Характеристики



INTRODUCTION.
Product: Rapid Breathalyzer
Model: A3


1. Introduction
The Rapid Breathalyzer is an alcohol test device with fuel cell technology, which is able to detect the breath of alcohol. The Breathalyzer also features a traffic wand design, it’s ideal for traffic management and emergency direction in all types of assignments.
The Breathalyzer has a non-slip textured grip with a wrist strap, it provides red, white, flash and red/white alternating
selections. With multiple color & flash combinations, alarm and vibration, the alcohol test result can be easily found in the field. In addition, The Breathalyzer is able to upload the test result to the backend system in real-time after the alcohol detected, which is able to trigger the body camera automatically into recording mode through the cellular network.
2. Feature
* Traffic Wand with White and Red Lighting Option;
* Voice & Light Alarm;
* 16mm Fuel Cell Sensor;
* 1.3 inch LCD Color Display;
* Test Result Uploading to Server via Cellular;
* Live Location via Cellular;
* Interaction with Body Camera via Cellular;










Overview
(1) Command light bulb
(2) LCD screen
(3) Test key/OK key
(4) Light key/down key
(5) Battery cover
(6) TypeC interface/SIM interface (network version)
(7) Menu key/Return key
(8) Horn hole
(9) Ring soft light
(10) Air intake








Item.
Button
Description
1
Test
Press and hold it for 2 seconds to power on/off.
Press it to start alcohol test.
Press it to confirm in menu mode.
2
Light
Switch to multiple light options in standby mode.
Press it to switch to next in menu mode.
3
Menu
Press and hold it to enter menu mode.
Press it to return.


Item.
Operation
Voice
1
Press “Test button”
"Start the test, please blow into the breathalyzer"
2
Test completed
"Alcohol detected, please cooperate with further testing" or "No alcohol, thank you for your cooperation"
3
Low battery
“Low battery”


























6. Function
6.1. Rapid Test
Press the TEST BUTTON to prepare to test, Blow into the Breathalyzer to start testing after a voice reminder was given. The test result will be displayed after 5 seconds, and the test record will be saved locally.




6.2. Alarm
When the test result exceeds the preset value (Preset value is customizable in the menu, the default is 20mg/100ml), the result is displayed in different colors, and the light will continue to flash.




6.3. Traffic Wand
With multiple color & flash combinations, it provides red, white, flash and red/white alternating selections.

6.4. Data Export
The test result can be exported to the PC via the application.

6.5. Result Uploads to the Server(Optional)
The Breathalyzer supports NB IoT Simcard, the test result can be automatically uploaded to the Backend System.

6.6. Low Battery Alarm
When the power supply voltage is lower than the low voltage, the Breathalyzer is be able to signal an alarm.

6.7. Continuous Testing
The Breathalyzer is able to run a test for more than 500 times continuously by using the built-in power supply.

6.8. Accuracy
The accuracy meets the following specification


Distance
(mm)
Blow Time (seconds)
 Alcohol Concentration C/(mg/100ml, BAC)
Deviation
(mg/100ml, BAC)
50
5
20
±10


6.9. Sensitive
The sensitive meets the following specification


Distance
(cm)
Blow Time (seconds)
 Alcohol Concentration C/(mg/100ml, BAC)
 Result
(mg/100ml, BAC)
5
5
5
1mg/100ml
5
5
0
0mg/100ml


6.11. Save Test Result Locally
The test result can be stored locally with a unique serial number. The storage can ensure that at least 10,000 results can be stored, and the data is tamper-proof.

6.12. Test Range
The test meets the range of 0-100mg/100ml, BAC.

6.13. Accuracy
1mg/100ml.

6.14. Live Location (Optional)
The Breathalyzer features live location if the cellular is enabled, the deviation of the location is not greater than 15m, and the
location update frequency is not less than 1Hz.

6.15. Interaction with Body Camera (Optional)
The Breathalyzer is able to upload the test result to the backend system in real-time after the alcohol detected, which is able to
trigger the body camera automatically into recording mode through the cellular network.

7. Technical Specification


Item.
Content
Description
1
Sensor
16mm Fuel Cell
2
Display
1.3 inch LCD Screen
3
Range
0~120mg/100ml
4
Accuracy
1mg/100ml
5
Test Time
5 Seconds, configurable from 1 to 15 seconds
6
Recalibration
3~5 seconds
7
Pump Method
Continuous pumping
8
Volume
>0.6L/min
9
USB
Type-C
10
Battery
Replaceable, 18650 2600mAh
11
Battery Life
>500 Times
12
Charging
5V 2A Adapter, ≤ 2.5 hours
13
Dimension
400*φ40mm
14
Weight
≤ 300g
15
Magnet
Support
16
High/Low Temperature Working Condition
40℃ and 0℃
17
Cellular Module
Optional, It is not included in the standard device.
