Киоск аксессуаров core Промышленная материнская плата управления RK3399 6 ядро встроенное lvds hdm
- Категория: Motherboards >>>
- Поставщик: Guangdong,High,Praise,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 83.60 $* | 85.92 $* |
| Jul-16-2025 | 67.93 $* | 68.26 $* |
| Jun-16-2025 | 81.62 $* | 83.22 $* |
| May-16-2025 | 81.92 $* | 83.76 $* |
| Apr-16-2025 | 64.31 $* | 65.68 $* |
| Mar-16-2025 | 79.90 $* | 81.85 $* |
| Feb-16-2025 | 79.89 $* | 81.75 $* |
| Jan-16-2025 | 78.91 $* | 80.8 $* |
Характеристики
Product Features
Size | 135mm×95mm | ||||||
CPU | RK3399 6 Core ARM® 64bit ,frequency up to 2.0GHz Big.Little architecture: Dual Cortex-A72 + Quad Cortex-A53 | ||||||
GPU | Quad Core ARM Mali-T860 Support OpenGL ES 1.1/2.0 /3.0，OpenVG1.1，OpenCL，Directx11 | ||||||
Memory | On-board DDR3 2G high-spead dual channel Ram（4G optional | ||||||
Built-in Storage | On-board EMMC 8G 5.1 high-speed storage（MAX.128G optional） 1*TF slot，support MAX.128G TF card | ||||||
Display screen interface | LVDS interface（single double way，6bit，8bit，10bit），Support Max Resolution 1080P Support eDP 1.3(4 lines, 10.8Gbps)，Support HDMI Port，Support Max Resolution 4K×2K @60HZ Support two screen display asynchronously（LVDS+eDP，HD-MI+eDP，HD-MI+LVDS) | ||||||
OS | Android 7.1 (Ubuntu optional） | ||||||
Network support | 100M ethernet，Support WiFi/BT4.0，3G/4G port（MINI-PCIE） | ||||||
Touchscreen | On board I2C port（Support Multipoint capacitance touchscreen） USB Port（Support multipoint infrared touch，Multipoint touch，Multipoint resistance touch，Multipoint nano-membrane touch，Multipoint sound wave，Multipoint optics touch） | ||||||
Video display | Support wmv、avi、flv、rm、rmvb、mpeg 、ts、mp4 etc. | ||||||
Picture format | Support BMP、JPEG、PNG、GIF etc. | ||||||
USB | USB 3.0 ports，5 USB PH2.0-4P socket, USB-OTG support (ADB debugging) | ||||||
COM | 2* TTL (RS232 optional, UARTO optional) , 1*TTL debugging port | ||||||
GPIO | 4 way IO，input or output optional | ||||||
Audio output | 1*3.5mm earphone jack，1*PH2.0-2P MIC input jack Built-in 8R/5W×2 Amplifier，left right audio channel output | ||||||
Special function | Built-in RTC real-time clock，support timing turn-on/off | ||||||
Power supply | DC-12V | ||||||
Working Humidity | 0% ~ 95% (relative humidity, non-condensing) | ||||||
Operating Temperature | 0°-60° | ||||||
Product Category
Production Process
Packing Details : 20pcs/carton
Carton Size: 50*49*20 CM
Carton Size: 50*49*20 CM
