Hydraulic Press Cutting Machine





USE AND CHARACTERS:

1. Widely applicable for cutting of nonmetal materials in various industries by die cutter.

    For example leather, rubber,plastic, plastic packing, textile and chemical fibre etc.

2. Adopt double oil cylinder, precise double-crank connecting rod mechanism,

    which can guarantee that the cutting depth at every cutting position is same.

3. With special setting mechanism, and equipped with die cutter and cutting depth setting,

    the travel adjustment is simple and accurate.

4. The pressing board of cutting carries out slow cutting when it contacts the die cutter,

    which can make that there is no size error between the uppermost layer and lowermost layer of cut materials.

5. The central oil supply automatic lubricating system guarantees machine precision and prolongs service life of machine.

6. The operation is labor-saving and simple, with low malfunction, strong cutting power and high cutting speed.

7. Operation with two hands makes high safety.



Technical parameters:



Maximum cutting force	50Tons
Travel adjustment range	0-110mm
Range between the working tables	50-180mm
Size of the upper pressing board	1600*500mm
Size of lower worktable	1600*510mm
Main motor power	2.3kW
Electric Supply Voltage	as optional
Automatic grade	manual
Drive type	hydraulic
hydraulic oil	46# or 68#
Machine color	as required
Net weight	1600kgs
Gross weight	1650kgs
Dimension	2220*1160*1320mm
