Может использоваться для наружного мониторинга потоковой передачи видео в реальном времени RTSP TO RTMP RTMPS

Описание и отзывы

Трекер стоимости

Характеристики

The xstrive 4G RTMP/RTMPS Encoder is a professional high-definition audio and video encoding product with powerful functions. It is a new generation of RTSP to RTMP transcoding and streaming all-in-one machine. It has the characteristics of integrating software and hardware design and H.264/H.265 code stream mixed encoding and transcoding.

It can not only be used as an NVR to work independently locally,  but also be used as a streamer for real-time streaming of surveillance video streams, meeting the functions of cloud storage and real-time live viewing of surveillance video streams. Customers can build their own surveillance video cloud storage and surveillance live broadcast systems according to their own needs.  It supports HTTP/RTSP/RTMP/RTP/UDP-TS network input protocol and HTTP-FLV/RTSP/RTMP/UDP-TS/HLS/WS-FLV/WS-RAW/ONVIF network output protocol.

Device model	xswTVR-10M16CH4G/P
Network video input protocol	HTTP/RTSP/RTMP(S)/RTP/UDP-TS
Network video output protocol	HTTP-FLV/RTSP/RTMP(S)/UDP-TS/HLS/WS-FLV/WS-RAW/ONVIF
Input resolution	1080P\\1080I\\720P, 1600x1200\\1400x1050\\1440x900\\1280x1024\\1280x960\\1280x800\\1024x768\\800x600 etc.
Output Resolution	1920×1080/1280×720/1024×576/960×540/850×480/720×576/720×540/720×480/720×404/704×576/640×480/640×360 etc. Rate
Video formats	H264/AVC High/Main/Baseline Profile, H265/HEVC Main Profile MJPEG/JPEG Baseline
Input Resolution	1080P/1080I/720P/1600*1200/1400*1050/1440*900/1280*1024/1280*960/1280*800/1024*768/ 800*600, etc.
Output Resolution	1920*1080/1280*720/1024*576/960*540/850*480/720*576/720*540/720*480/720*404/704*576/ 640*480/640*360 etc. Rate
Ethernet	1000M, RJ45
Input video encoding format	H.264/H.265 encoding
Output video encoding format	H.264/H.265 encoding
Input audio encoding format	AAC/G.711/MP3/MP2/AC3
Output audio encoding format	AAC
Maximum number of network video channels	16
Maximum total code rate	10Mbit (specifically, it will vary due to different protocols and encoding formats)
Video recording	No Support
Control mode	network-based management mode, the IP address is 192.168.0.15, which can be upgraded remotely
Remote management	support remote modification of device parameters and remote playback of device recordings
Language	Chinese and English control interface
Operating temperature	-10 to 70 ℃
Relative Humidity	5% to 90%, non-condensing
Dimensions	9.1x3.5x7cm
Weight	89g
Power adapter	Input: 100-240V 50/60Hz AC, Output: 12V DC 2A

Q1,What is your shipping method?

A1, FedEx, UPS, DHL, TNT, EMS and other international express shipping are supported. Normally, it takes 3-7 days from China to you, we will choose the best way for you based on our historical data to ensure that the package is received safely and smoothly



Q2, Can I get some samples?

A2, yes, of course, we are honored to provide you some samples for testing, but the samples are not free. In order to ensure the correct and safe purchase of the product, we will provide an online test



Q3, Can you provide OEM service according to our requirements? Is it free?

A3, with our professional and experienced design team, we can replace your company's logo on the chassis, software interface and carton to provide OEM service



Q4, How about your warranty?

A4, 1 year warranty free repair or replacement. We provide online technical support through remote assistance, and repair services are provided by experienced after-sales specialists.
