Nvvv NDR-240-24 240W 24V 10A импульсивный источник питания постоянного тока переменного dc промышленная din-рейку импульсный
- Категория: Industrial Power Supplies >>>
- Поставщик: Zhejiang,Junlin,Electric,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 24.97 $* | 25.94 $* |
| Aug-20-2025 | 24.55 $* | 25.48 $* |
| Jul-20-2025 | 20.55 $* | 21.59 $* |
| Jun-20-2025 | 23.73 $* | 24.84 $* |
| May-20-2025 | 20.87 $* | 21.13 $* |
| Apr-20-2025 | 23.41 $* | 24.10 $* |
| Mar-20-2025 | 23.59 $* | 24.21 $* |
| Feb-20-2025 | 22.20 $* | 23.33 $* |
| Jan-20-2025 | 22.12 $* | 23.52 $* |
Характеристики
Product Description
Specification
NDR-240 240W Rail Type Switching Power Supply | ||||||||
Project | NDR-240-24 | NDR-240-48 | ||||||
Output | DC VOLTAGE | 24V | 48V | |||||
RATED CURRENT | 10A | 5A | ||||||
CURRENT RANGE | 0~10A | 0~5A | ||||||
RATED POWER | 240W | 240W | ||||||
RIPPLE & NOISE | 150m Vp-p | 150m Vp-p | ||||||
VOLTAGE ADJ. RANGE | 24~28V | 48~55V | ||||||
VOLTAGE TOLERANCE | ±1.0% | ±1.0% | ||||||
LINE REGULATION | ±0.5% | ±0.5% | ||||||
LOAD REGULATION | ±1.0% | ±1.0% | ||||||
SETUP RISE TIME | 1500ms, 100ms/23OVAC | 3000ms, IOOms/115VAC at full load | ||||||
HOLD UP TIME (Typ.) | 28ms/23OVAC 22ms/115VAC at full load | |||||||
Input | VOLTAGE RANGE | 90~264VAC 127~370VDC | ||||||
FREQUENCY RANGE | 47~63Hz | |||||||
POWER FACTOR (Typ.) | PF>0.98/115VAC. PF>0.95/230VAC at lull load | |||||||
EFFiCIENCY (Typ.) | 88% | 89% | ||||||
AC CURRENT (Typ.) | 2.5A/115VAC 1.3A/23OVAC | |||||||
INRUSH CURRENT (Typ.) | 2OA/1I5VAC 35A/230VAC | |||||||
LEAKAGE CURRENT | ＜1mA/240VAC | |||||||
Protect | OVERLOAD | 105 — 130% rated output power | ||||||
OVER VOLTAGE | 29~33V | 56~65V | ||||||
Protection type : Constant current limiting, recovers automatically after taut condition is removed | ||||||||
OVER TEMPERATURE | Shut down o/p voltage, recovers automatically after temperature goes down | |||||||
Environmental | WORKING TEMP | -20℃～+70℃ | ||||||
WORKING HUMIDITY | 20-95% RH non-condensing | |||||||
STORAGE TEMP., HUMIDITY | -40℃～+85℃；10%～95RH | |||||||
TEMR COEFFICIENT | ±0.03%∫(0- 5O℃) | |||||||
VIBRATiON | ComponenLlo - 500Hz, 2G lOmin/1cyde, 60min. each along X, V. Z axes: Mounting: Compliance to IEC60068-2-6 | |||||||
Safety | SAFETY STANDARDS | UL508, TUV BS EN(EN62368-1. EAC TP TC 004, BSMI CNS14336-1 approved :(meet BS ENIEN6O2O4-1) | ||||||
WITHSTAND VOLTGE | O/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | |||||||
Other | MTBF | 230.2K hrs min. MIL-HDBK-217F (25 ℃) | ||||||
DIMENSION | 63*125*113mm (W*H*D) | |||||||
PACKING | 1Kg; l2pcs/l3Kg,/1.22CUFT | |||||||
Company Profile
Our Team
Packaging & Shipping
FAQ
Q1:How many Voltage you can supply?
A: 12v,24v,48v,50,60,110v(Depend on items).
A: 12v,24v,48v,50,60,110v(Depend on items).
Q2：Can I have a sample order?
A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable. At the same time, we have overseas warehouses so that you can get the products faster.
A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable. At the same time, we have overseas warehouses so that you can get the products faster.
Q3：Do you have any MOQ limited for the order?
A: Low MOQ, 1pc for sample checking is available.
A: Low MOQ, 1pc for sample checking is available.
Q4：How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx, or EMS. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
A: We usually ship by DHL, UPS, FedEx, or EMS. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5：Do you offer a guarantee for the products?
A: Yes, we offer a warranty on our products.
A: Yes, we offer a warranty on our products.
Q6: How to deal with the faulty?
A: Firstly, our products are produced in a strict quality control system and the defective rate will be less. Secondly, during the guarantee period, we will send new products with new orders for small quantities. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to the real situation
A: Firstly, our products are produced in a strict quality control system and the defective rate will be less. Secondly, during the guarantee period, we will send new products with new orders for small quantities. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to the real situation
