Калиброванный топливный бак из нержавеющей стали ss304
US $68.00-$74.00
Датчик уровня радара с
- Категория: Level Measuring Instruments >>>
- Поставщик: Hangzhou,Asmik,Sensors,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.55 $* | 0.24 $* |
| Aug-17-2025 | 0.63 $* | 0.77 $* |
| Jul-17-2025 | 0.86 $* | 0.83 $* |
| Jun-17-2025 | 0.24 $* | 0.26 $* |
| May-17-2025 | 0.1 $* | 0.94 $* |
| Apr-17-2025 | 0.46 $* | 0.7 $* |
| Mar-17-2025 | 0.64 $* | 0.40 $* |
| Feb-17-2025 | 0.91 $* | 0.37 $* |
| Jan-17-2025 | 0.93 $* | 0.3 $* |
Характеристики
Product Description
MIK-RD908 Radar level meter | MIK-RD908 Radar level meter | |
Application conditions | River、Reservoir、Mudflat | |
Range | 0-70m | |
Frequency range | 26GHz | |
Accuracy | ±3mm | |
Process connection | G1 1/2" screw/support/flange | |
Signal output | 4-20mA (with HART)、RS485 | |
Protection level | IP67 | |
MIK-RD901 Corrosive radar level meter | ||
Application conditions | Various strongly corrosive liquids | |
Range | 0-10m | |
Frequency range | 26GHz | |
Accuracy | ±5mm | |
Process temperature | -40~130 ℃ | |
Process pressure | -0.1 ~ 0.3MPa | |
Protection level | Screw/flange | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD902 Radar level meter for temperature/pressure application | ||
Application conditions | Temperature/Pressure resistance、Mildly corrosive liquid | |
Range | 0-30m | |
Frequency range | 26GHz | |
Accuracy | ±5mm | |
Process temperature | -40 ~ 130 ℃ | |
-Process pressure | -0.1 ~ 0.3MPa | |
Protection connection | Screw/flange | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD903 Radar level meter | ||
Application conditions | Solid、dust、crystallization、condensation | |
Range | 0-70m | |
Frequency range | 26GHz | |
Accuracy | ±15mm | |
Process temperature | -40 ~ 130℃ (250℃) | |
Process pressure | -0.1 ~ 4.0MPa (flat) | |
-0.1 ~ 0.3MPa (flange direction) | ||
Protection connection | Universal flange | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD904 Radar level meter | ||
Application conditions | Solid、dust、crystallization、condensation | |
Range | 0-80m | |
Frequency range | 26GHz | |
Accuracy | ±15mm | |
Process temperature | -40 ~ 130℃ (250℃) | |
Process pressure | -0.1 ~ 0.3MPa | |
Protection connection | Screw/flange | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD801 Radar level meter | ||
Application conditions | Liquid、Mildly corrosive liquid | |
Range | 0-20m | |
Frequency range | 6GHz | |
Accuracy | ±10mm | |
Antenna | Rod antenna (PP/PTEE) | |
Process temperature | -40 ~ 130 ℃ | |
Process pressure | -0.1 ~ 0.3MPa | |
Protection connection | Screw/flange (optional) | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD802 Radar level meter | ||
Application conditions | Strongly corrosive liquid | |
Range | 0-20m | |
Frequency range | 6GHz | |
Accuracy | ±10mm | |
Antenna | Rod antenna (PTEE) | |
Process temperature | -40 ~ 130 ℃ (180℃) | |
Process pressure | -0.1 ~ 1.6MPa | |
Protection connection | Flanging flange | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD803 Radar level meter | ||
Application conditions | Volatile liquid under pressure | |
Range | 0-35m | |
Frequency range | 6GHz | |
Accuracy | ±10mm | |
Process temperature | -40 ~ 130 ℃ (250℃) | |
Process pressure | -0.1 ~ 4MPa | |
Protection connection | Flanging flange | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD902T Radar level meter | ||
Application conditions | Corrosive liquids、steam、volatile liquids | |
Range | 0-20m | |
Frequency range | 26GHz | |
Accuracy | ±3mm | |
Process temperature | -40 ~ 150 ℃ | |
Process pressure | -0.1 ~ 2.0MPa | |
Protection connection | Flange | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD701 Guided wave radar level meter | ||
Application conditions | Liquid、solid | |
Range | 0-30m | |
Frequency range | 500MHz-1.8GHz | |
Accuracy | ±10mm | |
Antenna | Rod antenna or single cable antenna | |
Process temperature | -40 ~ 130 ℃ (250℃) | |
Process pressure | -0.1 ~ 4.0MPa | |
Protection connection | Flanging flange | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD702 Guided wave radar level meter | ||
Application conditions | Liquid、strongly corrosive liquid | |
Range | 0-20m | |
Frequency range | 500MHz-1.8GHz | |
Accuracy | ±10mm | |
Antenna | Rod antenna or all-four fluorine cable antenna | |
Process temperature | -40 ~ 130 ℃ (220℃) | |
Process pressure | -0.1 ~ 4.0MPa | |
Protection connection | Screw/flange | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD703 Guided wave radar level meter | ||
Application conditions | Solid (cement storage) | |
Range | 0-30m | |
Frequency range | 500MHz-1.8GHz | |
Accuracy | ±10mm | |
Antenna | Double cable antenna | |
Process temperature | -40 ~ 130 ℃ | |
Process pressure | -0.1 ~ 0.6MPa | |
Protection connection | Screw/flange | |
Output signal | 4-20mA (with HART)、RS485 | |
MIK-RD704 Guided wave radar level meter | ||
Application conditions | Low dielectric constant liquids (deionized water、deoxygenated water) | |
Range | 0-6m | |
Frequency range | 500MHz-1.8GHz | |
Accuracy | ±5mm | |
Antenna | Coaxial tube antenna | |
Process temperature | -40 ~ 130 ℃ | |
Process pressure | -0.1 ~ 0.6MPa | |
Protection connection | Screw/flange | |
Output signal | 4-20mA (with HART)、RS485 | |
