Контейнерные дома складной модульный дом роскошный современный раздвижной туристический
- Категория: >>>
- Поставщик: CDPH,(hainan),Company,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 14280.51 $* | 14994.2 $* |
| Aug-16-2025 | 14160.56 $* | 14868.66 $* |
| Jul-16-2025 | 11880.87 $* | 12474.95 $* |
| Jun-16-2025 | 13920.94 $* | 14616.26 $* |
| May-16-2025 | 12120.66 $* | 12726.52 $* |
| Apr-16-2025 | 13680.90 $* | 14364.17 $* |
| Mar-16-2025 | 13560.8 $* | 14238.47 $* |
| Feb-16-2025 | 13440.34 $* | 14112.30 $* |
| Jan-16-2025 | 13320.73 $* | 13986.37 $* |
Характеристики
PREDUCT VIDEO
PRODCUT DESCRIPTION
PRODUCT PARAMETERS
Specification | 1 | L*W*H（mm） | 6055*2990*2900（internal 5805*2740*2540） |
2 | Roof Type | Corrugated, roof draining via 4 pipes at the corner | |
Frame | 3 | Corner Column | Profile: L210*150mm, galvanized, t=2.5mm, metal code SGH340 |
4 | Roof Beam | Profile: 185mm, galvanized, t=2.5mm, metal code SGH340 | |
5 | Floor Beam | Profile: 160mm, galvanized, t=2.5mm, metal code SGH340 | |
6 | Roof Purlin | Profile: square tube 60*60*1.5mm, metal code Q235B | |
7 | Floor Purlin | Π type high strength, 101*1.0mm profile, metal code Q345 | |
8 | Painting | Bottom painting and surface painting, thickness 40μm, grey white | |
Roof | 9 | Roof Cladding | 0.4mm thick, galvalume metal sheet, white color |
10 | Insulation | 75mm glass wool, one side with aluminum film, density≥14kg/m³ | |
11 | Ceiling | 0.35mm thick, galvalume metal sheet, white color | |
Floor | 12 | Flooring Sheet | 1.6mm PVC flooring sheet |
13 | Base Plate | 18mm thick fiber cement board, density≥1.3g/cm³ | |
Wall | 14 | Thickness | 50mm panel, both sides 0.35mm metal sheet, grey white color |
15 | Insulation | Glass wool, density 50kg/m³ | |
Door | 16 | Size（mm） | WXH=840*2035 |
17 | Profile | Metal door | |
Window | 18 | Size（mm） | WXH=1120*1100 |
19 | Frame Profile | PVC integrated sliding window with security bar and screen | |
20 | Glass | 4mm+9A+4mm double glazed | |
Electrics | 21 | Voltage | 220V~250V |
22 | Electric Wires | Main circuit BVVB-3*6.0, air conditioner BVVB-3*4.0, socket BVVB-3*2.5, lighting BVVB-3*1.5 | |
23 | DB Box | 10 digit unexposed PVC box*1（Including high breaking circuit breaker 10A/1P, high breaking circuit breaker 20A/2P, high breaking circuit breaker 5A/2P, leakage protection circuit breaker 16A/2P, 1 piece each break） | |
24 | Lighting | LED lamp（LED 16.5W*2）*2 | |
25 | Socket | Industrial socket（3P/32A）*1, three pole multi-functional socket（250V 16A）*4, one gang switch*1 | |
Plumping and Sanitary | 26 | Sanitary Wares | Wash basin, toilet, shower, faucet, mirror, towel rail, soap holder, water supply and drainage pipelines, etc. |
Fittings | 27 | Flashing Part | 0.5mm metal sheet, white color |
28 | Ground Channel | 0.8mm metal sheet, white color | |
Option | 29 | Awning | 50mm thick glass wool awning, 1150mm wide |
PRODUCT DISPLAY
PRODUCT ADVANTAGES
1.Flat package: The standard house can be packed in one package, including roof structure,floor, wall panels, doors, windows and interior decoration.
2.Fast Installation: The standard house can be packed in one package for quick material collection and four workers can erect 5 units per day.
3.Economic transportation: 4sets of the flat package could replace the shipping space of one 20ft container to save the transport cost and time.
4.Bodily movement: the forklift pockets on the cabin structure enables forklift capability and the corner casting structure
enables lifting capability.
2.Fast Installation: The standard house can be packed in one package for quick material collection and four workers can erect 5 units per day.
3.Economic transportation: 4sets of the flat package could replace the shipping space of one 20ft container to save the transport cost and time.
4.Bodily movement: the forklift pockets on the cabin structure enables forklift capability and the corner casting structure
enables lifting capability.
CERTIFICATIONS
CUSTOMER VISIT
FACTORY WAREHOUSE
