Китайские Дешевые Маленькие компактные Новые запчасти гусеничные Бульдозеры shantui sd22 Nine prix dozer sd22e sd16 цена
- Категория: Bulldozers >>>
- Поставщик: Weifang,CP,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.3 $* | 0.5 $* |
| Aug-16-2025 | 0.75 $* | 0.84 $* |
| Jul-16-2025 | 0.13 $* | 0.40 $* |
| Jun-16-2025 | 0.81 $* | 0.54 $* |
| May-16-2025 | 0.26 $* | 0.77 $* |
| Apr-16-2025 | 0.58 $* | 0.41 $* |
| Mar-16-2025 | 0.82 $* | 0.77 $* |
| Feb-16-2025 | 0.61 $* | 0.97 $* |
| Jan-16-2025 | 0.49 $* | 0.58 $* |
Характеристики
Product Description
Specification
item | value |
Applicable Industries | Construction works , Energy & Mining |
Showroom Location | Egypt, Philippines, Brazil, Peru, Saudi Arabia, Pakistan, Mexico, Kenya, Chile, Algeria, South Africa, Kazakhstan, Nigeria, Uzbekistan, Tajikistan, Australia, Morocco |
Video outgoing-inspection | Provided |
Machinery Test Report | Provided |
Marketing Type | Hot Product 2021 |
Warranty of core components | 3 years |
Core Components | Gearbox, Gear |
Place of Origin | China |
Brand Name | Shan tui |
Model Number | SD22 |
Condition | New |
Moving Type | Crawler Bulldozer |
Machine Weight | 24600KG |
Dimension(Long * Breadth * High) | 6060*4200*3402mm |
Dozing Capacity | 7.8m³ |
Warranty | 3 years |
Hydraulic Cylinder Brand | Orignal |
Hydraulic Pump Brand | Orignal |
Hydraulic Valve Brand | Orignal |
UNIQUE SELLING POINT | High load Moment |
Engine | Cummins NT855-C280S10 |
Gross power | 175kW(235hp), 1800rpm |
Displacement | 14.01L |
Max. theoretical traction force | 450kN |
Track gauge | 2000mm |
Fuel capacity | 450L |
Ripper type | Three-shank ripper |
Weight | 2600kg |
Max. ripping depth | 666mm |
Ripper width | 2158mm |
ENGINE | SD22/W | SD22C | SD22F | SD22D/E | SD22S | SD22R | |||||
Engine | Cummins NT855-C280S10 | ||||||||||
Emission | China-I | ||||||||||
Rated revolution | 1800rpm | ||||||||||
Gross power | 175kW(235hp)@1800rpm | ||||||||||
Net power | 162kW(220hp)@1800rpm | ||||||||||
Number of cylinder-bore X stroke | 6-140 X 152mm | ||||||||||
Displacement | 14.01L | ||||||||||
Max. torque | 1080N.m@1300rpm | ||||||||||
Cooling system | Mechanic fan | ||||||||||
DRIVE SYSTEM | SD22/W | SD22C | SD22F | SD22D/E | SD22S | SD22R | |||||
Drive system | Manufactured by SHANTUI, with high working efficiency, low breakdown rate; torqflow transmission, 3 gears forward and 3 gears backward. | ||||||||||
Traveling speed Forward | F1:3.6km/h R2:6.5km/h F3:11.2km/h | ||||||||||
Traveling speed Backward | R1:4.3km/h R2:7.7km/h R3:13.2km/h | ||||||||||
Max. theoretical traction force | 450kN | ||||||||||
Torque converter | 3-element, single stage, 1-phase | ||||||||||
Transmission | Planetary gear and torqflow transmission hydraulically actuated, forced lubrication | ||||||||||
Central drive | Spiral bevel gear, single-stage speed reduction, splash lubrication | ||||||||||
Steering clutch | Wet multiple disc, disc spring loaded, hydraulically actuated, hand operated,Interconnected with steering brake. | ||||||||||
Brake clutch | Wet, contracting band, foot operated with hydraulic booster | ||||||||||
Final drive | Spur gear, double reduction ,splash lubrication | ||||||||||
CHASSIS SYSTEM | SD22/W | SD22C | SD22F | SD22D/E | SD22S | SD22R | |||||
Type | Swing type of sprayed beam,suspended structure of equalizer bar | ||||||||||
Track shoe type | Single grouser | Wetland type | |||||||||
Track gauge | 2000mm | 2000mm | 2000mm | 2000mm | 2250mm | 2250mm | |||||
Width of track shoe | 560/610/660mm | 660mm | 610/660mm | 560/610/660mm | 910mm | 910mm | |||||
Track grounding length | 2430mm | 2430mm | 2430mm | 3050mm | 3480mm | 3480mm | |||||
Track grounding area | 28727cm² | 40935cm² | 40935cm² | 38317cm² | 71476cm² | 71476cm² | |||||
Number of track shoe | 38pcs/side | 38pcs/side | 38pcs/side | 41pcs/side | 45pcs/side | 45pcs/side | |||||
Grounding pressure (standard configuration) | 66kPa | 57.5kPa | 64kPa | 66kPa | 36kPa | 35.2kPa | |||||
Number of carrier roller | 2 pcs/side | ||||||||||
Number of track roller | 6pcs/side | 7pcs/side | 8pcs/side | ||||||||
Pitch | 206mm | ||||||||||
REFILL CAPACITY | SD22/W | SD22C | SD22F | SD22D/E | SD22S | SD22R | |||||
Fuel capacity | 450L | 450L | 450L | 450L | 450L | 450L | |||||
Coolant liquid capacity | 79L | 79L | 79L | 79L | 79L | 79L | |||||
Engine oil capacity | 45L | 45L | 45L | 45L | 45L | 45L | |||||
Transmission | 122L | 122L | 122L | 122L | 122L | 122L | |||||
Drive axle | 110L | 110L | 110L | 110L | 110L | 110L | |||||
Final drive | 82L/side | 82L/side | 82L/side | 102L/side | 102L/side | 102L/side | |||||
OPERATING WEIGHT | SD22/W | SD22C | SD22F | SD22D/E | SD22S | SD22R | |||||
Standard | 23450kg | 24000kg | 24700kg | 24600kg | 25700kg | 26000kg | |||||
BLADE | SD22/W | SD22C | SD22F | SD22D/E | SD22S | SD22R | |||||
Blade type | Coal-U | Straight-tilt/Angle/Semi-U/U | Straight-tilt | Waste handing | |||||||
Blade capacity | 8m³ | 4.6/3.4/5.8/6.7m³ | 5.2m³ | 11.8m³ | |||||||
DIMENSION | SD22/W | SD22C | SD22F | SD22D/E | SD22S | SD22R | |||||
Machine height (without ROPS) | 3402mm | 3402mm | 3402mm | 3402mm | 3402mm | 3402mm | |||||
Track grouser height | 72mm | 72mm | 72mm | 72mm | 123mm (Wetland type) | ||||||
Ground clearance | 405mm | 405mm | 405mm | 405mm | 513mm | 513mm | |||||
Machine length (without draw bar) | 6027mm | 5462mm | 5462mm | 5712mm | 6257mm | 6257mm | |||||
Machine length (with draw bar) | 6060mm | 5495mm | 5495mm | 5745mm | 6290mm | 6290mm | |||||
Max. lifting height of blade | 1210mm | 1210mm | 1210mm | 1210mm | 1330mm | 1330mm | |||||
Max. digging depth of blade | 540mm | 540mm | 540mm | 540mm | 550mm | 550mm | |||||
Digging angle of blade | 55°±3°(deg.) | ||||||||||
Blade width | 4200mm | 3725/4365/3800/3725mm | 4365mm | 4365mm | |||||||
Blade height | 1350mm | 1315/1055/1343/1374mm | 1248mm | 1885mm | |||||||
Width from end of left track shoe to end of right track shoe (standard) | 3000mm | 3000mm | 3000mm | 3000mm | 3800mm | 3800mm | |||||
RIPPER | SD22/W | SD22C | SD22F | SD22D/E | SD22S | SD22R | |||||
Type | Three-shank ripper | Single shank ripper | |||||||||
Weight | 2600kg | 2450kg | |||||||||
Max. ripping depth | 666mm | 695mm | |||||||||
Max. lifting height | 555mm | 515mm | |||||||||
Ripper length (at deepest ripping) | 1781mm | 1974mm | |||||||||
Ripper width | 2158mm | 1426mm | |||||||||
Departure angle (at highest lifting) | 25.5° | 25.5° | |||||||||
Ripping width | 2000mm | 2000mm/106mm | |||||||||
Distance between ripper teeth | 930mm | - | |||||||||
