Nvvv LPV-100w-24v водонепроницаемый портативный источник питания переменного тока модуль 24V блок 100W 4A
- Категория: Industrial Power Supplies >>>
- Поставщик: Zhejiang,Junlin,Electric,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 14.4 $* | 15.16 $* |
| Aug-17-2025 | 14.53 $* | 15.63 $* |
| Jul-17-2025 | 12.78 $* | 13.36 $* |
| Jun-17-2025 | 14.60 $* | 15.24 $* |
| May-17-2025 | 12.49 $* | 13.39 $* |
| Apr-17-2025 | 14.82 $* | 15.58 $* |
| Mar-17-2025 | 14.2 $* | 15.87 $* |
| Feb-17-2025 | 13.41 $* | 14.71 $* |
| Jan-17-2025 | 13.68 $* | 14.11 $* |
Характеристики
Product Description
Specification
LPV-100 100W Waterproof Irrigation Switch Power Supply | ||||||||||
Project | Technical index | |||||||||
Output | DC voltage | 12V | 24V | |||||||
Rated current | 8.5A | 4.2A | ||||||||
Rated power | 102W | 100.8W | ||||||||
Ripple and noise ① | ＜120mV | ＜150mV | ||||||||
Voltage accuracy | ±5% | |||||||||
Load adjustment rate | ±2% | |||||||||
Linear adjustment rate | ±1% | |||||||||
Starting and rising time | 2000ms、25ms、15ms ：115VAC 2000ms、25ms、50ms ：230VAC | |||||||||
Input | Voltage range / frequency | 90-264VAC 47Hz～63Hz；127VDC～370VDC | ||||||||
Efficiency (typical) ② | ＞85% | ＞88% | ||||||||
Working current | 2.2A/110VAC 1.2A/230VAC | |||||||||
Impulse current | 220VAC： 60A | |||||||||
Protect | overload protection | 105%-135% Protection type: burping mode, automatic return to normal after removing abnormal conditions | ||||||||
Overvoltage protection | ≥ 115% - 145% protection type: close output, restart and automatically return to normal | |||||||||
Function | Working temperature and humidity | -30℃～+70℃；20%～90RH | ||||||||
Storage temperature and humidity | -40℃～+85℃；10%～95RH | |||||||||
Safety regulations | Withstand voltage | Input output: 3kvac for 1 minute | ||||||||
Leakage current | input shell When 240VAC＜2.5mA | |||||||||
Insulation impedance | Input output, input shell, output shell: 500VDC / 100M Ω | |||||||||
Other | Size | 163*68*42mm | ||||||||
Net weight / gross weight | 900/1200g | |||||||||
Company Profile
Packaging & Shipping
FAQ
Q1:How many Voltage you can supply?
A: 12v,24v,48v,50v,60v,110v(Depend on items).
A: 12v,24v,48v,50v,60v,110v(Depend on items).
Q2：Can I have a sample order?
A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable. At the same time, we have overseas warehouses so that you can get the products faster.
A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable. At the same time, we have overseas warehouses so that you can get the products faster.
Q3：Do you have any MOQ limited for the order?
A: Low MOQ, 1pc for sample checking is available.
A: Low MOQ, 1pc for sample checking is available.
Q4：How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx, or EMS. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
A: We usually ship by DHL, UPS, FedEx, or EMS. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5：Do you offer a guarantee for the products?
A: Yes, we offer a warranty on our products.
A: Yes, we offer a warranty on our products.
Q6: How to deal with the faulty?
A: Firstly, our products are produced in a strict quality control system and the defective rate will be less. Secondly, during the guarantee period, we will send new products with new orders for small quantities. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to the real situation.
A: Firstly, our products are produced in a strict quality control system and the defective rate will be less. Secondly, during the guarantee period, we will send new products with new orders for small quantities. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to the real situation.
