Месяц | Минимальная цена | Макс. стоимость |
---|---|---|
Sep-19-2025 | 5355.29 $* | 5623.57 $* |
Aug-19-2025 | 5310.82 $* | 5576.92 $* |
Jul-19-2025 | 4455.45 $* | 4678.89 $* |
Jun-19-2025 | 5220.73 $* | 5481.57 $* |
May-19-2025 | 4545.96 $* | 4772.79 $* |
Apr-19-2025 | 5130.52 $* | 5387.58 $* |
Mar-19-2025 | 5085.54 $* | 5339.43 $* |
Feb-19-2025 | 5040.40 $* | 5292.61 $* |
Jan-19-2025 | 4995.66 $* | 5245.97 $* |
Model | FB10 | FB15 | FB20 | FB25 | |||
Rated Loading Capacity(kg) | Rated Loading Capacity(kg) | 1000 | 1500 | 2000 | 2500 | ||
Load center(mm) | 400 | 500 | 500 | 500 | |||
Drive Form | Electric | Electric | Electric | Electric | |||
Tyre type | Solid | Solid | Solid | Solid | |||
Fork Lifting Height(mm) | 3000 | 3000 | 3000 | 3000 | |||
Free lifting height(mm) | 70 | 60 | 60 | 80 | |||
Mast Tilt Angle (Forward and Backward)(°) | 5/10 | 5/10 | 5/10 | 6/12 | |||
Wheel Base(mm) | 1260 | 1450 | 1450 | 1560 | |||
Wheel distance | Front (mm) | 843 | 920 | 920 | 1008 | ||
Back (mm) | 869 | 928 | 928 | 981 | |||
Overall dimensions | Length (excluding Fork) (mm) | 1852 | 2160 | 2160 | 2360 | ||
Width(mm) | 1000 | 1100 | 1100 | 1160 | |||
Overhead guard height(mm) | 1920 | 2040 | 2040 | 2190 | |||
Height of mast lowered | 1955 | 1933 | 1933 | 2030 | |||
Seat height | 835 | 1036 | 1036 | 1154 | |||
Min. Turning Radius(mm) | 1550 | 1650 | 1650 | 2180 | |||
Minimum right-angle stacking channel width(mm) | 2350 | 2450 | 2450 | 2950 | |||
Min. Ground Clearance(mm) | 106 | 106 | 106 | 122 | |||
Fork specifications(mm) | 32*100*1070 | 32*100*1070 | 32*100*1070 | 32*100*1070 | |||
Distance between forks(mm) | 200-944 | 200-1062 | 200-1063 | 244-1149 | |||
Cylinder bore(mm) | 45 | 45 | 45 | 50 | |||
Gear pump displacement(ml/r) | 14 | 14 | 14 | 16 | |||
Tyre model | Front (mm) | 16x9-18 | 18x7-10 | 18x7-10 | 23x10-12 | ||
Rear (mm) | 15x4 1/2-18 | 4.00-8 | 4.00-8 | 18x7-10 | |||
Performance parameter | Driving Speed (Empty/Full load) (km/h) | 12/12 | 12/12 | 12/12 | 12/12 | ||
Rear Wheel Tyre | Lifting Speed (Empty/Full load) (mm/h) | 250/300 | 250/300 | 250/300 | 250/300 | ||
Maximum climbing angle(%) | 10/15 | 10/15 | 10/15 | 10/15 | |||
Motor | Driving Motor(kw) | 3.7 | 5 | 6 | 8 | ||
Maximum speed of driving motor(rad/min) | 3800 | 3500 | 3500 | 3400 | |||
Oil pump motor(kw) | 3 | 4 | 5 | 9 | |||
Maximum speed of oil pump motor (rad/min) | 2000 | 2000 | 2000 | 2000 | |||
Battery | Voltage(V) | 60 | 72 | 72 | 72 | ||
Engine | Capacity(Ah) | 120(optional) | 140(optional) | 160(optional) | 180(optional) | ||
Input voltage(V) | 220/380 (optional) | 220/380 (optional) | 220/380 (optional) | 220/380 (optional) | |||
Engine | Current(A) | 20 | 25 | 30 | 30 | ||
Charging time(h) | 8-10 | 8-10 | 8-10 | 8-10 | |||
Electric control current(V/A) | 60/350 | 72/350 | 72/450 | 72/550 | |||
Steering system | Hydraulic | Hydraulic | Hydraulic | Hydraulic |
