Б/у мусорный грузовик 10 куб. М кухонный уплотнитель в

Cabin

Left rudder/half row

Whole vehicle main dimensions

Overall dimensions (LxWxH)mm

8255×2460×2820

Wheel base(mm)

4800

Weight data

Curb weight(kg)

5440

Gross vehicle weight（kg）

22000

Persons in cab (persons)

2

Engine

Model

YC6A240-33

Emissions standards

Euro III

Displacement（L）

7.255L

Rated Power

177

Max torque

900

Gearbox

Model

8JS105TA

Clutch

Type

Single dry diaphragm spring

Front axle

Type

5.5.T

Rear axle

Type/Main reducetion ratio

10T/4.875

Suspension

Front suspension/Leaf spring number

Non-independent suspension longitudinal plate spring /10

Rear suspension/Leaf spring number

Non-independent suspension longitudinal plate spring /10+8

Brake system

Service brake

Drum-type pneumatic brake

Parking brake

Barely able to brake

Basic equipment

Hydraulic Turnover/Cruise + 135A.H Battery/Manual Air Conditioners/Tuberless Tire (Inch) 11R22.5/ Manual Doors, Windows and
Rearview Mirrors /MP3 / Power Steering/Knit Shock Absorber Seat (Spring)

Upper

Tank material

Q235A carbon steel

Loading capacity

10CBM

Uploading and Loading cycling time

≤50s

Features

1.energy conservation and environmental protection
2.low failure rate and low operating cost
3. easy maintenance

Instruction

1. Garden tanks , the effective volume reaches 90%
2. Equipped with rubbish drum lifting system , the system has dustbin lock structure make sure that loading and unloading safe and
reliable.
3. Equipped with hydraulic system and operating system.
4. The feature : high level of automation , reliable working , well sealed , bulk loading , easy control and good environmental
protection.

Color &Painting

According to customer's requirements
