Можжевельник SCBE3-MX-S MX Серии роутеры карту в MX960

SCBE3-MX LEDs

OK/FAIL—A green LED indicates the board is OK. A red LED indicates the board has failed. If the LED is not lit, the SCBE3-MX is offline.

FABRIC ACTIVE—A green LED indicates the switch fabric on this board is in Active mode.

FABRIC ONLY—A green LED indicates the switch is in fabric-only mode and on slot 8.

XGE Port LINK—Indicates the status of the respective SFP+ interface.

GPS EXT CLK—Indicates the status of the GPS clocking interface. If the LED is green, the link is OK. If the LED is blinking amber, there is activity on the clocking interface.

SCBE3-MX Weights and Dimensions

Physical:

•


  Weight: 13.6 lb (6.2 kg)





•


  Width: 15.7 in (39.87 cm)





•


  Depth: 21.2 in (53.85 cm)





•


  Height: 1.2 in (3.05 cm)




Shipping box:

•


  Weight: 19.9 lb (9.03 kg)





•


  Width: 24.5 in (62.2 cm)





•


  Depth: 29.5 in (74.93 cm)





•


  Height: 7.5 in (19.05 cm)




SCBE3-MX Power and Cooling Requirements

For efficient and reliable power and cooling, you must install MX-series high-capacity power supplies and fan trays in the MX chassis. Additionally, for the MX960, you must install a high-capacity filter tray.
