Избыточный погружной блок питания Zumax APW12


Поделиться:


Цена:300,00 $ - 308,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-18-2025 357.25 $* 375.46 $*
Aug-18-2025 354.94 $* 372.34 $*
Jul-18-2025 297.67 $* 312.10 $*
Jun-18-2025 348.0 $* 365.57 $*
May-18-2025 303.82 $* 318.63 $*
Apr-18-2025 342.88 $* 359.16 $*
Mar-18-2025 339.59 $* 356.62 $*
Feb-18-2025 336.67 $* 353.79 $*
Jan-18-2025 333.61 $* 350.0 $*

Характеристики



Product Description


ZUMAX APW12-10000W  (IMMERSION)
Model No.:
APW12 psu 10000W
OUT1
DC voltage(直流电压)
12V-15V
Rated Current额定电流(220V input)
650A
Ripple& Noise(纹波与噪声)
<1%
Source Regulation(源调整率)
<1%
Load Regulation(负载调整率)
<1%
Setup,rise time(启动、上升时间)
2s
Power off protection Trip time(掉电保持时间)
>10mS
OUT2
DC voltage(直流电压)
12.3V
Rated Current额定电流(220V input)
20A
Ripple& Noise(纹波与噪声)
<1%
Voltage Accuracy(电压精度)
12.2V---12.4V
Source Regulation(源调整率)
<1%
Load Regulation(负载调整率)
<1%
Setup,rise time(启动、上升时间)
<2s
Power off protection Trip time(掉电保持时间)
>10mS
Input
Voltage Range(电压范围)
200-280V AC
Frequency Range(频率范围)
47-63Hz
Power Factor(功率因数)
>0.99(full load)
Leakage(漏电流)
<1.5mA(220V 50Hz)
Protection
Low-voltage Input(输入欠压保护值)
80-89V AC
Output Short Circuit(输出短路)
Yes
Overheat Protection(过温保护)
Yes
Over-current Output(输出过流保护值)
300A-380A(protection value varies under different voltage)
Environment
Operating Temperature(工作温度)
-20-45℃
Operating Humidity(工作湿度)
20%-90%RH(non-condensing无结露
Altitude(海拔)
<2000m
Structure
Dimensions(尺寸)
255mm*252mm*63mm
Weight(净重)
3.45Kg
Others
Cooling Mode(冷却方式)
Immerson type
Noise(噪音)
/




Company Profile




Dongguan Worldwide Electronic Technologies Co., Ltd. was established in 2010, located in Dongguan City, owning 4,300 square meters for factory.

We are specialized in ATX power supply for desktop, FLEX power supply, and others which are applicable in fields of ITX, POS, all in one machine, the projector, industrial computer, such as Flex, TFX, Micro, 1U, 2U, DC-ATX power supply and so on. Also, we can special customize as your particular requirements.

As fierce competition and decline market in power industry, our business increase as with reliable technology, good material and creative mind, helping us to win a sound reputation from our customers. The principle we insist on is that no loss, no inferior material, which makes cost higher and may cause the first cooperation missing between us. Good evaluation and safe guarantee for consumer is the basic foundation for our enterprise life.

There is an engineer team with rich experience and high efficiency. They are filled with enthusiasm to fulfill your PSU design.

In all, your demands are our future. Serving you is our honor.






FAQ


1. who are we?
We are based in Guangdong, China, start from 2010,sell to Domestic Market(30.00%),North America(20.00%),Eastern Asia(15.00%),Western Europe(10.00%),Southern Europe(10.00%),South America(5.00%),Northern Europe(5.00%),South Asia(5.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Switching Power Supply

4. why should you buy from us not from other suppliers?
1, Professional R&D team, most of them from famous Taiwan power companies.
2, The most advanced Chroma 6000 power supply AUTO test system to control quality.
3, Our trade team have 7 years experience

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,Cash;
Language Spoken:English,Chinese


Contact
Welcome to Zumax
if any problem pls feel free to let me know
My Name is Zoe :)
whatsapp +86 13546934197
