cost of processing ,sharing profits with customers, ensuring quality , utmost cost-effective globally
3) Complete CNC production line, the accuracy of assembling holes is 100%, easy to assemble, quality assured.
4) Wall-Mounting fan , easy installation and maintenance
5) Belt Drive, Big airflow
Products Description
Negative pressure fan is the use of air convection, negative pressure ventilation cooling principle, is a natural inhalation of fresh air from the installation site - the door or window, the indoor hot air quickly forced out of the outdoor, any poor ventilation can be improved.
Product Details
Application Area
Company Profile
Our company is a company specializing in gardening supplies, mainly engaged in seedling trays, flower pots and other products.Our factory in China is very large and has a complete production chain, which can ensure the output and quality of products. At the same time our products accept customization, you can provide your product model and desired quantity, we will meet your needs.
FATORY FLOOR PLAN
THE PACKING AND SHIPPING
GOOD COMMENTS
HONORARY CERTIFICATE
FAQ
Q:What is your minimum oreder quantity?
A:We accept small order quantity, but the freight cost will be very high
Q:Can you open our own brand?
A:Yes,we can offer OEM/ODM service,put your logo for the produce.
Q:Voltage your can offer?
A:Normal voltage will be 380V-50HZ-3Phase, And it can be customized based on your request.
Q:How about the quality of your product?
A:All the products are produced strictly according to the international standard,which has been passed CE certification,CCC certificated and ISO9001:2008 international quality management system.
Q:Can you accept an inspection of a Third-party detection instituation?
A:Yes,sure. Our products have been inspected by some third-party detection institutions authorized by customs before.and have got perfect inspection report.
