Новинка 2022 Лидер продаж Wi-Fi
- Категория: Other Consumer Electronics >>>
- Поставщик: Shenzhen,Junuo,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 39.38 $* | 40.4 $* |
| Jul-15-2025 | 32.51 $* | 33.1 $* |
| Jun-15-2025 | 39.94 $* | 40.73 $* |
| May-15-2025 | 38.97 $* | 39.92 $* |
| Apr-15-2025 | 31.9 $* | 32.85 $* |
| Mar-15-2025 | 38.4 $* | 39.54 $* |
| Feb-15-2025 | 38.75 $* | 39.73 $* |
| Jan-15-2025 | 37.83 $* | 38.18 $* |
Характеристики
Products Specification
Product model | X1 |
Weight | 300g |
Mounting method | Desktop |
Dimensions (excluding accessories) | 99mm x 99mm x 89mm |
Ethernet port | 10/100/1000 Mbps Base-TX port x 3 |
Local power supply | Support 12V 1A DC |
Antenna type | Two high-performance internal array antennas |
Antenna gain | 2.4G：4dBi 5G：4dBi |
Operating frequency bands | 802.11ax/ac/n/a : 5.725GHz-5.850GHz ; 5.15~5.35GHz (China only) 802.11ax/b/g/n : 2.4GHz-2.483GHz (China only) |
Wi-Fi data rate | 2.4G:2*2 11ax 573Mbps 5G:2*2 11ax 1200Mbps WiFi:2.4G/5G WIFI |
Wi-Fi power | 2.4G：20dBm@MCS7/BW20(EVM-30dB) 5G: 17dBm@MCS9/BW80(EVM-32dB) |
Maximum total transmitting power | 2.4 GHz: 23 dBm (combined power) 5 GHz : 20 dBm (combined power) The actual transmission power is subject to relevant regulations. |
Modulation technology | OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps MIMO-OFDM (11n): MCS 0-31 MIMO-OFDM (11ac): MCS 0-9 MIMO-OFDM (11ax): MCS 0-11 |
Modulation mode | 11b: DSS: CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps 11a/g: OFDM: 64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM 11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM 11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM |
Power adjustment | Automatic |
Reset | Supported |
Status LED | Solid on / Breathing / Network error (The LED can be turned off using software.) |
Operating temperature / Storage temperature | -10ºC～40ºC/-40ºC～70ºC |
Operating humidity / Storage humidity | 5%～95% (non-condensing) |
Protection class | IP41 |
Maximum total power | <15W |
EMC | GB9254、EN301 489、EN55022、FCC Part 15、RSS-210 |
Certification | FCC/CE/CCC/RoHS |
MTBF | >250000H |
CONTACT INFO
sales20@cnjuno.com
Overview
Essential details
Essential details
Max. LAN Data Rate:1900Mbps
With Modem Function:NO
Standards And Protocols:Wi-Fi 802.11g, Wi-Fi 802.11b, Wi-Fi 802.11n, Wi-Fi 802.11ac, Wi-Fi 802.11a, Wi-Fi 802.11ax
Wi-Fi Supported Frequency:2.4G & 5G
Supports WDS:Yes
Supports WPS:Yes
Wi-Fi Transmission Standard:WiFi 802.11 ax
Wired Transfer Rate:10/100/1000Mbps
2.4G Wi-Fi Transmission Rate:600Mbps
Encryption Type:WPA2-PSK, WPA2, WPA3, WPA2-Enterprise, WPA-PSK, WPA, WEP, WPA-Enterprise, WPA2-Personal, WPA-Personal,
WPA3-Personal
Private Mold:Yes
Products Status:New
Type:Mesh
Application:Multi-service
Function:Voip, FireWall, QoS, VPN, SDK available
LAN Ports:3, 1 GE WAN, 2 GE LAN
WAN Ports:1 x10/100/1000Mbps
Brand Name:Junuo/ODM/OEM
5G Wi-Fi Transmission Rate:1300Mbps
Product name:new wifi6 router
Bandwidth:600M/1200M/1800M
WiFi:2.4G/5G WIFI
Input voltage:DC in 12V/1A
Size(L*W*H):99mm x 99mm x 89mm
Material:Placstic
Color:Black/White
Brand:Brand Logo
Product Description
Feedback
Company Profile
Exhibition
Certificates
FAQ
1. Which services does OEM include?
A. Logo printing
B. Customized package
C. Software customization: Booting image, UI, App, Function, etc.
2. For the first-time order, how can I believe that you would send the product?
We are a 12-year golden supplier and a company verified by Alibaba. Our company locates in Building 1, Hezhou New Industrial Zone,Bao'an District, Shenzhen, Guangdong, China. We can provide you with pictures and videos from our company and factory. Also,we can provide you with some of our other customers' recent parcel tracking number to prove that their goods were delivered successfully.
3. Which payments do you accept?
We accept T/T, Western Union, Credit Card, etc according to the exact order amount.
4. How about the delivery time?
For samples: within 1-3 working days for standard products in stock. For bulk order: about 15-20 working days after we receive the 30% deposit and customers confirm all the OEM details.
5. Can my parcel be tracked and when can I get the tracking number of my parcel?
We will send you the tracking number on the second day after the parcel is shipped. You can track the parcel at the official
website of the delivery company.
6. What kind of power adapter can you provide?
EU, UK, US, AU four standards of plugs are available. We will send the different adapter to you according to your country or requirements.
7. How about the warranty?
1-year warranty:
If there is any problem, you could contact us. Our engineers will patiently tell you how to solve it.
If there's still a problem with the help of our engineers, you can return us the defective products for maintenance. And then we will send back good items to you ASAP.
Attention: Customers need to be responsible for the shipping costs.
In order to avoid loss, all our goods are tested carefully by technical staffs before delivery, please rest assured！
A. Logo printing
B. Customized package
C. Software customization: Booting image, UI, App, Function, etc.
2. For the first-time order, how can I believe that you would send the product?
We are a 12-year golden supplier and a company verified by Alibaba. Our company locates in Building 1, Hezhou New Industrial Zone,Bao'an District, Shenzhen, Guangdong, China. We can provide you with pictures and videos from our company and factory. Also,we can provide you with some of our other customers' recent parcel tracking number to prove that their goods were delivered successfully.
3. Which payments do you accept?
We accept T/T, Western Union, Credit Card, etc according to the exact order amount.
4. How about the delivery time?
For samples: within 1-3 working days for standard products in stock. For bulk order: about 15-20 working days after we receive the 30% deposit and customers confirm all the OEM details.
5. Can my parcel be tracked and when can I get the tracking number of my parcel?
We will send you the tracking number on the second day after the parcel is shipped. You can track the parcel at the official
website of the delivery company.
6. What kind of power adapter can you provide?
EU, UK, US, AU four standards of plugs are available. We will send the different adapter to you according to your country or requirements.
7. How about the warranty?
1-year warranty:
If there is any problem, you could contact us. Our engineers will patiently tell you how to solve it.
If there's still a problem with the help of our engineers, you can return us the defective products for maintenance. And then we will send back good items to you ASAP.
Attention: Customers need to be responsible for the shipping costs.
In order to avoid loss, all our goods are tested carefully by technical staffs before delivery, please rest assured！
Products Specification
Product model | X1 |
Weight | 300g |
Mounting method | Desktop |
Dimensions (excluding accessories) | 99mm x 99mm x 89mm |
Ethernet port | 10/100/1000 Mbps Base-TX port x 3 |
Local power supply | Support 12V 1A DC |
Antenna type | Two high-performance internal array antennas |
Antenna gain | 2.4G：4dBi 5G：4dBi |
Operating frequency bands | 802.11ax/ac/n/a : 5.725GHz-5.850GHz ; 5.15~5.35GHz (China only) 802.11ax/b/g/n : 2.4GHz-2.483GHz (China only) |
Wi-Fi data rate | 2.4G:2*2 11ax 573Mbps 5G:2*2 11ax 1200Mbps |
Wi-Fi power | 2.4G：20dBm@MCS7/BW20(EVM-30dB) 5G: 17dBm@MCS9/BW80(EVM-32dB) |
Maximum total transmitting power | 2.4 GHz: 23 dBm (combined power) 5 GHz : 20 dBm (combined power) The actual transmission power is subject to relevant regulations. |
Modulation technology | OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps MIMO-OFDM (11n): MCS 0-31 MIMO-OFDM (11ac): MCS 0-9 MIMO-OFDM (11ax): MCS 0-11 |
Modulation mode | 11b: DSS: CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps 11a/g: OFDM: 64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM 11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM 11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM |
Power adjustment | Automatic |
Reset | Supported |
Status LED | Solid on / Breathing / Network error (The LED can be turned off using software.) |
Operating temperature / Storage temperature | -10ºC～40ºC/-40ºC～70ºC |
Operating humidity / Storage humidity | 5%～95% (non-condensing) |
Protection class | IP41 |
Maximum total power | <15W |
EMC | GB9254、EN301 489、EN55022、FCC Part 15、RSS-210 |
Certification | FCC/CE/CCC/RoHS |
MTBF | >250000H |
Feedback
Company Profile
Exhibition
Certificates
FAQ
1. Which services does OEM include?
A. Logo printing
B. Customized package
C. Software customization: Booting image, UI, App, Function, etc.
2. For the first-time order, how can I believe that you would send the product?
We are a 12-year golden supplier and a company verified by Alibaba. Our company locates in Building 1, Hezhou New Industrial Zone,Bao'an District, Shenzhen, Guangdong, China. We can provide you with pictures and videos from our company and factory. Also,we can provide you with some of our other customers' recent parcel tracking number to prove that their goods were delivered successfully.
3. Which payments do you accept?
We accept T/T, Western Union, Credit Card, etc according to the exact order amount.
4. How about the delivery time?
For samples: within 1-3 working days for standard products in stock. For bulk order: about 15-20 working days after we receive the 30% deposit and customers confirm all the OEM details.
5. Can my parcel be tracked and when can I get the tracking number of my parcel?
We will send you the tracking number on the second day after the parcel is shipped. You can track the parcel at the official
website of the delivery company.
6. What kind of power adapter can you provide?
EU, UK, US, AU four standards of plugs are available. We will send the different adapter to you according to your country or requirements.
7. How about the warranty?
1-year warranty:
If there is any problem, you could contact us. Our engineers will patiently tell you how to solve it.
If there's still a problem with the help of our engineers, you can return us the defective products for maintenance. And then we will send back good items to you ASAP.
Attention: Customers need to be responsible for the shipping costs.
In order to avoid loss, all our goods are tested carefully by technical staffs before delivery, please rest assured！
A. Logo printing
B. Customized package
C. Software customization: Booting image, UI, App, Function, etc.
2. For the first-time order, how can I believe that you would send the product?
We are a 12-year golden supplier and a company verified by Alibaba. Our company locates in Building 1, Hezhou New Industrial Zone,Bao'an District, Shenzhen, Guangdong, China. We can provide you with pictures and videos from our company and factory. Also,we can provide you with some of our other customers' recent parcel tracking number to prove that their goods were delivered successfully.
3. Which payments do you accept?
We accept T/T, Western Union, Credit Card, etc according to the exact order amount.
4. How about the delivery time?
For samples: within 1-3 working days for standard products in stock. For bulk order: about 15-20 working days after we receive the 30% deposit and customers confirm all the OEM details.
5. Can my parcel be tracked and when can I get the tracking number of my parcel?
We will send you the tracking number on the second day after the parcel is shipped. You can track the parcel at the official
website of the delivery company.
6. What kind of power adapter can you provide?
EU, UK, US, AU four standards of plugs are available. We will send the different adapter to you according to your country or requirements.
7. How about the warranty?
1-year warranty:
If there is any problem, you could contact us. Our engineers will patiently tell you how to solve it.
If there's still a problem with the help of our engineers, you can return us the defective products for maintenance. And then we will send back good items to you ASAP.
Attention: Customers need to be responsible for the shipping costs.
In order to avoid loss, all our goods are tested carefully by technical staffs before delivery, please rest assured！
