Алюминиевый корпус AC 220 В 240 приглушаемый светодиодный драйвер 12 В/24 60 Вт-300 Вт Triac 0-10 в затемнение 2 1 источник питания трансформатор
- Категория: >>>
- Поставщик: Shenzhen,Ramasun,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.4 $* | 0.36 $* |
| Aug-15-2025 | 0.86 $* | 0.70 $* |
| Jul-15-2025 | 0.11 $* | 0.21 $* |
| Jun-15-2025 | 0.85 $* | 0.10 $* |
| May-15-2025 | 0.67 $* | 0.63 $* |
| Apr-15-2025 | 0.40 $* | 0.13 $* |
| Mar-15-2025 | 0.69 $* | 0.21 $* |
| Feb-15-2025 | 0.12 $* | 0.68 $* |
| Jan-15-2025 | 0.79 $* | 0.77 $* |
Характеристики
BUYERS NOTICES:
1. ALL THE DESCRIPTIONS AND THE PRICES MARKED ON THIS PAGE ARE NOT CORRECT, SUBJECT TO OUR FINAL CONFIRMATION.
2. TO GET LATEST PRICES AND FREIGHT COST, PLEASE KINDLY INQUIRE US NOW.
3. FREE SAMPLES ARE AVAILABLE TO PROVIDE. HOPE YOU ARE LUCKY TO GET THEM FREE.
..................................................................................................................................................................
Product Feature
0/1-10v & traic Dimming 2in1.
Aluminum shell IP20 non-waterproof, indoor use or installed in a rainproof box.
Ultra thin fanless cooling design, no noise from fan.
100% full load burn-in test.
Protections: short circuit, over load, over voltage, over temp.
Dimming interface: Triac/0-10v
Apply to leading edge / trailing edge Triac dimmers and 0-10vdimming system.
Built-in high performance MCU, dimming curve can be customized.
Dimming range: 0~100%, LED start at 0.1% possible .
Multi-current & wide voltage, suitable for different power LED.
Short circuit / Over-heat / Over load protection.
Compliant with Safety Extra Low Voltage standard.
12V/24V60W Dimmable Power Supply
VOLTAGE RANGE :AC200-240V
FREQUENCY RANGE :47-63Hz
DC VOLTAGE:DC 12V 5A 24V 2.5A OUTPUT
CURRENTRANGE:0-60W
Dimming interface:Triac/0-10V
Dimming range: 0~100%, LED start at 0.1% possible.
Efficiency: >85%
Working temperature: ta: -30 ~ 55°C tc: 80°C
Weight(G.W) :240g
12V/24V100W 300W Dimmable Power Supply
VOLTAGE RANGE :AC200-240V
FREQUENCY RANGE :47-63Hz
DC VOLTAGE:DC 12V/24V OUTPUT
CURRENTRANGE:100W 150W 200W 250W 300W
Dimming interface:Triac/0-10V
Dimming range: 0~100%, LED start at 0.1% possible.
Efficiency: >85%
Working temperature: ta: -30 ~ 55°C tc: 80°C
Weight(G.W) :290g
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
