Sinomach 142квт 719H автогрейдер
- Категория: Motor Graders >>>
- Поставщик: RISEN,Construction,Machinery,(Shanghai),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 47600.14 $* | 49980.94 $* |
| Aug-17-2025 | 47200.1 $* | 49560.5 $* |
| Jul-17-2025 | 39600.78 $* | 41580.29 $* |
| Jun-17-2025 | 46400.89 $* | 48720.58 $* |
| May-17-2025 | 40400.1 $* | 42420.53 $* |
| Apr-17-2025 | 45600.88 $* | 47880.74 $* |
| Mar-17-2025 | 45200.59 $* | 47460.26 $* |
| Feb-17-2025 | 44800.16 $* | 47040.51 $* |
| Jan-17-2025 | 44400.21 $* | 46620.55 $* |
Характеристики
Hot Product Links
Product Description
This 719H Motor Grader is equipped with reliable ShangChai SC11CB195G2B1 engine or genuine Cummins engine
Sing-handle electro-hydraulic controlled power-shift T/M, 6 forward & 3 reverse shifts makes operation easy and convenient
Hydraulic lock, auto lock/unlock NO-SPIN differential ensures stability and powerful traction
Ideal axel load allocation provides excellent stability while cutting hard surface
Serviceable, efficient hydraulic system enables every part to be fully used
Box-typed frame and advanced T/M enable it to complete heavy-duty work
A wide working range is accomplished through flexible blade suspension system and articulated frame
Main Parameter
| Basic specification | |
| Engine model | Cummi-ns 6CTA8.3-C190 |
| Rated power | 142KW@2200rpm |
| Dimension(L×W×H) | 8945×2600×3420(mm) |
| Operating weight(Standard) | 15600KG |
| Performance specification | |
| Travelling speed, forward | 6.5/11.4/14.6/24.8/30/49.2 |
| Travelling speed, reverse | 6.5/14.6/30 |
| Tractive force(f=0.75) | 80.2KN |
| Operating specification | |
| Max. steering angle of front wheels | 49 |
| Max. lean angle of front wheels | 17 |
| Max. oscillation angle of front axle | 16 |
| Max. oscillation angle of balance box | 13 |
| Frame articulation angle | 26 |
| Min. turning radius using articulation | 7.3m |
| Blade | |
| Maximum lift above ground | 450mm |
| Maximum grading depth | 535mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 29°~77° |
| Circle reversing rotation | 360° |
| Moldboard width × height | 4268×580mm |
Our Factory
RISEN ConstructionMachinery (Shanghai) Co., Ltd is engaged in developing, manufacturing andexporting construction machines in the areas of building, mining, energy andlogistic engineering. Offering 8 major categories, 38 product line and morethan 1000 models, RISEN is able to provide complete equipment package to theclients from all walks of life.We are a wholesaler of many brands in China, a professional exporter of construction machinery and a one-stop solution provider. Our team has over 15 years of experience in this field.
From the factory to our customer's destination, we will conduct all-round supervision.We can also helpto sign purchase ordercontracts, test product quality, guarantee timelydelivery, and accomodate special orders.
What is the proportion of your products exported?
75% of our products are exported to all over the world.
What is the payment term?
Payment term is negotiable and there will be favorable payment terms for long-term customers. TT, L/C, D/P, depending on the cooperation time, country and contract value.
What kind of logistic service do you supply?
A. Transportation: railway transportation, international through transport, including (international railway through transportation, Sea-rail intermodal through transportation, sea-land multimodal transportation. Means of transport : Container, LCL, FRC, ro-ro, bulk cargo, train carriage, truck, air plane.
B. Term: FOB,CIF, DAP, to door service, etc.
