Машина для прокатки листового металла
US $10000
Машина для изготовления глиняной кровельной черепицы машина оцинкованной панели листов
- Категория: Tile Making Machinery >>>
- Поставщик: Henan,Chuangqin,Mechanical,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.61 $* | 0.99 $* |
| Aug-16-2025 | 0.3 $* | 0.68 $* |
| Jul-16-2025 | 0.32 $* | 0.63 $* |
| Jun-16-2025 | 0.8 $* | 0.98 $* |
| May-16-2025 | 0.34 $* | 0.60 $* |
| Apr-16-2025 | 0.9 $* | 0.89 $* |
| Mar-16-2025 | 0.95 $* | 0.47 $* |
| Feb-16-2025 | 0.54 $* | 0.6 $* |
| Jan-16-2025 | 0.23 $* | 0.23 $* |
Характеристики
Price for clay roof tile making machine galvanize roof panel roll forming machine plastic-roof-sheet-making-machine
Product Description
Its color plate appearance is smooth and beautiful, with uniform paint, high strength, and durability. Widely used in industrial and civil buildings, such as factories, warehouses, stadiums, exhibition halls, and theater roofs.
Corrugated sheet roll forming machine
1.Put all necessary parts on the right location,make the ground falttening.
2.Connect electric wires,use 6-8 mm² support line and keep grounding.
3.Fill hydraulic oil in the pump.not too full,three quarters are ok.
4.Feed raw materil into the machine slowly,make it run smoothly then automatic.
5.Pay attention to final sheet collection,do not scretch it or hurts people.
Price for clay roof tile making machine galvanize roof panel roll forming machine plastic-roof-sheet-making-machine
Technical paremeter
| Spindle material | 45 # steel, outer diameter 70-90mm |
| Roller material | 45 # steel hard chrome plated |
| Number of forming rows | 22 rows |
| Chain drive | chain, sprocket |
| Host power | 5.5kw |
| Forming speed | 8m - 12m/min |
| Voltage | 380V, 50Hz, three-phase |
| Frame material | 350 # H-shaped steel |
| Vertical plate | 14mm |
| Cutting mode | three piece medium plate cutter |
| Electric cabinet configuration | Tricrystal frequency converter, PLC control, pump station 4kw |
Price for clay roof tile making machine galvanize roof panel roll forming machine plastic-roof-sheet-making-machine
Detailed Images
Our Services
1.Installation video helping customer assembly
2.24 hours technical support by mobile or email
3.One years free warranty period
