FOWAY 2205PF 5-разъемное зарядное usb-устройство для управления дополнительно 4 10/100 м коммутатор Poe Switch промышленный 48V
- Категория: Network Switches >>>
- Поставщик: Shenzhen,Hio,Link,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-19-2025 | 32.82 $* | 33.56 $* |
| Jul-19-2025 | 26.8 $* | 27.48 $* |
| Jun-19-2025 | 31.45 $* | 32.52 $* |
| May-19-2025 | 31.35 $* | 32.50 $* |
| Apr-19-2025 | 25.24 $* | 26.95 $* |
| Mar-19-2025 | 31.21 $* | 32.34 $* |
| Feb-19-2025 | 30.71 $* | 31.8 $* |
| Jan-19-2025 | 30.34 $* | 31.53 $* |
Характеристики
Technical Specification
Parameter | Specification |
Standard | IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet,IEEE802.3x Flow control,IEEE802.1q VLAN,IEEE802.1p QoS, IEEE802.1d Spanning Tree,IEEE802.3af,IEEE802.3at |
POE | 4 10/100M RJ45 PoE/PSE, support IEEE802.3af 15.4W / IEEE802.3at 30W Working mode:auto detect powered device,stop powering if not PD device |
Wavelength | 850nm/1310nm/1490nm/1550nm/ |
Transmission distance | 100M Fiber,multi-mode:2km; Single-mode:25/40/60/80/100/120Km Single-fiber:25/40/60/80/100/120Km CAT5: 100M |
Port | 4 10/100M RJ45 ports (POE/PSE): 10/100Mbs 1 100M FX uplink port: 100Mbps |
MAC | 2K |
Buffer memory space | 1Mbit |
Bit error rate | <1/1000000000 |
MTBF | 100,000 hours |
Power | DC48V dual input redundant backup |
Power consumption | Whole device:5W POE/PSE: maximum70W |
Working temperature | Common:-10~60℃; -T (wide temperature range):-40~75℃ |
Storage temperature | -40~80°C |
Humidity | 5%~90% non-condensing |
Installation | Wall mounting type |
Dimensions | 28mm (H)×193mm(W)×119mm (D) |
Order information
NO | Product code | NMS | Ports | PoE ports |
1 | Foway2205PF-4AF | No | 4 10/100M PoE+ 1 100M FX uplink | IEEE802.3af 15.4W, total 62w |
2 | Foway2205PF | No | 4 10/100M PoE+ 1 100M FX uplink | IEEE802.3af/at 15.4W/30W, total 62w |
3 | Foway2205PF-120W | No | 4 10/100M PoE+ 1 100M FX uplink | IEEE802.3af/at 15.4W/30W, total 120w |
4 | Foway2205PFM-4AF | Yes | 4 10/100M PoE+ 1 100M FX uplink | IEEE802.3af 15.4W, total 62w |
5 | Foway2205PFM | Yes | 4 10/100M PoE+ 1 100M FX uplink | IEEE802.3af/at 15.4W/30W, total 62w |
6 | Foway2205PFM-120W | Yes | 4 10/100M PoE+ 1 100M FX uplink | IEEE802.3af/at 15.4W/30W, total 120w |
