18 м 20 25 30 35 телескопическая антенна мачта для Hf Vhf Uhf и Shf Беспроводная
- Категория: Telecommunication Towers & Accessories >>>
- Поставщик: Henan,Yangbo,Lightning,Protection,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 583.43 $* | 595.84 $* |
| Jul-16-2025 | 473.27 $* | 482.66 $* |
| Jun-16-2025 | 574.16 $* | 585.62 $* |
| May-16-2025 | 569.80 $* | 580.62 $* |
| Apr-16-2025 | 454.81 $* | 463.73 $* |
| Mar-16-2025 | 560.63 $* | 571.42 $* |
| Feb-16-2025 | 555.12 $* | 566.76 $* |
| Jan-16-2025 | 551.73 $* | 562.14 $* |
Характеристики
SPECIFICATION
Type | Retracted Height(M) | Raised Height(M) | Diameter(mm) | Weight of Hand Crank(kg) | Weight of Motorized(kg) | |||||||||||
Min | Max | Al.Alloy | Carbon Fiber | Al.Alloy | Carbon Fiber | |||||||||||
YBK-5S | 1.60 | 5 | 50 | 80 | 23 | 18 | 35 | 30 | ||||||||
YBK-6S | 1.60 | 6 | 60 | 105 | 24 | 20 | 38 | 34 | ||||||||
YBK-8S | 2.20 | 8 | 60 | 105 | 26 | 22 | 45 | 41 | ||||||||
YBK-10S | 2.20 | 10 | 50 | 105 | 28 | 24 | 55 | 50 | ||||||||
YBK-12S | 2.25 | 12 | 40 | 105 | 30 | 30 | 62 | 56 | ||||||||
YBK-14S | 2.30 | 14 | 40 | 120 | 42 | 40 | 75 | 67 | ||||||||
YBK-15S | 2.40 | 15 | 40 | 140 | 47 | 44 | 80 | 71 | ||||||||
YBK-16S | 2.45 | 16 | 40 | 160 | 51 | 47 | 84 | 74 | ||||||||
YBK-18S | 2.70 | 18 | 50 | 160 | 54 | 49 | 90 | 79 | ||||||||
YBK-20S | 2.70 | 20 | 40 | 160 | 57 | 52 | 96 | 84 | ||||||||
YBK-30S | 2.90 | 30 | 40 | 220 | 130 | 125 | 220 | 210 | ||||||||
Note: 1) Top loading: 3kg or Customized. 2) Materials: Al Alloy or Carbon Fiber. 3) Wind Resistance: 27m/s or Customized. 4) Driven Method: Hand Crank or Motorized by Electricity | ||||||||||||||||
FUNCTIONS AND FEATURES
FAQ
1.What is the wind resistance rating when fully extended?
0.4kn/m², and 0.7kn/m²is customizable.
2. Do you have an option with 30-40kg payload?
Our payload is 3kg-30kg, others are customizable.
3. When do we need steel rope to fix the mast?
Generally, when the height is more than 6m, steel rope is necessary.
4. Are only 220V available, or 12v can be ordered?
Our mast is at 220V, others is customizable ?
5. Are additional cable retraction mechanisms available?
Of course
6. Are motorized rotational platforms are available?
Yes, you can equip it with a PTZ.
7.Do you have them in stock?
No, but generally, we can delivery within 7 days.
8. Can the mast be stable mid section ?
Yes, it can be stopped anywhere.
0.4kn/m², and 0.7kn/m²is customizable.
2. Do you have an option with 30-40kg payload?
Our payload is 3kg-30kg, others are customizable.
3. When do we need steel rope to fix the mast?
Generally, when the height is more than 6m, steel rope is necessary.
4. Are only 220V available, or 12v can be ordered?
Our mast is at 220V, others is customizable ?
5. Are additional cable retraction mechanisms available?
Of course
6. Are motorized rotational platforms are available?
Yes, you can equip it with a PTZ.
7.Do you have them in stock?
No, but generally, we can delivery within 7 days.
8. Can the mast be stable mid section ?
Yes, it can be stopped anywhere.
